HP Server Slide Mount Kit AB294A

for NEBS 2000 Rack

Installation Instructions

Manufacturing Part Number: AB294-96001

April 2004

U.S.A.

Legal Notices

The information contained herein is subject to change without notice. The only warranties for HP products

and services are set forth in the express warranty statements accompanying such products and services.

Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for

technical or editorial errors or omissions contained herein.

Printed in the U.S.A.

Reproduction, adaptation, or translation of this document without prior written permission is prohibited,

except as allowed under the copyright laws.

Related Documents. The latest versions of server documents, and any updates to these documents are

posted under the appropriate server at http://docs.hp.com. For online access to technical support information,

self-solve tools, online assistance, community forums of IT experts, broad multi vendor knowledge base, and

monitoring and diagnostic tools, go to http://www.hp.com/support.

Chapter 1 3

1HP Server Slide Mount Kit for NEBS 2000

Rack – Installation Instructions

Introduction

This manual provides instructions for installation of the hp Integrity cx2600 server chassis on slides in a

NEBS 2000 rack.

Cabinet Safety Precautions

WARNING Ensure that the rack is level and stable before working on the rack. Be sure the

leveling jacks (feet) extend to the floor and that the full weight of the rack rests

firmly on the floor.

WARNING Ensure that the rack has anti-tip measures in place. Such measures may include

floor-bolting, anti-tip feet, ballast, or a combination of these measures as specified by

the rack manufacturer and applicable codes.

WARNING Be sure that adequate personnel are on hand to support the product(s) during the

installation process. Use of the appropriate lifting device is recommended as an

installation aid.

WARNING Always load the rack from the bottom up. Load the heaviest items in the rack first.

This makes the rack bottom-heavy and helps prevent the rack from becoming

unstable.

WARNING After mounting, extend only one chassis at a time. The rack can become unstable if

more than one chassis in extended.

WARNING Use caution when pressing the slide lock release latches before sliding the chassis

into the rack. Your fingers can be pinched by moving slide parts.

WARNING When extending a chassis, pull the chassis slowly from the rack. Extending the

chassis too quickly can result in damage to the slide rails.

WARNING Do not overload the branch circuit that provides power to the rack. The total rack

load should not exceed 80% of the branch circuit rating.

HP Server Slide Mount Kit for NEBS 2000 Rack – Installation Instructions

Introduction

Chapter 1

Mounting Kit Contents

This manual provides installation instructions for server mount kit AB294A. This kit is intended for use with

the hp Integrity cx2600 server, and includes the following:

• Two Slide Assemblies

• Two Front Mount Brackets (pre-assembled onto Slide Assembly)

• Two Rear Mount Brackets (pre-assembled onto Slide Assembly)

• Two Inside Track Slides (pre-assembled onto Slide Assembly)

• Two Rear Chassis Rack Mount Brackets

• Two Rear Cable Routing Brackets

• One Cable Management Strain Relief Bar

• Four Rack Mount Retainer Bars

• Mounting Hardware (screws and nuts)

HP Server Slide Mount Kit for NEBS 2000 Rack – Installation Instructions

Installation Procedure

Chapter 1 5

Installation Procedure

Figure 1-1 HP Integrity cx2600 Servers Mounted in a NEBS 2000 Rack

Mounting Kit

Before mounting your server in the NEBS 2000 rack, inspect the mounting kit hardware. Check that all

required mounting hardware is available. A mounting kit parts list is provided at the rear of this manual.

Mount the Server

Mount a server in the NEBS 2000 rack as follows:

Step 1. Remove the rear door from the rack. Set this door aside because it will not be reinstalled.

Step 2. Attach the rear cable routing brackets to each side of the server chassis with T15 flathead screws.

2600inrack1

HP Server Slide Mount Kit for NEBS 2000 Rack – Installation Instructions

Installation Procedure

Chapter 1

Figure 1-2Attach the Cable Routing Brackets and Inner Slides to the Server

Step 3. Remove the inner rail assemblies (inside track slides) from the slide assemblies and attach an inner

rail to each side of the server chassis with T15 waferscrews. (Observe that the bend in this slide rail

is at the front of the chassis.)

Step 4. Remove the outer rail assemblies from the slide assemblies and loosen the rear screws.

Step 5. Install the outer rails in the rack at the desired mounting position. Push slide rails tightly against

the rack columns while securing the rails in place with T25 screws.

Figure 1-3Attach the Outer Slide Assemblies to the Rack Columns

chasrails1

Cable

Routing

Brackets

Inner Slide Rail

T15

Waferscrews

rckrails2

T25 Screws

Rack Mount

Bracket

Retainer Bar

T25 Screws Outer Slide

Rails

HP Server Slide Mount Kit for NEBS 2000 Rack – Installation Instructions

Installation Procedure

Chapter 1 7

Step 6. Tighten the rear screws (loosened in step 4) on the outer slide rails.

Step 7. Install the rack mount retainer bars on the inner side of each column, above the slides as shown in

Figure 1-3. Secure each retainer bar with one T25 screw, using the top threaded hole in the retainer

bar.

Step 8. Install the rear chassis rack mount brackets on the outer side of each rear column, aligned with the

retainer bars as shown in Figure 1-3. Secure each rear rack mount bracket to the retainer bar with

two T25 screws.

Step 9. Insert the chassis-mounted slides into the rack-mounted slides and push the chassis fully into the

rack. Press the blue tabs on the slides to release slide locks and allow insertion.

Step 10. Secure the chassis to the front of the rack with T25 screws. (The screws thread into the front

retainer bars installed in step 7.)

Step 11. Secure the rear chassis cable routing brackets on the chassis to the rear chassis rack mount

brackets on the rear columns with two T25 screws.

Figure 1-4Install the Cable Management Bar

Step 12. Secure the cable management strain relief bar to the rear rack brackets on the chassis with two

T25 screws.

cmbar2

T25 Screws

Cable Management

Strain Relief Bar

HP Server Slide Mount Kit for NEBS 2000 Rack – Installation Instructions

AB294A Rack Mount Kit

Chapter 1

AB294A Rack Mount Kit

The HP Server Mounting Kit, part number AB294A includes the items listed below.

* This item is not available as an individual replacement part. To purchase this part, you must order Slide

Assembly AB294-00003.

Table 1-1 Mounting Kit Parts List

Item Quantity HP Part Number

Slide assembly 2 AB294-00003

Bracket, rear mount

(pre-assembled to the

slide assembly)

2 AB294-00004*

Bracket, front mount

(pre-assembled to the

slide assembly)

2 AB294-00001*

Slide, inside track,

(pre-assembled onto slide

assembly)

2 AB296-00006*

Rack mount retainer bar,

4 AB293-00006

Rear chassis cable

routing bracket

2 AB293-00001

Rear chassis rack mount

bracket

2 AB293-00005

Cable management

strain relief bar

1 AB292-00011

Screw, T15, waferscrew

w/captive lockwasher, M4

x 7 mm 7.5 mm

8 A6474-00134

Screw, T15, M4 x 0.7 x

6 mm, flathead

w/patchlock

8 0515-2042

Screw, T25, 10-32 x

0.625", panhead w/CC

washer

28 2680-0323

HP Server Slide Mount

Kit AB294A for NEBS

2000 Rack, Installation

Instructions

1 AB294-96001
