Home Accents Holiday 1003142984 Manuel utilisateur

Safety Information

IMPORTANT SAFETY

INSTRUCTIONS

When using electrical products, basic precautions should always be

followed including the following:

a) READ AND FOLLOW ALL SAFETY

INSTRUCTIONS.

b) This product is for indoor use only. The electrical rating 0.6 A 120 V 60

Hz.

c) Do not use seasonal products outdoors unless marked suitable for

indoor and outdoor use. When products are used in outdoor applications,

connect the product to a Ground Fault Circuit Interrupting (GFCI) outlet. If

one is not provided, contact a qualified electrician for proper installation.

d) This seasonal use product is not intended for permanent installation or

use.

e) Do not mount or place near gas or electric heaters, fireplace, candles or

other similar sources of heat.

f) Do not secure the wiring of the product with staples or nails, or place on

sharp hooks or nails.

g) Do not let lamps rest on the supply cord or on any wire.

h) Unplug the product when leaving the house, when retiring for the night,

or if left unattended.

i)Thisisanelectricproduct–notatoy! Toavoidriskoffire,burnspersonal

injuryandelectricshockitshouldnot beplayedwithorplacedwheresmall

children can reach it.

j) Do not use this product for other than its intended use.

k) Do not hang ornaments or other objects from cord, wire, or light string.

l) Do not close doors or windows on the product or extension cords as this

may damage the wire insulation.

m)Do not cover theproductwithcloth,paperoranymaterialnotpartof the

product when in use.

n)This product employs overload protection (fuse). A blown fuse

indicates an overload or short-circuit situation. If the fuse blows, unplug

theproduct fromthe outlet. Alsounplugany additional stringsorproducts

that may be attached to the product. Replace the fuse as per the User

Serving instructions (follow product marking for proper fuse rating) and

check the product. If the replacement fuse blows, a short-circuit may be

present and the product should be discarded.

o) Read and follow all instructions that are on the product or provided with

the product.

p) SAVE THESE INSTRUCTIONS.

Pre-Assembly

Package Contents

Part Description Quantity

A Tree top 1

B Upper middle section 1

C Lower middle section 1

D Tree bottom 1

E Tree stand 1

F Power cord 1

7.5 ft Warm White / Multi Micro Dot LED 9 Function

One Plug Tree

SKU# 1003142984

Assembly

Assembling the tree stand

Step 1. Choose a location near a wall outlet.

Step2. Open the standto a 90 degree angleuntil the hole linesupwith the

hole on the tube.

Step 3. Screw an eye bolt into the hole.

CAUTION! – ALWAYS UNPLUG YOUR TREE

FROM ITS POWER SOURCE BEFORE ASSEMBLING OR

DISASSEMBLING.

Assembling the tree

Pleaseremove protective covers from the base of the pole for each tree

section before assembling.

Step 1. Insert tree bottom (D) into the tree stand and tighten the screw.

(See Fig. 1)

Step2. Insertlowermiddlesection(C)intothetreebottom(D).(SeeFig.2)

Step 3 Insert upper middle section (B) into the lower middle section (C).

(See Fig. 3)

Step 4. Insert tree top (A) into the upper middle section (B). (See Fig. 4)

Warning: There is a tree top connector on the tree top (A). Do

not overload. Connect other lighting strings or tree toppers

end-to-end up to a maximum of 216 Watts (1.8 Amps). Do not

interconnect low-voltage products.

Step 5. Insert the provided power cord into the connector on the tree

bottom (D) in right direction porperly and tightly (always match the

protuberance of the end connector of power cord to the concave

of the connector found on the tree bottom (D) according to the

magnified drawing on fig. 5.).

Step6. Allowbranchestofall into placeorgentlypull branchesup andout.

