Hozelock 7816 Manuel utilisateur

2823

7816

7819

Hozelock Ltd.

Midpoint Park,

Birmingham B76 1AB. England

Tel: +44 (0) 121 313 1122

[email protected]

www.hozelock.com

33801-001

1Depth A & B must be less than 9m Max

Depth C must be less than 9m Max

garden PUMP kit

33801-001 GardenPump Inst 6/11/07 12:52 Page 1

A B

Ensure seals are fitted to the front between the

pump and the adaptor

Ensure hand tight

Ensure filter is

fitted the correct

way around

Ensure seal is

fitted to the

front between

the adaptor and

the filter

Ensure hand

tight

Ensure that the

pump is filled to

the brim with

clean water

There is no

requirement to

fill the hose or

filter with water

Ensure seal is fitted to the front between the filter

and the hose

Ensure all fittings are hand tight

6mm

33801-001 GardenPump Inst 6/11/07 12:52 Page 2

G H I

L MK

The hose should be open i.e. the other end not blocked or

closed with either a spray gun or water stop connector

The pump will prime, this can be noisy and can take up to

5 minutes. It is complete when the pressure from the hose is

steady and the noise is reduced

33801-001 GardenPump Inst 6/11/07 12:52 Page 3

High pressure water can be

dangerous, always turn the power

to the pump off before

disconnecting the hose from the

pump

If the pump is running, and the

water is prevented from flowing

(eg. spraygun is in off mode) then

the water inside the pump can

become very hot. Never run the

pump for more than 10 minutes

without water flowing

Warning : Read this manual

carefully before installing this

pump.

This sign warns the user that

failure to follow an instruction may

damage the pump or the system

This sign warns the user of

important electrical safety

information.

Carefully store this manual.

If problems arise contact

Hozelock customer services.

Every Hozelock Garden Pump

is carefully tested and packed during

assembly.

On receipt, check that the pump has not

been damaged during transport. If the

pump is damaged, do not use, and

contact Hozelock customer services.

Check that the voltage and frequency

of pump shown on the rating label

corresponds to those available on the

mains.

ELECTRICAL INSTALLATION:

A 10MA OR 30MA RESIDUAL

CURRENT DEVICE (RCD)

MUST BE FITTED TO THE

MAINS SUPPLY.

PROTECT THE PLUG AND THE

POWER CABLE FROM HEAT,

OIL AND SHARP EDGES.

THE POWER CABLE SHOULD

ONLY BE REPLACED BY

QUALIFIED PERSONNEL.

MAKE SURE THAT

ELECTRIC CONNECTIONS ARE

PROTECTED FROM WATER

& SPLASHES

THE INSTALLATION OF THE PUMP

SHOULD BE ON A STABLE FLAT

DRY SURFACE

THE PUMP MUST NOT BE

SUBMERGED

THE POWER CABLE SHOULD

HAVE A MINIMUM OF 3 CORE

0.75MM2SECTION EQUIVALENT

TO THAT OF H05 RN-F. TO MAKE

SURE THE PLUG IS PROTECTED

FROM ANY SPLASHES, USE THE

CABLE SUPPLIED TO CONNECT

AS FAR AWAY FROM THE PUMP

AS POSSIBLE

BEFORE USING THE PUMP,

ALWAYS INSPECT IT VISUALLY

(ESPECIALLY THE POWER CABLE

AND THE PLUG). DO NOT USE

THE PUMP IF IT IS DAMAGED.

NEVER USE THE POWER CABLE

TO LIFT THE PUMP.

Electrical SafetyGeneral Safety

33801-001 GardenPump Inst 6/11/07 12:52 Page 4

This pump can be used to:

Drive sprayguns, sprinklers and micro

irrigation systems

This pump is not suitable to be

used with swimming pools, where

people can become immersed in

the water.

This pump is not suitable for table

fountains / aquariums / Fountains /

Filters for fish ponds / Waterfalls.

The pump cannot be used for sea

water & inflammable, corrosive,

explosive or dangerous liquids.

Do not run dry.

The pump must be used with the

filter supplied, this protects the

pump from debris that may be

present in the water. Failure to use

the filter will invalidate the pump

warranty

If the pump is not going to be

useg for more than one month or

there is a risk of freezing, the

pump, filter and hose should be

drained.

