Home Accents Holiday TG90M2V39D02 Manuel utilisateur

Safety Information

IMPORTANT SAFETY

INSTRUCTIONS

a. READ AND FOLLOW ALL

SAFETY INSTRUCTIONS.

When using electrical products, basic precautions should

always be followed, including the following:

b. Do not use seasonal products outdoors unless marked

suitable for indoor and outdoor use. When products are

used in outdoor applications, connect the product to a

Ground Fault Circuit Interrupting (GFCI) outlet. If one is

not provided, contact a qualified electrician for proper

installation.

c. This seasonal product is not intended for permanent

installation or use.

d. Do not mount or place the product near gas or electric

heaters, fireplaces, candles, or other similar sources of

heat.

e. Do not secure the wiring of the product with staples or

nails, or place on sharp hooks or nails.

f. Do not let lamps rest on the supply cord or on any wire.

g. Unplug the product when leaving the house, when

retiring for the night, or if left unattended.

h. This is an electric product and not a toy! To avoid risk of

fire, burns, personal injury and electric shock it should not

be played with or placed where small children can reach it.

i. Do not use this product for other than its intended use.

j. Do not hang ornaments or other objects from cord, wire,

or light string.

k. Do not close doors or windows on the product or exten

sions cords as this may damage the wire insulation.

l. Do not cover the product with cloth, paper, or any materi

al that is not a part of the product when in use.

m. This product is equipped with push-in type lamps. Do not

twist lamps.

n. Read and follow all instructions that are on the product

or provide with the product.

o. SAVE THESE INSTRUCTIONS

Christmas Tree

Model: TG90M2V39D02

Sku # 760 411

Step 1.

Grasp the power adapter or power cord plug, and than

unplug from the power outlet.Do not pull the power cord.

LAMP REPLACEMENT

Step 2.

Lift up lamp lock tab, then pull the

lamp and plastic lamp base straight

out of the lamp-holder.

Step 3.

Replace with a new spare lamp

provided with this product.

( Reference figure only)

USER SERVICING INSTRUCTIONS Section 3

Section 4

Section 2

Section 1

Do Not Tamper

Internal Parts

Open the

protective

cover

100S

50S

Do Not Tamper

Internal Parts

Open the

protective

cover

Control box

Adaptor

To Be Plugged

Into Wall

Outlet

Step 1

. Choose a location near a wall outlet.

Step 2

. Unfold the legs and lay the stand in a flat area. Then

slide the locking disc downward and snap into place.

Step 3

. When inserting the bottom section of the tree into

the assembled stand, thread the eyebolt into the

stand and tighten until the pole is firmly secured.

Assembling the tree

This tree assmebles with Quick Set® technology

---Set up and light up your tree in less than 10 minutes!

Step 1

. Remove the protective caps from the tree bottom

and insert the pole into the tree stand.

Step 2

. Continue by inserting the upper tree section(s) to

the lower section(s) until inserting the tree top.

Step 3

. Shape the branches to your preference by working

from the bottom to the top. When adjusting branches,

ensure that all wires are free of branch hinges.

Step 4

. Insert the adaptor into the wall outlet. All your lights

should now be lit.

Step 5

. When finished shaping the branches, slightly

upsweep all branch tips for a uniform look.

Assembly

Assembling the tree stand

Eye Bolt

Pre-Assembly

Package Contents

Part Description Quantity

A Tree top, tag 4 1

B Tree center, tag 3 1

C Tree bottom, tag 2 1

D Tree bottom, tag 1 1

E Tree stand 1

Press the selector button on the “Dual Color Light Control

ler” or “Remote Controller” to select among:

(1) CLEAR - MULTI: FADING (2) CLEAR: FADING

(3) CLEAR - MULTI: ALTERNATING (4) CLEAR: STEADY

(5) CLEAR - MULTI: SLOW FADING (6) MULTI: STEADY

(7) MULTI: FADING (8) COMBINATION

Light Controller

Selector

Button

Remote

Controller

Christmas Tree

Model: TG90M2V39D02

Sku # 760 411

Troubleshooting

Problem Solution

The tree does

not light

Ensure that all tree sections are

plugged into each other and that the

tree is plugged into the wall. If your

tree came with a foot pedal, step on

the On/Off button.

Check for loose, broken, or missing

bulbs and replace as needed with the

replacement bulbs provided

Insulation

Tab Battery

CR2032

Cover

HOW TO USE THE REMOTE CONTROLLER :

The remote control is for the wired controller only:

(1) REMOVE THE INSULATION TAB OF THE REMOTE

CONTROLLER.

(2) PRESS THE BUTTON TO SELECT DIFFERENT

FUNCTIONS, REFER TO “HOW TO USE THE DUAL

COLOR LIGHT CONTROLLER”.

(3) TO REPLACE THE BATTERY, OPEN THE BATTERY

COMPARTMENT WITH A COIN. REPLACE WITH

A CR2032 BATTERY.

(4) DISPOSE USED BATTERY PROPERLY. OBSERVE LOCAL

REGULATIONS REGARDING DISPOSAL

OF HAZARDOUS WASTE.

(5) ENSURE THE BATTERIES ARE INSTALLED CORRECTLY

WITH REGARD TO POLARITY (+ AND -).

CAUTION:

Use only power adaptor that was provided with this product.

Using a different power adaptor will damage the lights and

cause fire, electrical shock hazard.

IMPORTANT SAFETY

INSTRUCTIONS

1. WARNING: SMALL PARTS, KEEP AWAY FROM CHILDREN.

2. Do not expose light set to moisture.

3. Remove batteries when not used for an extended period

of time, or when depleted.

4. Dispose of used batteries properly by following directions

on batteries.

5. Use only CR2032 batteries for the remote controller.

6. Clean the battery contacts prior to battery installation.

7. DO NOT DISPOSE OF BATTERIES IN FIRE. BATTERIES MAY

EXPLODE OR LEAK.

NOTE: If some bulbs do not light or flicker, search for any

loose plugs and/or broken, loose, or missing bulbs. Replace

bulbs promptly with the replacement bulbs provided in

order to maintain the performance and life expectancy of

your tree.

Step 1. Connect the light strings of the tree together and

plug the power cord into a wall outlet.

Step 2. If the tree comes with a foot pedal, step on the

On/Off button.

Operation

Turning on the tree

This tree package includes hinge pins, washers and bulbs

for any replacement or repair that you need to perform on

your tree. If extra parts are needed, contact the Customer

Service Team at 1-877-527-0313 between the hours of 8 am

and 5 pm EST, Monday through Friday.

Repairing Loose Hinges

Step 1. Place the branch into the slot of the bracket

Step 2. Insert a new hinge pin through the holes of the

bracket and secure with a washer.

Maintenance

Spare parts

1. Before using or reusing, inspect product carefully. Discard

any products that have cut, damaged or frayed wire

insulation or cords, cracks in the lampholders or enclo

sures, loose connections, or exposed copper wire.

2. Before disassembling the tree, unplug the tree and

remove all ornaments and decorations.

3. Gently lift the tree top straight up to remove from the

center section and fold all branches towards the pole.

4. Repeat this step for the center and bottom tree sections.

5. When storing the product, carefully remove the product

from wherever it is placed, including

tree, branches, or bushes, to avoid

any undue strain or stress on the

product conductors, connections,

and wires. Cover the protective

cap on the poles to avoid damaging the internal parts.

6. When not in use, store neatly in a cool, dry location

protected from sunlight.

Use and Care Instructions

HOW TO USE THE DUAL COLOR LIGHT CONTROLLER

AND REMOTE CONTROL:

User servicing instructions
