Home Accents Holiday TG90M3P07D09 Manuel utilisateur

Assembly

Pre-Assembly

Package Contents

Part Description Quantity

A Tree top, tag 3 1

B Tree center, tag 2 1

C Tree bottom, tag 1 1

D Tree stand 1

Christmas Tree

Model: TG90M3P07D09

Sku # 1002 362 533

Step 1. Pull apart the legs of the stand so that they are

snapped into an x-shape, place the tree stand on a

level surface.

To close the stand, press the metal button and fold the legs

together.

Assembling the tree

This tree assmebles with Quick Set® technology

---Set up and light up your tree in less than 10 minutes!

Step 1. Remove the protective caps from the tree bottom

and insert the pole into the tree stand.

Step 2. Continue by inserting the upper tree section(s) to

the lower section(s) until inserting the tree top.

Step 3. Shape the branches to your preference by working

from the bottom to the top. When adjusting

branches, ensure that all wires are free of branch

hinges.

Step 4. Insert the adaptor into the wall outlet. All your lights

should now be lit.

Step 5. When finished shaping the branches, slightly

upsweep all branch tips for a uniform look.

Assembling the tree stand

Click

Safety Information

IMPORTANT SAFETY

INSTRUCTIONS

a. READ AND FOLLOW ALL

SAFETY INSTRUCTIONS.

When using electrical products, basic precautions should

always be followed, including the following:

b. Do not use seasonal products outdoors unless marked

suitable for indoor and outdoor use. When products are

used in outdoor applications, connect the product to a

Ground Fault Circuit Interrupting (GFCI) outlet. If one is

not provided, contact a qualified electrician for proper

installation.

c. This seasonal product is not intended for permanent

installation or use.

d. Do not mount or place the product near gas or electric

heaters, fireplaces, candles, or other similar sources of

heat.

e. Do not secure the wiring of the product with staples or

nails, or place on sharp hooks or nails.

f. Do not let lamps rest on the supply cord or on any wire.

g. Unplug the product when leaving the house, when

retiring for the night, or if left unattended.

h. This is an electric product and not a toy! To avoid risk of

fire, burns, personal injury and electric shock it should not

be played with or placed where small children can reach it.

i. Do not use this product for other than its intended use.

j. Do not hang ornaments or other objects from cord, wire,

or light string.

k. Do not close doors or windows on the product or exten

sions cords as this may damage the wire insulation.

l. Do not cover the product with cloth, paper, or any materi

al that is not a part of the product when in use.

m. This product is equipped with push-in type lamps. Do not

twist lamps.

n. Read and follow all instructions that are on the product

or provide with the product.

o. SAVE THESE INSTRUCTIONS

Step 1.

Grasp the power adapter or power cord plug, and than

unplug from the power outlet.Do not pull the power cord.

LAMP REPLACEMENT

Step 2.

Lift up lamp lock tab, then pull the

lamp and plastic lamp base straight

out of the lamp-holder.

Step 3.

Replace with a new spare lamp

provided with this product.

( Reference figure only)

USER SERVICING INSTRUCTIONS

NOTE: If some bulbs do not light or flicker, search for any

loose plugs and/or broken, loose, or missing bulbs. Replace

bulbs promptly with the replacement bulbs provided in

order to maintain the performance and life expectancy of

your tree.

Step 1. Connect the light strings of the tree together and

plug the power cord into a wall outlet.

Step 2. If the tree comes with a foot pedal, step on the

On/Off button.

Operation

Turning on the tree

This tree package includes hinge pins, washers and bulbs

for any replacement or repair that you need to perform on

your tree. If extra parts are needed, contact the Customer

Service Team at 1-877-527-0313 between the hours of 8 am

and 5 pm EST, Monday through Friday.

Repairing Loose Hinges

Step 1. Place the branch into the slot of the bracket

Step 2. Insert a new hinge pin through the holes of the

bracket and secure with a washer.

Maintenance

Spare parts

1. Before using or reusing, inspect product carefully. Discard

any products that have cut, damaged or frayed wire

insulation or cords, cracks in the lampholders or enclo

sures, loose connections, or exposed copper wire.

2. Before disassembling the tree, unplug the tree and

remove all ornaments and decorations.

3. Gently lift the tree top straight up to remove from the

center section and fold all branches towards the pole.

4. Repeat this step for the center and bottom tree sections.

5. When storing the product, carefully remove the product

from wherever it is placed, including tree, branches, or

bushes, to avoid any undue strain or stress on the

product conductors, connections, and wires. Cover the

Use and Care Instructions

protective cap on the poles to

avoid damaging the internal parts.

6. When not in use, store neatly in a

cool, dry location protected from

sunlight.

Christmas Tree

Model: TG90M3P07D09

Sku # 1002 362 533

Section 3

Section 2

Section 1

Do Not Tamper

Internal Parts

Open the

protective

cover

Do Not Tamper

Internal Parts

Open the

protective

cover

100S

50S

100S

50S

100S

50S

100S

Control box

Adaptor

To Be Plugged

Into Wall

Outlet

Foot Pedal

on/off Switch

CAUTION: Use only power daptor that was

provided with this product. Using a different power

adaptor will damage the lights and cause fire, electrical

shock hazard.

Troubleshooting

Problem Solution

The tree does

not light

Ensure that all tree sections are

plugged into each other and that the

tree is plugged into the wall. If your

tree came with a foot pedal, step on

the On/Off button.

Check for loose, broken, or missing

bulbs and replace as needed with the

replacement bulbs provided

Press the selector button on the “Dual Color Light Control

ler” or “Remote Controller” to select among:

(1) CLEAR - MULTI: FADING (2) CLEAR: FADING

(3) CLEAR - MULTI: ALTERNATING (4) CLEAR: STEADY

(5) CLEAR - MULTI: SLOW FADING (6) MULTI: STEADY

(7) MULTI: FADING (8) COMBINATION

HOW TO USE THE DUAL COLOR LIGHT CONTROLLER

AND REMOTE CONTROL:

User servicing instructions

Light Controller

Selector

Button

Remote

Controller

Insulation

Tab Battery

CR2032

Cover

HOW TO USE THE REMOTE CONTROLLER :

The remote control is for the wired controller only:

(1) REMOVE THE INSULATION TAB OF THE REMOTE

CONTROLLER.

(2) PRESS THE BUTTON TO SELECT DIFFERENT

FUNCTIONS, REFER TO “HOW TO USE THE DUAL

COLOR LIGHT CONTROLLER”.

(3) TO REPLACE THE BATTERY, OPEN THE BATTERY

COMPARTMENT WITH A COIN. REPLACE WITH

A CR2032 BATTERY.

(4) DISPOSE USED BATTERY PROPERLY. OBSERVE LOCAL

REGULATIONS REGARDING DISPOSAL

OF HAZARDOUS WASTE.

(5) ENSURE THE BATTERIES ARE INSTALLED CORRECTLY

WITH REGARD TO POLARITY (+ AND -).