Pump performance depends upon

the length and diameter of the

outlet hose (watering hose), and

the height that the water is

pumped.

Before installation, and whenever

you are handling the pump,

always disconnect from the

electrical supply.

To prevent injury, never put your

fingers into the mouth of the pump.

• Use the handle provided to carry or

lift the pump

• When used with a Water Butt for the

first time, ensure the water butt is

emptied and cleaned of all sediment,

leaves and accumulated debris.

Pump assembly :

Attach the metal baseplate to the

pump with the bolts and washers

supplied

Screw one of the yellow accessory

adaptors to the inlet of the pump

Screw the filter onto the adaptor.

The arrow on the filter should

point towards the pump.

Remove filter adaptor from hose

and attach the suction hose to the

filter

Ensure that the inlet to the suction

hose is at least 150mm (6") under

the surface of the water. If required

weight the end of the hose using a

brick.

It is critical that all the seals are

present and that all the joints

are airtight.

There should be no elbows or

kinks in the suction hose as this

will affect performance

The installation should be

consistant with the limitations as

shown in diagrams A & B on the

cover of this booklet

InstallationLimitations

33801-001 GardenPump Inst 6/11/07 12:52 Page 5

Fill the pump chamber to the brim

with tap water using a watering can

The Hozelock garden pumps are

self priming, therefore they can

be primed without filling the

suction pipe or filter.

Attach the outlet connector to the

outlet of the pump

Connect the garden hose to the

outlet, ensuring that the other end

of the garden hose is open and that

it will be free to drain when the

pump is turned on

Ensure that the suction hose is

under the surface of a suitable

water reservoir (water butt etc.)

Plug the pump into a suitable power

supply

When the power is turned on, the

pump will start the priming process.

This operation can take several

minutes. During the priming process

the pump is pumping a mixture of

air and water, this drastically reduces

the performance of the pump and is

very noisy.

When the pump is primed and ready

to use, the noise reduces and the

flow and pressure are maximised.

If any of the seals or fittings are

missing, overtightened or loose

the pump will not prime

If the pump does not prime

after 5 minutes - stop and

repeat steps 6 to 10

TO CONNECT TO AN IRRIGATION

SYSTEM:

■For use with hoses and hose reels

add a 2166 hose connector

(available separately)

• The Hozelock Garden Pump has a

built in thermal protection switch.

The pump stops if an overload

condition occurs. The motor restarts

automatically after it has cooled

down.

• Insert the plug into a 220-240v A/C

socket

Make sure that the pump is

disconnected from the electric

power supply before performing

any maintenance.

If pump performance drops it may

be because the two filters in the kit

have become clogged, and require

cleaning

Regularly check the coarse filter on

the end of the suction hose, and

clean if required. After checking or

cleaning the pump with new

repriming. See steps F-J.

Regularly check fine filter fitted

prior to the pump, and clean if

required.

Use the large plastic spanner

supplied to loosen large yellow

locking nut

Remove cup and filter, clean under a

tap. ! Do not scrub

Reassemble, and make sure the nut

is tightened securely - use spanner

provided

• Disconnect hose and loosen bottom

red nut and allow to drain

• Store the pump in a dry place and

protect from frost.

Installation Overload protection

To start the pump

Maintenance

Pump storage

33801-001 GardenPump Inst 6/11/07 12:52 Page 6

Troubleshooting

Problem Possible Cause Remedy

The pump does

not pump water

and the motor is

not running

No electricity Check that the electricity supply

is turned on and that the pump is

correctly plugged in

Plug inserted incorrectly

Circuit breaker is

tripped

Reset electricity supply.

