Home Accents Holiday 21PG90231 Manuel utilisateur
Pre-Assembly
Package Contents
Part Description Quantity
A Tree top 1
B Tree center, Sticker 2 1
C Tree center, Sticker 1 1
D Tree stand 1
Christmas Tree
Model: 21PG90231
Sku # 1006 215 608
Tree top
Section 2
Section 1
Control box
Adapter
To Be Plugged
Into Wall
Outlet
Foot Pedal
on/off Switch
Safety Information
IMPORTANT SAFETY
INSTRUCTIONS
a. READ AND FOLLOW ALL
SAFETY INSTRUCTIONS.
When using electrical products, basic precautions should always
be followed, including the following:
b. Do not use seasonal products outdoors unless marked suitable for
indoor and outdoor use. When products are used in outdoor
applications,
connect the product to a Ground Fault Circuit Interrupting (GFCI)
outlet. If one is not provided, contact a qualified electrician for proper
installation.
c. This seasonal product is not intended for permanent installation or use.
d. Do not mount or place the product near gas or electric heaters,
fireplaces, candles, or other similar sources of heat.
e. Do not secure the wiring of the product with staples or nails, or place on
sharp hooks or nails.
f. Do not let lamps rest on the supply cord or on any wire.
g. Unplug the product when leaving the house, when retiring for the
night, or if left unattended.
h. This is an electric product and not a toy! To avoid risk of fire, burns,
personal injury and electric shock it should not be played with or
placed where small children can reach it.
i. Do not use this product for other than its intended use.
j. Do not hang ornaments or other objects from cord, wire, or light string.
k. Do not close doors or windows on the product or extensions cords as
this may damage the wire insulation.
l. Do not cover the product with cloth, paper, or any material that is not
a part of the product when in use.
m. This product is equipped with push-in type lamps. Do not twist lamps.
n. Read and follow all instructions that are on the product or provide with
the product.
o.
SAVE THESE INSTRUCTIONS
Align both arrows
in a straight line
before sliding
down to insert
Open the
cap cover
Do Not Tamper
Internal Parts
NEED HELP?
DO NOT RETURN TO STORE. Call: 1-877-527-0313
Form 8am to 5pm EST, Monday through Friday.
Assembly
80S
100S
100S
70S
100S
50S
100S
100S
Step 1. Pull apart the legs of the stand so that they are snapped
into an x-shape, place the tree stand on a level surface.
To close the stand, press the metal button and fold the legs together.
Assembling the tree
This tree assmbles with Quick Set® technology
---Set up and light up your tree in less than 10 minutes!
Step 1. Remove the protective caps from the tree bottom and
insert the pole into the tree stand.
Step 2. Continue by inserting the upper tree section(s) to the
lower section(s) until inserting the tree top.
Step 3. Shape the branches to your preference by working from
the bottom to the top. When adjusting branches, ensure
that all wires are free of branch hinges.
Step 4. Insert the adapter into the wall outlet. All your lights
should now be lit.
Step 5. Shape the tree from the bottom to the top. Start with the
branches farthest from the pole – fan out in a star shape,
and continue until the entire tree is shaped.
Step 6. When finished shaping the branches, slightly upsweep
all branch tips for a uniform look.
Assembling the tree stand
Click
Top view Side view
TM
Step 1.
Grasp the power adapter or power cord plug,
and than unplug from the power outlet.
Do not pull the power cord.
LAMP REPLACEMENT
Step 2.
Lift up lamp lock tab, then pull the
lamp and plastic lamp base
straight out of the lamp-holder.
Step 3.
Replace with a new spare lamp
provided with this product.
(Reference figure only)
This tree package includes hinge pins, washers and bulbs for any
replacement or repair that you need to perform on your tree. If
extra parts are needed, contact the Customer Service Team at
1-877-527-0313 between the hours of 8 am and 5 pm EST,
Monday through Friday.
Repairing Loose Hinges
Step 1. Place the branch into the slot of the bracket
Step 2. Insert a new hinge pin through the holes of the
bracket and secure with a washer.
Maintenance
Spare parts
Turning on the tree
NOTE: If some bulbs do not light or flicker, search for any loose
plugs and/or broken, loose, or missing bulbs. Replace bulbs
promptly with the replacement bulbs provided in order to
maintain the performance and life expectancy of your tree.
Step 1. Connect the light strings of the tree together and plug
the adapter into a wall outlet.
Step 2. If the tree comes with a foot pedal, step on the On/Off
button.
Operation
1. Before using or reusing, inspect product carefully. Discard any
products that have cut, damaged or frayed wire insulation or
cords, cracks in the lampholders or enclosures, loose
connections, or exposed copper wire.
2. Before disassembling the tree, unplug the tree and remove all
ornaments and decorations.
3. Gently lift the tree top straight up to remove from the center
section and fold all branches towards the pole.
4. Repeat this step for the center and bottom tree sections.
5. When storing the product, carefully remove the product from
wherever it is placed, including tree, branches, or bushes, to
avoid anyundue strain or stress on the product conductors,
connections, and wires. Cover the
protective cap on the poles to avoid
damaging the internal parts.
6. When not in use, store neatly in a cool,
dry location protected from sunlight.
Use and Care Instructions
To activate the DEMO mode:
1. With the tree plugged in, press and hold the FUNCTION button of
the in-line controller/receiver for 5 seconds.
2. The Clear Lights will blink 3 times. The tree is now in DEMO mode.
3. Within DEMO mode, the tree will display the COMBO pattern at all
time unless the function button is pressed to change the flashing
pattern. The tree will return to COMBO pattern whenever the
controller is idle for 30 seconds.
To deactivate the DEMO mode:
1. With the tree plugged in and in DEMO mode, press and hold the
FUNCTION button of the in-line controller/receiver for 5 seconds.
2. The multi-light will flash 5 time indicating that DEMO mode is off.
3. The tree is now in normal mode. Flashing pattern can be set to
whichever desired and the tree will remember the last setting.
*IN-LINE CONTROLLER/RECEIVER
*Controller
Tree Comes with Demo Mode Not Activated
CAUTION:
Use only power adapter that was provided with this product.
Using a different power adapter will damage the lights and cause
fire, electrical shock hazard.
Christmas Tree
Model: 21PG90231
Sku # 1006 215 608
Press the selector button on the “Light Controller” to select among:
(1) WARM WHITE - MULTI: FADING
(2) WARM WHITE: FADING
(3) WARM WHITE - MULTI: ALTERNATING
(4) WARM WHITE: STEADY
(5) WARM WHITE - MULTI: SLOW FADING
(6) MULTI: STEADY
(7) MULTI: FADING
(8) COMBINATION
HOW TO USE THE DUAL COLOR LIGHT CONTROLLER:
User servicing instructions
Light
Controller
Selector
Button
TM
Troubleshooting
Problem Solution
The tree does not
light
Ensure that all tree sections are plugged into
each other and that the tree is plugged into
the wall. If your tree came with a foot pedal,
step on the On/Off button.
Check for loose, broken, or missing bulbs and
replace
as needed with the replacement
bulbs provided
Christmas Tree
Model: 21PG90231
Sku # 1006 215 608
TM
Not Full?
Spread Branches
Tree is in Demo Mode
Run Extension Cord
Tree Topper? Lights Cycle Through
Functions?
Branch Hanging Low?
Bend up
No Lights Working?
Check For Loose Connection
Ensure pole fully connected
Section Out?
Other Issue? Call 1-877-527-0313
To deactivate:
Press & hold until multicolor
lights blink 5 times
To activate:
Press & hold until warm white
lights blink 3 times
Function
button
