Home Accents Holiday HMS-9CL Manuel utilisateur

Christmas Tree

Model: HMS-9CL

Sku # 658 454

Safety Information

IMPORTANT SAFETY

INSTRUCTIONS

a. READ AND FOLLOW ALL

SAFETY INSTRUCTIONS.

b.This product is for indoor use only.

c. This seasonal product is not intended for permanent

installation or use.

d. Do not mount or place the product near gas or electric

heaters, fireplaces, candles, or other similar sources of heat.

e. Do not secure the wiring of the product with staples or

nails, or place on sharp hooks or nails.

f. Do not let lamps rest on the supply cord or on any wire.

g. Unplug the product when leaving the house, when

retiring for the night, or if left unattended.

h.This is an electric product and not a toy! To avoid risk of

fire, burns, personal injury and electric shock it should not

be played with or placed where small children can reach it.

i. Do not use this product for other than its intended use.

j. Do not hang ornaments or other objects from cord, wire,

or light string.

k. Do not close doors or windows on the product or exten-

sions cords as this may damage the wire insulation.

l. Do not cover the product with cloth, paper, or any material

that is not a part of the product when in use.

m.Read and follow all instructions that are on the product or

provided with the product.

n. SAVE THESE INSTRUCTIONS

Assembling the tree stand

Assembly

When using electrical products, basic precautions should

always be followed, including the following:

Step 2.When inserting the bottom section of the tree into

the assembled stand, insert and turn the eyebolts into

the stand and tighten until the tree pole is firmly

secured.

Step 1.Pull apart the legs of the stand so that they are

snapped into an x-shape, place the tree stand on a

level surface.

Step 3.To close the stand, remove the eyebolts, press the

metal button and fold the legs together.

Step 1. Remove the protective caps from the tree bottom (E)

and insert the pole into the tree stand (F).

Step 2. Remove the protective caps from the tree center 3

(D) and insert the pole into the tree bottom (E) .

Step 3. Remove the protective caps from the tree center 2

Step 4. Remove the protective caps from the tree center 1 (B)

and insert the pole into the tree center 2 (C) .

Assembling the tree

Eye Bolt

Click

Eye Bolt

S50 S50

Section 5

Section 4

Section 3

Section 2

Section 1

Clear

Both

Multi

Off

Both

Off

Clear

Off

S100

S50

S100

S50

S100

S50

S100

S50

S100

S50

S100

S50

S100 S100

S100

Light Strings

Extension Cord

Male Electrical Plug

Extension Cord Socket

for clear lights

Extension Cord Socket

for multi lights

Package Contents

Pre-Assembly

Part Description Quantity

F Tree stand 1

A Tree top, tag 5 1

B Tree center, tag 4 1

C Tree center, tag 3 1

D Tree center, tag 2 1

E Tree bottom, tag 1 1

Remote control

Insert Red Label

Plugs Into Red

Labeled Extension Cord

Insert yellow Label

Plugs Into Yellow

Labeled Extension Cord

Christmas Tree

Model: HMS-9CL

Sku # 658 454

Operation

Turning on the tree

Maintenance

Care and Cleaning

Troubleshooting

Spare parts

Repairing Loose Hinges

Problem Solution

The tree does

not light

Ensure that all tree sections are plugged

into each other and that the tree is

plugged into the wall. If your tree came

with a foot pedal, step on the

On/Off button.

Check for blown fuses at the power cord

plug. Replace as needed with the

replacement fuses provided.

Check for loose, broken, or missing bulbs

and replace as needed with the

replacement bulbs provided

Step 5. Insert the tree top (A) into the tree center 1 (B).

Step 6. Shape the branches to your preference by working

from the bottom to the top.When adjusting

branches, ensure that all wires are free of branch

hinges.

Step 7. Insert the control box plug into the wall outlet. All

your lights should now be lit.

Step 8.When finished shaping the branches, slightly

upsweep all branch tips for a uniform look.

NOTE: If some bulbs do not light or flicker, search for any

loose plugs and/or broken, loose, or missing bulbs. Replace

bulbs promptly with the replacement bulbs provided in

order to maintain the performance and life expectancy of

your tree.

Step 1.Connect the light strings of the tree together and

plug the power cord into a wall outlet.

Step 2.If the tree comes with a foot pedal, step on the

On/Off button.

This tree package includes hinge pins, washers, bulbs and

fuses for any replacement or repair that you need to

perform on your tree. If extra parts are needed, contact the

Customer Service Team at 1-877-527-0313 between the

hours of 8 am and 5 pm EST, Monday through Friday.

Step 1.Remove all ornaments and decorations.

Step 2.Unplug the cord from the wall and then unplug each

section of the tree.

Step 3.Gently lift the tree top straight up to remove from the

center sections and fold all branches towards the

pole.

Step 4.Repeat this step for the bottom tree section.

Step 5.Carefully place all tree sections into a shipping box

and tape it shut.

Step 6.Store your tree in a cool, dry place away from sunlight.

Step 1.Place the branch into the slot of the bracket.

Step 2.Insert a new hinge pin through the holes of the

bracket and secure with a washer.

WARNING - Risk of fire:This product employs overload

protection (fuse lamp) in each series light circuit to provide

overload protection in addition to the fuse(s) located in the

plug. Do not replace the fuse lamp contained in this set with

any other type of lamp, use only spare fuse lamps provided

with this product. In case of a burnt out FUSED lamp, the

entire series of 50 lamps will be out.To replace the fused

lamp:

1. Grasp the plug and remove from the receptacle or other

outlet device. Do not unplug by

pulling the cord.

2. Locate the fused lamp with gray

color lamp holder. Pull the burnt

fused lamp and plastic lamp base

straight out of the lamp holder.

3. Replace with a spare fused lamp.The fused lamp can be

distinguished by a gray lamp base and an additional clear

plastic cover.

4. Plug in the lights again.

User servicing instructions

Fused Lamp Replacement
