Hotpoint C150E Manuel utilisateur

Instructions

C150E

Installation 5-6

For your Safety – Always 7

For your Safety – Never 8

Features 9

Control Panel 10

Hotplates General Information Notes 11-12

Temperature Conversion Chart 13

Grill 14

Grill Chart 15

Oven 16

Oven Cookery Notes 17-19

Care and Cleaning 20-21

Cooking Results Not Satisfactory 22

Something Wrong with your Cooker 23

Key Contacts Back Cover

Contents

Introduction 4

You must read these instructions prior to using the appliance and

retain them for future reference.

Introduction

This appliance conforms to the following EEC Directives:

Electromagnetic Compatibility Low Voltage Equipment

89/336/EEC 73/23/EEC

92/31/EEC 93/68/EEC

93/68/EEC

To minimise the risk of injury to children please dispose of your product carefully and safely.

Remove all doors and lids. Remove the mains cable (where fitted) by cutting off flush with the

appliance and always ensure that no plug is left in a condition where it could be connected to

the electricity supply.

To help the environment, Local Authority instructions should be followed for the disposal of

your product.

DISPOSAL OF YOUR PRODUCT

Your new appliance is guaranteed* and will give lasting service. This guarantee is only applicable

if the appliance has been installed in accordance with the installation instructions detailed in this

booklet.

To help make best use of your cooking equipment, please read this booklet carefully.

The cooker is designed specifically for domestic use and responsibility will not be accepted for

use in any other installation.

When first using the cooker ensure that the room is well ventilated (e.g. open a window or use an

extractor fan) and that persons who may be sensitive to the odour avoid any fumes. It is suggest-

ed that any pets be removed from the room until the smell has ceased. This odour is due to tem-

porary finish on oven liners and elements and also any moisture absorbed by the insulation.

When the cooker is first used an odour may be emitted,

this will cease after a period of use

* The guarantee is subject to the provisions that the appliance:

(a) Has been used solely in accordance with the Users Instruction Book.

(b) Has been properly connected to a suitable supply voltage as stated on the

rating plate attached to this equipment.

any person other than the authorised employee or agent.

(d) Has been correctly installed.

Installation

WARNING – THIS APPLIANCE MUST BE EARTHED.

Your cooker should have been checked to ensure

that the

voltage corresponds with your supply volt

age,

this is stated

on the rating plate, which is situated

on the rear panel.

The cooker must be connected by a competent

person eg. (NICEIC registered contractor) to suitable

double-pole control unit with a minimum rating of 32A

and a minimum contact clearance of 3mm, which should

be fitted adjacent to the cooker, in accordance with IEE

regulations.

The power supply cable should conform to B.S.6004 with a

conductor size of 6mm2minimum.

The control unit should be easily accessible in the event of

an emergency, but must be within 2 metres of and not

directly above an appliance.

This appliance conforms to EN 55014 regarding

suppression of radio and television interference.

Access to the mains terminals is gained by removing the

rear access cover.

The mains cable must pass through the cable clamp

adjacent to the terminal block. Sufficient cable should be

used to allow the cooker to be pulled out for servicing.

Ensure that the mains cable is routed away from any

brackets affixed to the rear panel and is not trapped to the

rear wall when pushing the cooker into position between

cabinets.

The cooker is designed to fit between kitchen

cabinets spaced 500mm apart. The space either side need

only be sufficient to allow withdrawal of the cooker for

servicing. It can be used with cabinets one side or both

as well as in an angled corner setting. It can also be used

free standing.

This cooker is a Type X appliance, as such adjacent side

walls which project above hob level, must not be nearer to

the cooker than 150mm and should be

protected by heat

resistant material. Any overhanging

surface or cooker hood

should not be nearer than 650mm.

The height of the cooker can be adjusted by means of

adjustable feet in the plinth (900mm - 915mm). Adjust the

feet by tilting the cooker from the side. Then install the

cooker into position.

Siting the Cooker

Moving the Cooker

Before moving your cooker, switch off at the cooker

control unit, ensure that it is cool.

Movement of your cooker is most easily achieved by lifting

the front as follows:

Open the grill door sufficiently to allow a comfortable grip

on the underside front edge of the oven roof, avoiding any

grill elements.

Note: Take care in moving the cooker as it is heavy.

Take care to ensure that any floor covering is not

damaged.

Splashplate optional, apply to Parts Department

(see Back Cover for contact number.)

Splash Panel

Kit (Wall Mounted)

Safety Information

When used properly your appliance is completely safe but as with any electrical product

there are certain precautions that must be observed.

PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE.

●Remove all packing from the appliance before switching on for the first time.