When adjusting branches be sure that all wires are free of branch

hinges. (See Fig. 6)

Step 7. Shape the branches. Starting with tips closest to the pole, shape

onetiptotheright,one totheleftandoneatthecenterofthemain

stem. Repeat pattern for each branch. (See Fig. 7)

Step 8. Plug the power cord into a proper outlet. This tree comes with a

control box to change functions. This tree is Color Changing, the

9 lighting options available are:

1. Steady On

2. Steady Warm White

3. Flashing Warm White

4. Fade In and Fade Out Warm White

5. Steady Multicolor

6. Flashing Multicolor

7. Fade In and Fade Out Multicolor

8. Sequential Multicolor & Warm White

9. Color Changing

These functions can be changed by using the control box.

Please see Instructions of control box as below.

Operation

Turning on the tree

Step 1. Connect each tree section well and plug the power cord into a wall

outlet.

Instruction of control box

1. Press the ON/OFF Timer button on control box more than 1 second

to turn on and off timer function.

2. Press the ON/OFF Timer button on control box for more than 2

seconds to select below timer hours:

i. Indicator lights of timer on control box turn on red:

The tree lights will automatically run through a 2-hours

ON, 22-hours OFF cycle.

ii. Indicator lights of timer on control box turn on green:

The tree lights will automatically run through a 4-hours

ON, 20-hours OFF cycle.

iii. Indicator lights of timer on control box turn on blue:

The tree lights will automatically run through a 6-hours

ON, 18-hours OFF cycle.

iv. Indicator lights of timer on control box turn on yellow:

The tree lights will automatically run through an 8-hours

ON, 16-hours OFF cycle.

No memory mode on timer whether the tree or the timer is

re-started.

3. Press the Function button to select the lighting functions below:

1) Steady On

2) Steady Warm White

3) Flashing Warm White

4) Fade In and Fade Out Warm White

5) Steady Multicolor

6) Flashing Multicolor

7) Fade In and Fade Out Multicolor

8) Sequential Multicolor & Warm White

9) Color Changing

There is memory mode on Function adjustment.

Maintenance

Replace the fuse.

1. Power cord fuse replacement (replaceable 3 amp, 125 volt fuse is

located in spare parts bag):

2. Grasp plug and remove from the receptacle or other outlet device. Do

not unplug by pulling on cord.

3. Open fuse cover. Slide open the fuse access cover on

back of control box.

4. Remove fuse carefully.

5. Risk of fire. Replace fuse only with 3 Amp, 125 Volt fuse (provided with

product).

6. Close fuse cover. Slide closed the fuse access cover.

7. Risk of fire. Do not replace attachment plug. Contains a safety device

(fuse)that shouldnotberemoved. Discard productifthe attachmentplug

is damaged.

CAUTION! – ALWAYS UNPLUG YOUR TREE FROM ITS

POWER SOURCE BEFORE ATTEMPTING FUSE REPLACEMENT.

CAUTION: To reduce the risk of fire or electric shock, do not

attempt to replace lamps or modify string.

Care and Cleaning

Step 1. Remove all ornaments and decorations.

Step 2. Unplug the power cord from the wall outlet. And remove your

power cord from tree bottom (D) and save them.

Step3. Gentlyliftthe treetopstraightup toremovefromthe center section

and fold all branches towards the pole.

Step 4. Repeat this step for the center and bottom tree sections.

Step5. Carefullyplacealltreesectionsintoashippingboxandtapeitshut.

Step 6. Store your tree in a cool, dry place away from sunlight.

Troubleshooting

Problem Solution

The tree

does not

light

Ensurethat alltreesectionsare connectedwellandthat

the tree is plugged into the wall outlet. Make sure the

power cord is well connected to the tree bottom (D).

Check for blown fuses at the power cord plug. Replace

as needed with the replacement fuses provided.

If you are still experiencing problems with the tree

please call 1-877-527-0313 for instructions.

Warning: Please note that changes or modifications

not expressly approved by the party responsible for

compliance could void the user’s authority to operate the

equipment.

NOTE: This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to Part 15

of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by

one or more of the following measures:

● Reorient or relocate the receiving antenna.

● Increase the separation between the equipment and

receiver.

● Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

● Consult the dealer or an experienced radio/TV technician

for help.

UL Model No. LTW36C-12V1C
