Home Accents Holiday HMS-15CL Manuel utilisateur

Christmas Tree

Model: HMS-15CL

Sku # 658 450

Package Contents

Safety Information

IMPORTANT SAFETY

INSTRUCTIONS

a. READ AND FOLLOW ALL

SAFETY INSTRUCTIONS.

b.This product is for indoor use only.

c. This seasonal product is not intended for permanent

installation or use.

d. Do not mount or place the product near gas or electric

heaters, fireplaces, candles, or other similar sources of heat.

e. Do not secure the wiring of the product with staples or

nails, or place on sharp hooks or nails.

f. Do not let lamps rest on the supply cord or on any wire.

g. Unplug the product when leaving the house, when

retiring for the night, or if left unattended.

h.This is an electric product and not a toy! To avoid risk of

fire, burns, personal injury and electric shock it should not

be played with or placed where small children can reach it.

i. Do not use this product for other than its intended use.

j. Do not hang ornaments or other objects from cord, wire,

or light string.

k. Do not close doors or windows on the product or exten-

sions cords as this may damage the wire insulation.

l. Do not cover the product with cloth, paper, or any material

that is not a part of the product when in use.

m.Read and follow all instructions that are on the product or

provided with the product.

n. SAVE THESE INSTRUCTIONS

Pre-Assembly

Assembling the tree stand

Assembly

When using electrical products, basic precautions should

always be followed, including the following:

Step 1.Pull apart the legs of the stand so that they are

snapped into an x-shape, place the tree stand on a

level surface.

Step 2.When inserting the bottom section of the tree into

the assembled stand, insert and turn the eyebolts into

the stand and tighten until the tree pole is firmly

secured.

Step 3.To close the stand, remove the eyebolts, press the

metal button and fold the legs together.

Step 1.Remove the protective cap from the tree bottom (K)

and insert the pole into the tree stand (L).

Step 2.Continue by inserting the upper tree section(s) to the

lower section(s) until inserting the tree top.

Assembling the tree

Part Description Quantity

I Tree section, tag 3 1

A Tree top, tag 11 1

D Tree section, tag 8 1

C Tree section, tag 9 1

B Tree section, tag 10 1

E Tree section, tag 7 1

H Tree section, tag 4 1

G Tree section, tag 5 1

F Tree section, tag 6 1

J Tree section, tag 2 1

K Tree bottom, tag 1 1

L Tree stand 1

Section 8

Section 9

Section 10

Section 11

Section 7

Section 6

Section 4

Section 5

Section 3

Section 2

Section 1

S100

S50

S100

Extension Cord to Wall Outlet

Electrical Rating for the tree: 5.1A 120V 60Hz

Extension Cord to Wall Outlet

Electrical Rating for the tree: 2.38A 120V 60Hz

Extension Cord to Wall Outlet

Electrical Rating for the tree: 4.42A 120V 60Hz

Insert

Green Label

Plug Into Wall

Outlet

Foot Pedal

on/off Switch

Eye Bolt

Click

Eye Bolt

S100

S50

S100

S100S100S100S50

S100

S50

S100

S100 S100

S100

Insert yellow Label

Plugs Into Yellow

Labeled Extension Cord

Insert Blue Label

Plugs Into Blue

Labeled Extension Cord

Insert Red Label

Plugs Into Red

Labeled Extension Cord

Insert Purple Label

Plugs Into Purple

Labeled Extension Cord

Insert Orange Label

Plugs Into Orange

Labeled Extension Cord

Insert Pink Label

Plugs Into Pink

Labeled Extension Cord

Christmas Tree

Model: HMS-15CL

Sku # 658 450

Operation

Turning on the tree

Maintenance

Care and Cleaning

Troubleshooting

Spare parts

Repairing Loose Hinges

Problem Solution

The tree does

not light

Ensure that all tree sections are plugged

into each other and that the tree is

plugged into the wall. If your tree came

with a foot pedal, step on the

On/Off button.

Check for blown fuses at the power cord

plug. Replace as needed with the

replacement fuses provided.

Check for loose, broken, or missing bulbs

and replace as needed with the

replacement bulbs provided

Step 3.Shape the branches to your preference by working

from the bottom to the top.When adjusting

branches, ensure that all wires are free of branch

hinges.

Step 4.Connect the plug(s) securely to the extension cord(s)

as per the color labels indicated in attached photo

and insert the green label extension cord plug into

the wall outlet.

Step 5.When finished shaping the branches, slightly

upsweep all branch tips for a uniform look.

NOTE: If some bulbs do not light or flicker, search for any

loose plugs and/or broken, loose, or missing bulbs. Replace

bulbs promptly with the replacement bulbs provided in

order to maintain the performance and life expectancy of

your tree.

Step 1.Connect the light strings of the tree together and

plug the power cord into a wall outlet.

Step 2.If the tree comes with a foot pedal, step on the

On/Off button.

This tree package includes hinge pins, washers, bulbs and

fuses for any replacement or repair that you need to

perform on your tree. If extra parts are needed, contact the

Customer Service Team at 1-877-527-0313 between the

hours of 8 am and 5 pm EST, Monday through Friday.

Step 1.Remove all ornaments and decorations.

Step 2.Unplug the cord from the wall and then unplug each

section of the tree.

Step 3.Gently lift the tree top straight up to remove from the

center sections and fold all branches towards the

pole.

Step 4.Repeat this step for the bottom tree section.

Step 5.Carefully place all tree sections into a shipping box

and tape it shut.

Step 6.Store your tree in a cool, dry place away from sunlight.

Step 1.Place the branch into the slot of the bracket.

Step 2.Insert a new hinge pin through the holes of the

bracket and secure with a washer.

WARNING - Risk of fire:This product employs overload

protection (fuse lamp) in each series light circuit to provide

overload protection in addition to the fuse(s) located in the

plug. Do not replace the fuse lamp contained in this set with

any other type of lamp, use only spare fuse lamps provided

with this product. In case of a burnt out FUSED lamp, the

entire series of 50 lamps will be out.To replace the fused

lamp:

1. Grasp the plug and remove from the receptacle or other

outlet device. Do not unplug by

pulling the cord.

2. Locate the fused lamp with gray

color lamp holder. Pull the burnt

fused lamp and plastic lamp base

straight out of the lamp holder.

3. Replace with a spare fused lamp.The fused lamp can be

distinguished by a gray lamp base and an additional clear

plastic cover.

4. Plug in the lights again.

User servicing instructions

Fused Lamp Replacement
