Home Accents Holiday 1001302140 Manuel utilisateur

Safety Information

IMPORTANT SAFETY

INSTRUCTIONS

When using electrical products, basic precautions should always be

followed including the following:

a) READ AND FOLLOW ALL

SAFETY INSTRUCTIONS.

b)This product is for indoor use only. The electrical rating0.4 A120V60

Hz.

c) This seasonal use product is not intended for permanent installation or

use.

d)Donotmountorplaceneargasorelectricheaters,fireplace,candlesor

other similar sources of heat.

e)Donotsecurethewiring of theproductwithstaplesor nails, or place on

sharp hooks or nails.

f) Do not let lamps rest on the supply cord or on any wire.

g)Unplug the product when leaving the house, when retiring for the night,

or if left unattended.

h) This is an electric product –not a toy! To avoid risk of fire, burns

personal injury and electric shock it should not be played with or placed

where small children can reach it.

i)Do not use this product for other than its intended use.

j) Do not hang ornaments or other objects from cord, wire, or light string.

k)Donotclosedoorsorwindowsontheproductorextensioncordsasthis

may damage the wire insulation.

I)Do not cover the product with cloth,paperoranymaterial not part ofthe

product when in use.

m) This product employs overload protection (fuse). A blown fuse

indicates an overload or short-circuit situation. If the fuse blows, unplug

theproductfromtheoutlet. Also unplug any additionalstrings orproducts

that may be attached to the product. Replace the fuse as per the User

Servicing Instructions (following product marking for proper fuse rating)

and check the product. If the replacement fuse blows, a short-circuit may

be present and the product should be discarded.

n)This product is equipped with push-in type lamps. Do not twist lamps.

o)Thisproducthasapolarized plug (one blade is wider than the other) as

afeaturetoreducetheriskofelectricshock. Thisplugwillfitinapolarized

outlet only one way. If the plug does not fit fully in the outlet, reverse the

plug. If it still does not fit, contact a qualified electrician. Do not use with

an extension cord unless plug can fully inserted. Do not alter or replace

the plug.

p)Read and followallinstructionsthat areontheproduct or providedwith

the product.

q) SAVE THESE INSTRUCTIONS.

Pre-Assembly

Package Contents

Part

Description

Quantity

A Tree top 1

B Tree center 1

Tree bottom

Tree stand

Power supply cord with a

foot pedal switch

7.5' Warm White/Multi LED Color Changing

self Shape One Plug Tree

SKU# 1001302140

Assembly

Assembling the tree stand

Step 1. Choose a location near a wall outlet.

Step2.Openthestandtoa90degreeangleuntiltheholelinesupwiththe

hole on the tube.

Step 3. Screw an eye bolt into the hole.

CAUTION! – ALWAYS UNPLUG YOUR TREE

FROM ITS POWER SOURCE BEFORE ASSEMBLING OR

DISASSEMBLING.

Assembling the tree

Please remove protective covers from the base of the pole for each tree

section before assembling.

Step1. Inserttreebottom (C)intothetreestand(D)andtighten thescrew.

(See Fig. 1)

Step 2. Insert tree center (B) into the tree bottom (C). (See Fig. 2)

Step 3Insert the tree top (A) into the tree center (B). (See Fig. 3)

Step 4. Connect the end connector of power cord with foot pedal switch

(E) with the connector found on the bottom section (C) in correct

direction (always match the connection on the end connector of

powercordto the concaveonthe connectorfound onthebottom

section (C) according to the magnified drawing on Fig. 4.

Step5. Allowbranchestofallintoplaceorgentlypullbranchesupandout.

Whenadjustingbranchesbesurethatallwiresarefreeofbranch

hinges. (See Fig. 5)

Step 6. Shape the branches. Starting with tips closest to the pole, shape

one tip to the right, one to the left and one at the center of the

main stem. Repeat pattern for each branch. (See Fig. 6)

Step 7. Plug the well-connected power supply cord from the bottom

section (C) into electrical outlet. Please note this tree comes

with a foot pedal switch for changing functions. This tree is

Color Changing, the 8 lighting options available are:

1.Steady Warm White

2.Flashing Warm White

3.Slow Fade Warm White

4. Steady Multicolor

5. Flashing Multicolor

6.Slow Fade Multicolor

7.Sequential Multicolor & Warm White

8.Slow Fade Multicolor & Warm White

Operation

Turning on the tree

NOTE: If some bulbs do not light or flicker, search for any loose, broken

bulbs and /or missing bulbs. Replace bulbs promptly with the

replacement bulbs provided in order to maintain the performance and life

expectancy of your tree.

Step1. Connecteachtreesectionwellandplugthepowercordintoawall

outlet.

Maintenance

Fuse Replacement

A) Extension cord fuse replacement(1 replaceable 3A, 125 V fuse is

located in the plug):

Note: This plug will fit in a polarized outlet only one way. If the plug does

not fit fully in the outlet, reverse the plug.

1. Graspplugandremove fromits powersource.

2. Locate blown fuse by sliding access cover on

top of plug towards prongs.

3. Remove blown fuse by turning the plug over.

Fuses should fall into your hand (gentle tapping

may be required).

4. Locate spare replacement fuse included in plug.

5.Insertsparereplacement fuse. Close fuse cover by sliding fuse access

cover towards the cord.

CAUTION:To reduce risk of fire –replace fuse in extension

cord with only 3 A, 125 V fuse. Do not replace attachment plug. Discard

product if the attachment plug is damaged.

Replacing the bulbs

1. Grasp plug and remove from itspower source.

2. Unlock the lamp lock on the socket of the bulb.

3. Pull bulb AND plastic base straight out of socket. Do not twist bulbs

while you are removing them.

4. Replace burnt outbulbwith3.0V, 0.06 WLED bulb ONLY. (Additional

bulbs are included for your convenience.)

5. Relock the lamp lock on the socket of the bulb.

If the new lamp base does not fit in lampholder, follow these steps:

Pull reflector out.

Remove the base of the burned-out

bulb by straightening the bulb leads,

and gently pull bulb out.

Thread leads of new bulb through

holes in old base with one lead in each hole.

After bulb is fully inserted into base, bend each lead up so that the

leads will touch the contacts inside the bulb holder.

Insert the reflector into the base.

CAUTION! – ALWAYS UNPLUG YOUR TREE

FROM ITS POWER SOURCE BEFORE ATTEMPTING

FUSE AND BULB REPLACEMENT.

Care and Cleaning

Step 1. Remove all ornaments and decorations.

Step2. Unplugtheplugcordfromthewalloutlet. Andremoveyourpower

supply cord with an on/off foot pedal switch from bottom section

Step 3. Gently lift the tree top straight up to remove from the center

section and fold all branches towards the pole.

Step 4. Repeat this step for the center and bottom tree sections.

Step 5. Carefully place all tree sections into a shipping box and tape it

shut.

Step 6. Store your tree in a cool, dry place away from sunlight.

Warning: Please note that changes or modifications not

expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to Part

15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause

harmful interference to radio communications.

Troubleshooting

Problem

Solution

Thetreedoes

not light

Ensure that all tree sections are connected well into

each other and that the tree is plugged into the wall

outlet.

Check for blown fuses at the power cord plug.

Replace as needed with the replacement fuses

provided.

Check for loose, broken, or missing bulbs and

replace as needed with the replacement bulbs

provided.

If you are still experiencing problems with the tree

please call 1-877-527-0313 for instructions.

However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference

by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and

receiver.

- Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician

for help.

UL Model No. TME7.5-6(0.4)