If the circuit breaker trips once

more contact a specialised

electrician

Damaged motor Contact hozelock customer

services for assistance

Pump has overheated Pump contains thermal

protection - check if pump case is

hot, and if so, allow to cool

The pump

supplies a

limited amount

of water or the

pump does not

pump water,

and the motor is

running, even

after several

minutes the

pump is still

noisy

Pump full of air Unplug from the electricity

supply

Pump is not primed Repeat priming process - follow

steps 6 -10

Obstructed inlet Check inlet is under surface of

water, inlet filter is clean, and

inlet hose is not kinked or

damaged

Obstructed pipe/outlet Remove obstructions in inlet hose

or kinks

Worn impeller Contact Hozelock customer

services for assistance

33801-001 GardenPump Inst 6/11/07 12:52 Page 7

Troubleshooting

Problem Possible Cause Remedy

The pump

works only

intermittently

The temperature of the

fluid is too high

Only use with fluids below 35ºC

Fluid too dirty Empty and clean the water butt,

refill with fresh rain/tap water

Faulty motor Contact Hozelock customer

services for assistance

Water is leaking

from the outlet

of the pump

Inlet assembly not tight

enough

Tighten

Hozelock connector not

correctly attached

Re-attach Hozelock connector

33801-001 GardenPump Inst 6/11/07 12:52 Page 8

33801-001 GardenPump Inst 6/11/07 12:52 Page 9

33801-001 GardenPump Inst 6/11/07 12:52 Page 10

Autres manuels pour 7816

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Hozelock Pompe à eau

Hozelock

Hozelock TECNOTRONIC Manuel utilisateur

Hozelock

Hozelock cascade 1500 Manuel utilisateur

Hozelock

Hozelock FLOWMAX 4500 Manuel utilisateur

Hozelock

Hozelock 7606 Manuel utilisateur

Hozelock

Hozelock TECHNODIVE 6000 Manuel utilisateur

Hozelock

Hozelock FLOWMAX 10200 Manuel utilisateur

Hozelock

Hozelock 7816 Manuel utilisateur

Hozelock

Hozelock 7825 Manuel utilisateur

Hozelock

Hozelock Flood Pump 7825 Manuel utilisateur

Hozelock

Hozelock Flowmax Collect 2200 Manuel utilisateur

Hozelock

Hozelock Flowmax Collect 2200 Manuel utilisateur

Hozelock

Hozelock Titan 3000 Manuel utilisateur

Hozelock

Hozelock 2826 Manuel utilisateur

Hozelock

Hozelock 7816 Manuel utilisateur

Hozelock

Hozelock cascade 450 Manuel utilisateur

Hozelock

Hozelock easyclear LV Manuel utilisateur

Hozelock

Hozelock EASYCLEAR 3006 Manuel utilisateur

Hozelock

Hozelock 7825 Manuel utilisateur

Hozelock

Hozelock 3000 K7 Manuel utilisateur

Hozelock

Hozelock titan 5500 Manuel utilisateur

Hozelock

Hozelock aquaforce 6000 Manuel utilisateur

Hozelock

Hozelock EASYCLEAR 6000 Manuel utilisateur

Hozelock

Hozelock Aquaforce 1000 Manuel utilisateur

Hozelock

Hozelock JET 3500 K7 AUTOMATIC 7608 Manuel utilisateur

Manuels Pompe à eau populaires d'autres marques

Neptun

Neptun NPHW 5500 Manuel utilisateur

Sensidyne

Sensidyne Gilian BDX-II Instructions d'installation et d'utilisation

Draper

Draper 47808 Manuel utilisateur

Trolla

Trolla 12820 Manuel utilisateur

Sunfab

Sunfab SVH Series Manuel utilisateur

WilTec

WilTec 50740 Manuel utilisateur

Fieldmann

Fieldmann FVC 5015 EK Manuel utilisateur

Everbilt

Everbilt EFSUB5-122HD Manuel utilisateur

Graco

Graco Husky 3300e Manuel utilisateur

esotec

esotec 101018 Manuel utilisateur

moyno

moyno 2000 CC Manuel utilisateur

Becker

Becker BASIC VASF 2.80/1-0.AC230 Manuel utilisateur

Sykes AmeriPumps

Sykes AmeriPumps GP100M Guide de dépannage

DUROMAX

DUROMAX XP WX Series Manuel utilisateur

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Manuel utilisateur

Franklin Electric

Franklin Electric IPS Manuel utilisateur

Xylem

Xylem e-1532 Series Manuel utilisateur

Milton Roy

Milton Roy PRIMEROYAL Manuel utilisateur
