Horticat U80PRO Manuel utilisateur

USER MANUAL

U80PRO Ultrasonic Humidification System

-1-

The Leader of Ultrasonic Misting

Technology

INTRODUCTION

Thank you for choosing the Horticat U80PRO Ultrasonic Humidifier!

This unit is designed for easily and efficiently adding humidity to any environment

that requires on demand humidity frequently.

This unit will disperse up to 80 pints of humidity per day. Depending on how tightly

sealed your environment is or how much humidity is lost or removed, this unit can

humidify up to 2000 sq.ft. of space.Additional units can be added and linked together for

larger demands. We highly suggest having our units connected to a reverse osmosis or a

water source under 200ppm.

-2-

The Leader of Ultrasonic Misting

Technology

Page Index

1Product Overview .....................................................................3

1.1 Appearance ..........................................................................................3

1.2 Product Features ..................................................................................3

1.3 Package Listing.....................................................................................5

2 Product Specifications.............................................................6

2.1 Specifications........................................................................................6

3 Installation Guideline................................................................7

3.1 Installation.............................................................................................7

3.2 Connecting the Unit ..............................................................................7

4 Getting Started..........................................................................9

4.1 Steps to Success..................................................................................9

4.2 Features................................................................................................9

4.3 Setting the Humidity Levels ……………………………………………. 10

5 Maintenance............................................................................12

5.1 Air Filter Maintenance.........................................................................12

5.2 Ultrasonic Plate Maintenance ………………………………………….. 12

6 Trouble Shooting .................................................................... 13

-3-

The Leader of Ultrasonic Misting

Technology

Product Overview

1.1 Appearance

1.2 Product Features

A Large Volume Output & Ultra-fine Mist Particle Size

Ultrasonic mist output up to 80 pints per day. Ultra-fine mist droplets of ≤5μ with high

gasification rate up to 80% to enhance humidification effectiveness.

B Convenient Autofill

Directly connects to water source and fills itself as needed with the built-in float

mechanism.

-4-

The Leader of Ultrasonic Misting

Technology

D Intelligent Auto-control

With built-in humidistat for precise control of humidity ranging from 35-85%.

E Overflow / Loss of Water Protection

In the event the float valve gets stuck open, there is an overflow drainage outlet to

protect the unit from overflowing and causing internal damage to the unit.

In the event of loss of water pressure or the float valve is stuck closed, the unit will

stop functioning to protect itself from internal overheating and damage to the ultrasonic

plate.

F Energy Saving & Ultra Quiet

Unit only uses 130 Watts while running at full output capacity. Much more quiet than

centrifuge humidifiers while producing humidity levels much faster without the mess.

G Antibacterial & Easy to clean

The ultrasonic chamber uses silver ion antibacterial technology for hygienic mist. It

is recommended to clean the unit every two months or as needed. It is very easy to open

and clean.

H Simple Installation

Easy wall-mount installation, push-fit connectors and do it yourself water line

connection valve allows for very fast and easy installation.

-5-

The Leader of Ultrasonic Misting

Technology

1.3 Package Listing

Product/Pic

QTY

Product/Pic

QTY

Product/Pic

QTY

U80PRO Unit

SET

Saddle Valve

Push-fit connector

set

1/2" to 1/4" Push-fit

connector PE shut

off valve

1/2" to 1/4" Push-fit

connector

1/2" to 3/8" Push-fit

connector

1/4”black tubing

25ft

3/8”white tubing

25ft

Expansion screws

-6-

The Leader of Ultrasonic Misting

Technology

2Product Specifications

2.1 Specifications

Input Voltage

110AC

50/60Hz

N.W

9.9 lbs

Ambient

Temperature

≤50℃

Power

130 W

G.W

14.33 lbs

Ambient

Humidity

≤85%RH

Mist Output

80 pints day

Dimension

16.5x11.75x6.25

inches

Atomizing

Media

Tap-water

Mist Particle

Dia（D50）

≤5μm

Max

Atomizing

Distance

10ft throw

Water

Temperature

50~130 °F

-7-

The Leader of Ultrasonic Misting

Technology

3Installation Guideline

3.1 Installation

Mount securely to wall or structure that can support at least 30lbs. Please use the level

ruler to position the wall mount panel on the wall, mark the holes, install the wall panel on

the wall using anchors, and then hang the machine on the wall panel as shown below:

3.2 Connecting the Unit

A. Overflow and Drain Connections

Connect the tubing for the overflow and drain outlet, do not over tighten as you can

damage the tank inside. The drain outlet should be the connection with inline open/close

valve. Be sure to insert the rubber rings (washers). Connect supplied 3/8” tubing and run

to the nearest drain, this U shaped piping assembly connection is for draining the unit to

clean and to provide over flow outlet in case of float device malfunction.

-8-

The Leader of Ultrasonic Misting

Technology

B. Connecting the Humidistat

Plug in the supplied humidistat into the rj45 port next to the water inlet on the bottom

of the unit. The humidistat is tucked into the foam in the box for shipping purposes, this

humidistat can be extended by an rj45 extension to be hung anywhere you desire for a

better relative humidity reading. The humidifier will not work if the humidistat is not

plugged in or will go to sub mode and use the master unit settings if connected wirelessly

in the room.

C. Water Input

Thread the supplied ½”threaded to ¼”push fitting adapter to the water inlet port on

the bottom of the unit. Be sure to use the supplied rubber washer and be careful not to

over tighten and damage the unit.

You may alter your layout / connections / fittings to customize to your needs. The

only required connection is the water supply in and a shut off fitting on the drain outlet.We

suggest running this unit on a RO water system and/or with the use of an inline filter and

supplied water is under 200ppm. Without any pre-filter you may get calcium and other

mineral deposits built up in the unit and surrounding area. The most common connection

is to your buildings water supply lines with the use of the included ¼” saddle valve. We

have included in the box a step by step installation sheet for the saddle valve installation,

if you don’t feel comfortable with installing it please contact a local plumber.

-9-

The Leader of Ultrasonic Misting

Technology

4Getting Started

4.1 Steps to Success

1) Be sure the drain inline valve is closed

2) Make sure sensor is plugged in via rj45 port by the water inlet on bottom side

3) Turn on your water source

4) Ensure the unit is plugged into power source

5) The unit is powered on

6) Adjust to desired humidity levels

Note: The unit will not produce ultrasonic mist until the tank has reached its required

water fill level which could take a couple of minutes.

4.2 Features

1) The humidity controller responds to environmental temperature changes in real

time.

2) The controller has a built-in light sensor, which can automatically identify the

light intensity and allows for two operating parameter settings for day and night

modes.

3) According to your different humidity needs, the humidity upper limit and humidity

over limit can be set (for humidity lag and calibration). The settings are

automatically saved.

4) Multiple humidifiers can be operated as one unit with the built in wireless signal

with master-sub mode.
