ENGLISH

This appliance is double insulated and must not be earthed.

IMPORTANT: The wires in the mains lead are coloured in accordance with the following

code:

Blue – NEUTRAL Brown – LIVE

Cord reel pedal (5) *

Push to automatically reel in supply

cord.

Controls (6)

❉

Power control

Move slide control to set power

level.

b) Bag check indicator

Turns from green to red as bag

fills. When 2/3red, bag needs

emptying.

Storing the cleaner (7) *

Use stowage clip as shown when

storing the cleaner.

Park position (8)

For temporary stowage during

cleaning.

*Feature varies according to model

Telescopic tubes (1) *

a) Twist to release lock.

Pull out to required length.

Twist to tighten.

b) Push latch forward or upwards as

applicable.

Pull out to required length.

Release latch to lock.

Hose fitting (2)

Push into hose inlet.

To release squeeze both buttons and

pull out.

Suction regulator (3)

Squeeze trigger to reduce suction.

ON/OFF pedal (4)

Push to switch on

Push again to switch off.

WARNING!

ELECTRICITY CAN BE EXTREMELY DANGEROUS.

Electrical requirements

(+) increase decrease (-)

ENGLISH

Carpet/floor nozzle (9) *

a) Carpet position - brushes in

b) Hard floor position - brushes out

c) Universal nozzle

Cleaning tools (10)

a) Crevice tool

b) Dusting brush

c) Multi-purpose nozzle

Changing the paper bag (11)

The bag check indicator will turn red

when the bag needs emptying.

For true bag check indication the power

control* must be set to maximum.

DO NOT overfill the bag.

To change the bag:

1. Remove hose.

2. Press latch and open bag door.

3. Lift out bag cassette.

4. Pull bag collar from cassette using

finger grips. The bag will self seal.

5. Slide collar of new bag into cassette

and lower cassette into bag housing.

6. Close bag door and refit hose.

IMPORTANT: Switch cleaner off

and remove plug from electricity

supply before changing paper

bag or removing any filters.

DO NOT use cleaner without bag in

place.

Hoover recommend that new filters

are fitted after five full bags of dirt

have been removed.

Changing the secondary

filter (12)

With paper bag removed lift filter from

bag housing.

Fit new filter and replace paper bag.

a) *Secondary filter

b) *‘S’ class filter cassette

*Active carbon filter

Changing the exhaust filter

(13)

1. Lift off filter cover.

2. Remove filter.

Fit new filter and replace cover.

*Exhaust filter

ENGLISH

Calling for service

A charge will be made if the cleaner is found to be in working order or has not

been assembled in accordance with these instructions or has been used incorrectly.

Before calling a HOOVER Service Engineer run through the following checklist:

1. Is there a working electricity supply to the cleaner?

Check with another appliance.

2. Is the paper bag full?

3. Is the hose blocked?

4. Are the filters blocked?

If there is any doubt call your local Hoover Service Office for advice, they may be

able to assist you over the telephone.