●Understand the controls prior to using the appliance.

●Keep children away from the appliance when cooking as the surfaces will get extremely hot

during and after use.

●Turn controls off when not in use.

●Stand back when opening an oven door to allow any build up of steam or heat to disperse.

●

Always use dry good quality oven gloves when removing items from the oven/grill.

●Always place pans centrally over the hotplate making sure handles are kept away from the

edge of the hob and cannot become heated by other hotplates or pans.

●

Always take care to avoid heat or steam burns when operating the controls.

●Always turn off the electricity supply at the wall switch and allow the appliance to cool before

cleaning (or changing an oven lamp if fitted).

●

Always make sure the shelves are in the correct position before switching on the oven or grill.

●Always keep the oven/grill door closed when the appliance is notin use.

●Always keep the appliance clean as a build up of grease or fat from cooking can cause a fire.

●

Always follow the basic principles of food handling and hygiene to prevent the possibility of

bacterial growth.

●Always keep ventilation slots clear of obstructions.

●Always refer servicing to a qualified appliance service engineer.

●Always take care when removing items from the grill compartment when the lower oven is in

use as the contents will be hot

●Always turn off the electricity supply to the appliance at the wall switch should any glass

panel (if fitted) crack or shatter and then DO NOT USE THE APPLIANCE until repaired.

●During use, the oven becomes hot. Care should be taken to avoid touching heating elements

inside the oven.

Always

Safety Information

●Never stare at Halogen heating units

●Never leave children unsupervised where a cooking appliance is installed as all surfaces will

be hot during and after its use.

●Never allow anyone to sit or stand on any part of the appliance.

●

Never store items above the appliance that children may attempt to reach.

●Never leave anything on the hob surface when unattended and not in use.

●Never remove the oven shelves whilst the oven is hot.

●Never heat up unopened food containers as pressure can build up causing the container to

burst.

●Never store chemicals/food stuffs or pressurised containers in or on the appliance, or in cabi-

nets immediately above or next to the appliance.

●Never place flammable or plastic items on or near the hob.

●Never fill a deep fat frying pan more than 1/3 full of oil, or use a lid.

DO NOT LEAVE DEEP FAT FRYING PANS UNATTENDED WHILE COOKING.

●Never use the appliance as a room heater.

●Never use the grill to warm plates.

●Never dry any items on either the hob or oven doors.

●Never install the appliance next to curtains or other soft furnishings.

●Never operate the grill with the grill door closed as this will cause the appliance to over heat.

Never

SAFETY ADVICE IN CASE OF A CHIP-PAN FIRE

In the event of a chip pan fire or any other pan fire.

1. TURN OFF THE COOKER APPLIANCE AT THE WALL SWITCH.

2. COVER THE PAN WITH A FIRE BLANKET OR DAMP CLOTH, this will smother the flames and

extinguish the fire.

LEAVE THE PAN TO COOL FOR AT LEAST 60 MINUTES BEFORE

MOVING IT. Injuries are often

caused by picking up a hot pan and rushing outside with it.

NEVER USE A FIRE EXTINGUISHER TO PUT OUT A PAN FIRE as the force

of the extinguisher is likely to tip the pan over.

Never use water to extinguish oil or fat fires.

Features

A0272

2.0kW

HOTPLATE

REDSPOT

GRILL

DOOR

GRILL

MODEL/SERIAL NO.

PLINTH

VENTILATION

SLOTS

HOB VENTILATION SLOTS

RATING PLATE (ON REAR PANEL)

1.5kW

HOTPLATE

1.5kW

HOTPLATE

REDSPOT

CONTROL

PANEL

STAYCLEAN

REMOVABLE

SIDE PANELS

OVEN ROD

SHELVES

GRILL PAN

WITH REMOVABLE

HANDLE AND WIRE

FOOD SUPPORT

1.0kW

HOTPLATE

OVEN

PILOT

LIGHT

Control Panel

LEFT

FRONT

HOTPLATE

LEFT

REAR

HOTPLATE

RIGHT

REAR

HOTPLATE

RIGHT

FRONT

HOTPLATE

GRILL

CONTROL OVEN

CONTROL

GRILL

PILOT

LIGHT

Control Knobs The knobs for the grill and hotplates can be rotated in either

direction to provide variable heat control, the oven knob can

only be rotated clockwise from the off position.

Note: Always ensure that all controls are in the OFF position,

when appliance is not in use.

Operating the In common with all cookers having controls sited above the grill

control when the compartment, care must be taken when setting the controls, due

grill is in use to hot air being emitted from the grill compartment.

❍❍❍❍❍❍
