Homelite ELECTRIC GENERATOR Manuel utilisateur

IMPORTANT: READ AND UNDERSTAND ALL OPERATING INSTRUCTIONS

AND WARNING LABELS THOROUGHLY BEFORE STARTING THIS GENERATOR.

3500 WATT ELECTRIC GENERATOR

OWNERS MANUAL

REV. A

This product is not to be returned to retailer. For service, parts and warranty information, call toll free 1-866-260-8280

Should you experience a problem or need to return your generator for repair, please call our

customer service department TOLL FREE at 1-866-260-8280 between the hours of 7am and

5pm Monday thru Friday PST and Saturday 8am to 4pm PST. During DST hours change to MT.

You will be instructed how to proceed.

A COPY OF THE SALES RECEIPT IS REQUIRED.

Congratulations on your purchase of a Homelite

Generator

It is warranted to be free of manufacturing defects in the material of workmanship for a period

of 1 year form the date of purchase. During the warranty period Homelite will at its option,

repair, provide replacement parts or replace your Homelite generator at no charge. This

warranty does not cover normal wear items or damage caused by neglect or misuse of the

product.

Engine Warranty – 1 year

Electrical component Warranty - 1 year

Warranty is void if:

Generator is dent or broken due to abuse or accidents

Proper maintenence is not performed on the engine as outlined in the owners

manual.

Generator shows signs of erosion, corrosion, or signs of normal wear and tear.

If the product is used as rental equipment.

Homelite or its aliates is not liable for any damage claim or liability claim person or otherwise

resulting from the operation of this product in any way.

Generator Warranty

SAFETY POINTS.................................. 4

PARTS & SUBASSEMBLIES ................ 5

CHECk UPS BEFORE OPERATION

OIL LEvEL ....................................... 6

FUEL LEvEL .................................... 6

AIR FILTER ...................................... 6

STARTING THE GENERATOR.............. 7

USAGE OF THE GENERATOR.............. 8

WATTAGE REFERENCE GUIDE ........... 9

STOPPING THE GENERATOR............. 10

MAINTENANCE

OIL CHANGE ................................... 11

SPARk PLUG CHECk ...................... 11

CLEANING OF AIR FILTER.............. 12

FUEL CUP CLEANING ..................... 12

MAINTENANCE SCHEDULE ............. 13

TROUBLE SHOOTING ....................... 14

TECHNICAL DATA ............................ 15

CIRCUIT DRAWING ........................... 16

Table of Contents

! WARNING

SAFETY POINTS

CARBON MONOXIDE HAZARD

Fumes can be harmful or fatal.

You CAN NOT see or smell this gas.

Do not operate generators indoors

Do not operate generators in garage or carport

Do not operate generators near open doors or windows

To avoid Electrical shock, do not operate in a wet environment

Keep amables at least 4 feet away

Do not smoke while adding fuel

Do not overll gas tank causing fuel to spill

Turn engine off before refueling

! WARNING

To avoid Electrical shock, make sure generator is grounded

! WARNING

Parts and Subassemblies

Oil dip stick plug

On Off Switch

Circuit Breaker

Voltage switch

AC Outlet Terminals

Air Filter box

Starter pull cord

Fuel Valve

Choke Lever

Carburetor

Carburetor drain

screw

Front View

Side View

Rear View

Gas cap

Fuel level gauge

Choke lever

Oil drain plug screw

GroundTerminal

Engine Label

3. Check Air Filter: Remove air lter foam elements by unlatching clips

on top and bottom of air lter housing. Check the foam

lter elements making sure they are clean and

intact. If air lter elements need cleaning,

follow the instructions on page 11.

Before Each Operation

Caution: Checking and lling oil and gas must

be carried out on level ground with the engine

turned off

1. Check oil level: If oil is low on dip stick, add oil up to the

edge of the ll hole. After checking oil, make

sure oil dip stick cap has been re-installed and

tightened. Recommended Oil: SAE10W-30

2. Check Fuel level: Check Gasoline level by looking at sight

gauge located on top of tank. If gasoline

is low, remove gas cap and add gasoline

up to the bottom of the ller neck.

WARNING: DO NOT OVERFILL GAS TANK ALLOWING

GASOLINE TO SPILL

Dip Stick

Gasoline sight gauge Gas Cap

Air lter cover

Air lter clips

Air Filter Foam Air Filter Elements

Starting the Generator

1. Remove (unplug) all loads from the AC outlet Terminals.

2. Turn the AC circuit breaker to the “OFF”

position

3. Turn the fuel valve to the “ON” Position.

4. Turn the Choke lever to the “CLOSED” position.

5. Turn the engine switch to “ON”.

6. Gently pull the starting pull handle until some resistance

is felt and then pull it abruptly.

7. Once engine has warmed up, turn the choke lever to the

“OPEN” position.

