Hoshizaki

©HOSHIZAKI AMERICA, INC.

618 Hwy. 74 S., eachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com

CUBER DIMENSIONS

WxDxH

SLIM-LINE MODULAR CRESCENT CUBER

Warranty

Valid in United States, Canada, uerto Rico, & U.S.Territories. Contact factory for warranty in

other countries.

Three Year - arts & Labor on entire machine.

Five Year - arts & Labor on: Evaporator.

Five Year - arts on: Compressor, air-cooled condenser coil.

KM-600MAH

Item #

Project:

Qty:

Hoshizaki reserves the right to change specifications without notice.

KM-600M_H

22 x 273/8 x 377/16

*AutoCad available on KCL

•115 - 120V supply volta e

•Up to 592 lbs. of ice production per 24 hours

•Durable stainless steel exterior

•Protected by HoshiGuard Antimicrobial A ent

•Individual crescent cube

•CycleSaver®Desi n

•EverCheck®alert system

•Stainless steel evaporator

•Mount two units side-by-side, in only 44" of floor space, for 1,184 lbs. per 24 hours

•Removable air filters (Air-cooled model only)

•R-404A Refri erant

•Complies with California Ener y Commission uidelines (CEC)

* The KM-600MAH is ENERGY STAR certified.

KM-600MAH

Air-Cooled

Shown on an optional

B-300 Bin

B-900

B-800

B-700

B-500

B-300

Also ava lable on Large B ns:

B-1150SS

B-1300SS

B-1500SS

B-1650SS

KM-600MAH

7/08

Item # 13231

Hoshizaki

DIMENSIONS

WxDxH

©HOSHIZAKI AMERICA, INC.

KM-600MAH

SLIM-LINE MODULAR CRESCENT CUBER

UTILITY CONSUMPTION

AIR-COOLED

Model Number

70˚

50˚ 70˚

592

90˚

80˚

90˚

Ice Production

Per Cycle

K H per

100 LBS.

Potable

ater

Gal. per

100 lbs.

Lbs. Cubes

Air Temp˚ F.

ater Temp˚ F.

SPECIFICATIONS

Model Number Condenser Amperage Min. Circuit

Ampacity Shipping

eight

5.7 19.7

572

566

532

516

474

447

14.3 720

503

90/70

Condenser

ater

Gal. per

100 lbs.

N/A

O P E R AT I N G L I M I T S

• Ambient Temp Range 45 - 100˚F

• Water Temp Range 45 - 90˚F

• Water ressure 10 - 113psig

• Voltage Range 104 - 127V

ELECTRICAL&PLUMBING/KM-600MAH

• 115-120V/60/1

• 15 Amp Max Fuse/HACR Breaker Size

• 3/8” OD copper or equivalent independent potable water supply

• 3/4” F T independent water drain

SER ICE

• anels easily removed and all components

accessible for service.

• Removable/cleanable air filters.

(Air-cooled model only)

618 Hwy. 74 S., eachtree City, GA 30269 TEL 1-800-438-6087 FAX 1-800-345-1325 www.hoshizaki.com rinted in U.S.A.

KM-600MAH

22 x 273/8 x 377/16

• Air-cooled

KM-600MAH

12.0 15 A 200 lbs.

Air-Cooled

KM-600MAH

STORAGE BINS

Model Number Application Capacity ARI-Rated Capacity

B-500 500 lbs. 360 lbs.

B-700 700 lbs. 550 lbs.

B-800 800 lbs. 600 lbs.

B-900 900 lbs. 660 lbs.

B-1150 1150 lbs. N/A

B-1300 1275 lbs. N/A

B-1500 1490 lbs. N/A

B-1650 1605 lbs. N/A

FRONT VIE SIDE VIE

AIR-COOLED UNIT

ICE DROP ZONE

1/2" F T

1.2 (1/16")

Drain

3/4" F T

Drain (Dew Water)

3/8" O.D. ipe

30 (1-3/16")

3(1/8")

695 (27-3/8")

700 ("27- 9/16") Water Inlet

B-300 300 lbs. 260 lbs.
