USER MANUAL
HOMEVIZ OB10 Wireless Security Camera
v1.0
What’s in the Box
Product Overview
Specifications
Getting Started
Contact Us
2
3
4
4
18
CONTENTS
1
WHAT’S IN THE BOX
OB10 Wireless
Security Camera × 1
Waterproof Cap × 1
Antenna × 19.8ft Power Adapter (12V/1A)
Screw × 4 Anchor × 4
Quick Start Guide × 1
V1.0
Quick Start Guide
HOMEVIZOB10 Wireless Security Camera
2
PRODUCT OVERVIEW
Reset
MIC
Speaker
microSD Card Slot
Reset
Power Jack
LAN
Lens
Photosensitive Sensor
Antenna
IR Lights
White LED Lights
IR Lights
White LED Lights
3
SPECIFICATIONS
Main Chip
Sensor
Viewing Angle
Camera
Alarm Trigger
Storage
Waterproof Level
Network
XM530
Image output 2304 × 1296 (2K)
90° diagonally, 69° horizontally, 50° vertically
4 LED lights, 4 infrared lights
Custom motion detection, human detection, area
detection, etc.
Supports up to 128GB microSD card
IP66
2.4GHz band
GETTING STARTED
1. Downloading and Installing the App
Option 1: Scan the QR code below:
HOMEVIZHOMEVIZ
Option 2: Search for the "HOMEVIZ" app on the App Store or Google Play.
4
2. Connecting to Power
Insert a microSD card (not included) into the microSD slot. Then connect the
camera to a wall outlet with the included power adapter.
Reset
Tip: To initialize the device, press and hold the reset button for about 10 seconds
until you hear a prompt sound.
3. Setting up the Camera
• Wireless Network Configuration
Step 1: Open the "HOMEVIZ" app and tap "Login". (Please register first if you don't
have an account.)
Step 2: Tap "+".
Device List
Click to add device
Device AlbumAlarm My
Other Login Methods
Login
Register Forget Password
Please Input UserName
Please Input Password
Step 1 Step 2
5
Step 3: Tap "Wireless camera".
Step 4: Tap "OB10 Security Camera".
Step 5: Tap "Fast network configuration".
Add camera
Network video recorder
Add network video recorder
Wireless camera
Add WIFI wireless webcan
Wireless camera
CB10
Security Camera
Wireless camera
Fast network configuration
Pair via WiFi
Share & add
Add with sharing code
Step 5Step 3 Step 4
6
Enter the network name and password of your current Wi-Fi network and Tap
"Next".
Note: This device currently only supports 2.4GHz Wi-Fi. If you are using 5GHz Wi-Fi,
please confirm that your Wi-Fi is compatible with 2.4GHz.
Step 2 Connect to the network
Next
saina-210
Please enter WIFI password
Only search devices in the same LAN.
Try to keep the device,mobile phone and router
close enough,long press the SET button until the
indicator light flashes quickly (for some products,
a thimble shall be gently inserted into the
configuration hole)
Step 2 Connect to the network
Next
saina-210
Please enter WIFIpassword
Only search devices in the same LAN.
Try to keep the device,mobile phone and router
close enough,long press the SET button until the
indicator light flashes quickly (for some products,
a thimble shall be gently inserted into the
configuration hole)
Please wait ...
7
• Alarm Push
To receive alerts and push notifications：
Step 1: Tap .
Step 2: Tap [Intelligent Alarm] to enter the alarm setting interface.
Step 3: Enable"Humanoid Detection Switch", "APP Push", and "Allow Notifications".
Customize alarm settings according to your needs.
Step 3
Intelligent alert Save
Humanoid Detection Switch
Turn the figure detection function on or off
Show movement traces
Alam Lingage
Reginoal Settings
Displays Traces
Turn alarm recording on or off
Alarm Record
Turn alarm snapshot on or off
Alarm Snapshot
Turn App push on or off
APP Push
Turn push on or off
Allow Notifications
Cordon Alert Area
Alarm Sound
Step 2
b11b75a5b5cbebed
Device Name
OSD Configuration
Video Management
Intelligent Alarm
Time Synchronous
2020-12-29 09:38:19
East8.0 District
Click here to sync device time to your phone
Advanced Setting
Firmware Upgrade
Deivice Reboot
About
It is already the latest
version
Device List
b11b75a5b5cbebed
Device Alarm Album My
Online
Step 1
8
Step 1
Device List
b11b75a5b5cbebed
Device Alarm Album My
Online
• View Video Playback
To playback video footage, ensure that an SD card (Max. 128GB, sold separately) is
inserted into the camera.
Step 1: Tap the device.
Step 2: Tap [PlayBack].
Talk: Tap and hold to talk and listen
Sound: Tap to unmute or mute
Record: Tap to start/stop manual recording
Snap: Tap to take a snapshot
Setting: Tap to go to Settings
Step 3
Remote video
1X
Snap
Record Play Multiple Voice
09:14:49
09:12:55
2020-12-29 15:45:04
2020-12-29
:00 05:00:00 06:00:00 07:00:00 08:00:00 09:00:00 10:00:00 11:00:00 12:00
Meaning of Colors:
Normal Video: Normal Video
Alarm Record: Human Detection Video
Detect Recording: Motion Detection Video
Step 2
b11b75a5b5cbebed
Sound
Talk
1CH
PlayBack Vigillance
Record Snap Setting
Video Open Successfuly
0.0KB/S
HD
HD
9CH4CH
Channel Management
9
