Home Accents Holiday 21PG90177 Manuel utilisateur

Safety Information

IMPORTANT SAFETY

INSTRUCTIONS

a. READ AND FOLLOW ALL

SAFETY INSTRUCTIONS.

When using electrical products, basic precautions should always

be followed, including the following:

b. Do not use seasonal products outdoors unless marked

suitable for indoor and outdoor use. When products are used

in outdoor applications, connect the product to a Ground

Fault Circuit Interrupting (GFCI) outlet. If one is not provided,

contact a qualified electrician for proper installation.

c. This seasonal product is not intended for permanent

installation or use.

d. Do not mount or place the product near gas or electric

heaters, fireplaces, candles, or other similar sources of heat.

e. Do not secure the wiring of the product with staples or nails,

or place on sharp hooks or nails.

f. Do not let lamps rest on the supply cord or on any wire.

g. Unplug the product when leaving the house, when retiring

for the night, or if left unattended.

h. This is an electric product and not a toy! To avoid risk of fire,

burns, personal injury and electric shock it should not be

played with or placed where small children can reach it.

i. Do not use this product for other than its intended use.

j. Do not hang ornaments or other objects from cord, wire, or

light string.

k. Do not close doors or windows on the product or extensions

cords as this may damage the wire insulation.

l. Do not cover the product with cloth, paper, or any material

that is not a part of the product when in use.

m. This product is equipped with push-in type lamps. Do not

twist lamps.

n. Read and follow all instructions that are on the product

or provide with the product.

o. SAVE THESE INSTRUCTIONS

Step 1

. Choose a location near a wall outlet.

Step 2

. Unfold the legs of the tree stand and lay the stand

on the floor.

Step 3

. Slide the locking disk of the tree stand down until it

snaps into place.

Assembling the tree

Step 1

. Remove the protective caps from the tree bottom

and insert the pole into the tree stand.

Step 2

. Continue by inserting the upper tree section(s) to

the lower section(s) until inserting the tree top.

Step 3

. Shape the branches to your preference by working

from the bottom to the top. When adjusting branches,

ensure that all wires are free of branch hinges.

Step 4

. Insert the adapter into the wall outlet. All your lights

should now be lit.

Step 5.

Shape the tree from the bottom to the top. Start with

the branches farthest from the pole – fan out in a star

shape, and continue until the entire tree is shaped.

Step 6

. When finished shaping the branches, slightly

upsweep all branch tips for a uniform look.

Assembly

Assembling the tree stand

Pre-Assembly

Package Contents

Part Description Quantity

A Tree top 1

B Tree Section2 (Sticker ) 1

C Tree Section1 (Sticker ) 1

D Tree stand 1

Christmas Tree

Model: 21PG90177

Sku # 1006 215 465

Tree top

Section 2

Section 1

Control box

Adapter

To Be Plugged

Into Wall

Outlet

Top view Side view

NEED HELP?

DO NOT RETURN TO STORE. Call: 1-877-527-0313

Form 8am to 5pm EST, Monday through Friday.

100S

50S

100S

Insert Red Label

Plugs Into Red

Labeled Extension Cord

Christmas Tree

Model: 21PG90177

Sku # 1006 215 465

Step 1. Grasp the power adapter or power cord plug,

and than unplug from the power outlet.

Do not pull the power cord.

LAMP REPLACEMENT

Step 2. Lift up lamp lock tab, then pull the

lamp and plastic lamp base

straight out of the lamp-holder.

Step 3. Replace with a new spare lamp

provided with this product.

(Reference figure only)

This tree package includes hinge pins, washers and bulbs for any

replacement or repair that you need to perform on your tree. If extra

parts are needed, contact the Customer Service Team at

1-877-527-0313 between the hours of 8 am and 5 pm EST, Monday

through Friday.

Repairing Loose Hinges

Step 1. Place the branch into the slot of the bracket

Step 2. Insert a new hinge pin through the holes of the

bracket and secure with a washer.

Maintenance

Spare parts

Turning on the tree

NOTE: If some bulbs do not light or flicker, search for any loose plugs

and/or broken, loose, or missing bulbs. Replace bulbs promptly with the

replacement bulbs provided in order to maintain the performance and

life expectancy of your tree.

Step 1. Connect the light strings of the tree together and plug

the adapter into a wall outlet.

Operation

1. Before using or reusing, inspect product carefully. Discard any products

that have cut, damaged or frayed wire insulation or cords, cracks in the

lampholders or enclosures, loose connections, or exposed copper wire.

2. Before disassembling the tree, unplug the tree and remove all ornaments

and decorations.

3. Gently lift the tree top straight up to remove from the center section and

fold all branches towards the pole.

4. Repeat this step for the center and bottom tree sections.

5. Carefully place all tree sections into a shipping box and tape it shut.

6. When not in use, store neatly in a cool,

dry location protected from sunlight.

Use and Care Instructions

Press the selector button on the “Light Controller” to select among:

(1) WARM WHITE - MULTI: FADING

(2) WARM WHITE: FADING

(3) WARM WHITE - MULTI: ALTERNATING

(4) WARM WHITE: STEADY

(5) WARM WHITE - MULTI: SLOW FADING

(6) MULTI: STEADY

(7) MULTI: FADING

(8) COMBINATION

HOW TO USE THE DUAL COLOR LIGHT CONTROLLER:

User servicing instructions

Light

Controller

Selector

Button

To activate the DEMO mode:

1. With the tree plugged in, press and hold the FUNCTION button of the

in-line controller/receiver for 5 seconds.

2. The Clear Lights will blink 3 times. The tree is now in DEMO mode.

3. Within DEMO mode, the tree will display the COMBO pattern at all time

unless the function button is pressed to change the flashing pattern.

The tree will return to COMBO pattern whenever the controller is idle

for 30 seconds.

To deactivate the DEMO mode:

1. With the tree plugged in and in DEMO mode, press and hold the

FUNCTION button of the in-line controller/receiver for 5 seconds.

2. The multi-light will flash 5 time indicating that DEMO mode is off.

3. The tree is now in normal mode. Flashing pattern can be set to

whichever desired and the tree will remember the last setting.

*IN-LINE CONTROLLER/RECEIVER

*Controller

Tree Comes with Demo Mode Not Activated

CAUTION:

Use only power adapter that was provided with this product. Using a

different power adapter will damage the lights and cause fire, electrical

shock hazard.

Troubleshooting

Problem Solution

The tree does

not light

Ensure that all tree sections are plugged into

each other and that the tree is plugged into

the wall.

Check for loose, broken, or missing bulbs and

replace as needed with the replacement bulbs

provided

Run Extension Cord

Tree Topper? Branch Hanging Low?

Bend up

No Lights Working?

Check For Loose Connection

Other Issue? Call 1-877-527-0313

Not Full?

Spread Branches

Light Section Out?

Connect Plug Between Sections

Tree is in Demo Mode

Lights Cycle Through

Functions?

To deactivate:

Press & hold until multicolor

lights blink 5 times

To activate:

Press & hold until warm white

lights blink 3 times

Function

button