Fuel Valve

AC Circuit Breaker AC Outlet Terminals

On/Off Switch

Start Pull Handle

Choke Lever

CLOSED

OFF

Choke

OPEN

Usage of Generator

To keep generator in optimal condition mechanically and electrically, the following points shall be

observed

1. The total power of electric load shall not exceed the rated power of the generator

2. If generator is to be wired for house power supply, wiring shall be carried out by an electrician.

Check to make sure all wiring is correct. Wrong wiring will cause damage to the generator and

even a re.

3. Ground generator before use.

USE OFAC

1: Ground generator by attaching ground wire to ground terminal. The other end of the ground

wire should be attached to a grounded object or attached to a grounded metal spike.

2: Start the engine using “Starting Generator” procedure on previous page .

3. Connect needed devices to the AC Outlet Terminals.

4. Turn voltage switch to 120V or 240V depending on needed voltage.

5. Turn AC Circuit breaker to “ON” position.

Note: Overcurrent will automatically turn off the AC breaker. When breaker is tripped to

“OFF” position, reduce load and re-start a few minutes latter.

Voltage switch

AC Circuit Breaker AC Outlet Terminals

Ground Terminal

Wattage Reference Guide

HOME

ESSENTIALS:

Light Bulb - 60 Watt 60 0

Light Bulb - 70 Watt 75 0

Refriderator / Freezer 700 2200

Sump Pump - 1/3 HP 800 1300

Sump Pump - 1/2 HP 1050 2200

Water Well Pump - 1/3 HP 1000 2000

Electric Water Heater 4000 0

HEATING/COOLING

Space heater 1800 0

Humidier - 13 gallon 175 0

Furnace Fan - 1/2 HP 800 2350

Furnace Fan - 1/3 HP 700 1400

Window AC 10,000 BTU 1200 1800

Window AC 12,000 BTU 3250 3950

Central AC 10.000 BTU 1500 3000

Central AC 24,000 BTU 3800 4950

Central AC 40,000 BTU 6000 6700

Heat Pump 4700 4500

LAUNDRY ROOM

Iron 1200 0

Washing Machine 1150 2250

WORK

DIY/JOBSITE:

Quartz Hal. Work Light 300W 300 0

Quartz Hal. Work Light 500W 500 0

Quartz Hal. Work Light 1000W 1000 0

Airless Sprayer 1/3 HP 600 1200

Reciprocating Saw 960 0

Electric Drill 3/8”, 4.0 amp 440 600

Electric Drill 1/2” 5.4 amp 600 900

Hammer Drill 1000 3000

Circular Saw 7 1/4” 1400 2300

Miter Saw 10” 1800 1800

PLAY

TAILGATING/CAMPING

Electric Grill 1650 0

AM/FM Radio 100 0

CD/DVD Player 100 0

Box Fan 20” 200 0

Clothes Dryer - Electric 5400 1350

Clothes Dryer - Gas 700 1800

KITCHEN

Microwave Oven 625W 625 0

Microwave Oven 1000W 1000 0

Coffee Maker 1000 0

Electric Stove 8” Element 2100 0

Dishwasher Hot/Dry 1500 1500

Food Processer 400 0

Toaster Oven 1200 0

Toaster 850 0

Electric Can Opener 168 0

FAMILY ROOM

VCR 100 0

Stereo Receiver 450 0

Color TV 27” 500 0

X-box, Game Qube., Play Station 40 0

OTHER

Security System 500 0

1/2HP Garage Door Opener 875 2350

Curling Iron 1500 0

Hair Dryer 1250W 1250 0

Planer/Jointer 6” 1800 1800

Table Saw/Radial Arm 10” 2000 2000

Belt Sander 1200 2400

Air Compressor 1/4 HP 975 1600

Air Compressor 1 HP 1600 4500

OFFICE EQUIPMENT

Personal Comp. 17” Monitor 800 0

Fax Machine 65 0

Laser Printer 950 0

Ink Jet Printer 80 0

Copy Machine 1800 0

Color TV 13” 150 0

Outdoor light String 250 0

Cell Phone Battery Charger 25 0

Inator Pump 50 150

NOTE: Wattages listed are only approximates. Check your electrical device for actual wattage.

TOOL OR APPLIANCE RUNNING

(RATED)

WATTS

ADDITIONAL

STARTING

WATTS

TOOL OR APPLIANCE RUNNING

(RATED)

WATTS

ADDITIONAL

STARTING

WATTS

Stopping the Generator

1.. Turn the AC circuit breaker to the “OFF”

position

5. Turn the generator switch to “OFF”.

5. Remove Loads from outlet terminals.

3. Turn the fuel valve to the “OFF” Position.

NOTE: When an emergency stop of the engine is needed, turn the generator switch to “OFF”

position

AC Circuit Breaker AC Outlet Terminals

On/Off Switch

OFF

Fuel Valve

AC Outlet Terminals
