HOLUXWirelessGPSLoggerM-241User’sManual

Holux

Wireless GPS Logger

M-241

OCT 2007

Rev.A

Technology, Inc.

1F, No. 30, R&D Rd. II, HsinChu City 300, Science-based Industrial Park, Taiwan

TEL: 886-3-6687000 FAX: 886-3-6687111

Website: www.holux.com

User’s Guide

HOLUX Wireless GPS Logger M-241 User’s Manual

Table of Contents

Table of Contents ........................................................................................................................3

1. Overview ..............................................................................................................................4

2. Packing List .........................................................................................................................6

3. Main features .......................................................................................................................7

4. Specification ........................................................................................................................8

5. Icons & Indicators .............................................................................................................10

6. Product Overview..............................................................................................................11

7. Basic Operations...............................................................................................................12

8. Connecting the device to the PC .....................................................................................20

9. Download Log Data to PC ................................................................................................21

10. Bluetooth device connection installation .......................................................................31

11. Installation of Mini GPS Viewer program ........................................................................33

12. Execute the Mini GPS Viewer program ...........................................................................34

13. Power .............................................................................................................................36

14. Warranty.............................................................................................................................36

15. Troubleshooting ................................................................................................................37

Federal Communications Commission (FCC) Statement......................................................38

HOLUX Wireless GPS Logger M-241 User’s Manual

1. Overview

The HOLUX M-241 wireless GPS logger provides real time coordinate

logging and easy-to-use trip guiding service. The M-241 can record up to

130,000 positions, each position including longitude, latitude, time, and altitude.

The log file can be downloaded for analysis via USB connection. You can

combine these positions with your Digital camera photos to share the track

histories and photo locations to mapping application software such as Google

Earth.

Position information, moving speed, free logging volume and the date &

time can be shown on the LCD display directly at any time. The M-241

supports distance and time logging modes, kilometer and mile distance units,

and 3 languages (English, Traditional Chinese, and Simplified Chinese).

Because the M-241 provides a Bluetooth interface, you can use it freely

while driving without the clutter of cables.

Enjoy the GPS life!

The M-241 is a high performance wireless GPS logger with the following

features:

1. Dual interface (Bluetooth + GPS-mouse by USB cable).

2. Compatible with Bluetooth Serial Port Profile (SPP) completely.

3. Powered by one AA battery.

4. LCD display (32mm L* 8.9mm W) to show position information, speed,

capable logging memory size, date & time.

5. Capable memory size to record up to 130,000 positions, including longitude,

latitude, time, and altitude.

6. Personal settings to select the logging mode by distance or time, unit by

Kilometer or mile, and 3 languages (English, Traditional Chinese, and

Simplified Chinese) support.

HOLUX Wireless GPS Logger M-241 User’s Manual

Applications:

* Vehicle tracing & Location base services

* Navigation with PDA/Notebook/Smartphone devices

* Car navigation

* Marine navigation

* Distance measurement

* Sports and Recreation

* Fleet Management

Software application program:

A user-friendly software utility is provided with the following functions:

* Download recorded data to PC.

* Recording mode setting (Time / Distance)

* Erase recorded data

* Output data format

(1) Save exploring data to KML file format (Interface with Google Earth)

(2) NMEA file format (*.txt)

(3) Binary file format

(4) GPX file format

HOLUX Wireless GPS Logger M-241 User’s Manual

2. Packing List

Thank you for purchasing the M-241 wireless GPS logger. Before you start,

make sure that the following items are included in your package. If any of

these items are missing, please contact your original local HOLUX dealer or

distributor.

1. M-241 wireless GPS logger 1 Set

2.AABattery 1Set

3. Car Charger *+ USB cable 1 Set

4. User guide and Driver CD 1 Pcs

5. M-241 Quick Guide 1 Pcs

6.Warrantycard 1Pcs

7. Nylon strap 1 Pcs

Option

1. Travel power supply 1 Set

* Car Charger can only be used as the power supply adapter, it does not

have any battery charging function.

HOLUX Wireless GPS Logger M-241 User’s Manual

3. Main features

1. Built-in MTK Low power consumption GPS chipset.

2. 32 parallel satellite-searching channels for fast acquisition and

reacquisition.

3. Superior sensitivity, up to -159 dBm.

4. Built-in WAAS/EGNOS/MSAS Demodulator without any additional

hardware.

5. Completely compatible with Bluetooth Serial Port Profile (SPP).

6. Low power consumption. Use AA alkaline batteries (or rechargeable

batteries) for up to 12 hours of operation.

7. Provide expanded terminal contact to other systems without the

Bluetooth device.

8. Support NMEA0183 V 3.01 data protocol

9. Compact and lightweight design for ease of use.

10. LCD display (32mm * 8.9mm /128 * 32 pixels) to show position

information, speed, capable logging memory size, date & time.

11. Capable memory size to record up to 130,000 position data, including

longitude, latitude, time, and altitude.

12. Personal setting to choose the logging mode by distance or time, unit

by Kilometer or mile, and 3 languages (English, Traditional Chinese,

Simplify Chinese) support.

HOLUX Wireless GPS Logger M-241 User’s Manual

4. Specification

Specifications

•32 parallel satellite searching channels

•Receiver: L1, 1575.42 MHz

•Frequency: 1.023 MHz

•Update frequency: 1 Hz.

•Antenna type: Built-in

•Satellite signal reception sensitivity: -159dBm

•Dimensions: 32.1mm X 30mm X 74.5mm

•Weight (excluding battery): < 39g.

•Switch: Slider switch

•1 AA alkaline battery lasts for up to 12 hours of operation

•Operating temperature: 0 ℃to + 50 ℃

•Storage temperature: -10 ℃to + 60 ℃

•Operating humidity: 5% to 90%

Positioning

◆Non DGPS (Differential GPS)：

•Position : 3.0 M CEP excluding SA

•Velocity: 0.1M / sec.

•Interval: 0.1 sec to Sync GPS

◆DGPS (EGNOS/WAAS/MSAS)：

•Position: < 2.2 M., Horizontal deviation 95% time

< 5 M., Vertical deviation 95 % time

*The above data is based on the specifications of the MTK GPS chip

Positioning

Timing

•Time to reposition < 0.1 sec average

•Hot boot 1 sec

•Warm boot 33 sec

•Cold boot 36 sec

*The above data are based on specifications of the MTK GPS chip

Protocol and

Interface

◆Bluetooth compatible serial specifications (SPP)

•Bluetooth V1.2 compatible

•Bluetooth class 2 (within 10m of range in open space)

•Frequency: 2.400 to 2.480 GHz

•Modulation: FHSS / GFSK

•RF channels: 79

•Input sensitivity: -85dBm

•Output power: +2dBm

HOLUX Wireless GPS Logger M-241 User’s Manual

◆Output port: Mini-USB (CMOS Level)

•NMEA protocol output: V 3.01

Baud rate: 38400 bps

Data bits: 8

Sync bits: N

End bit: 1

•Output interface:

Standard: GPGGA (1 time per second), GPGSA (1 time per second),

GPGSV (1 time per second), GPRMC (1 time per second), GPVTG (1

time per second).

Physical

Specifications

•Sea level: Max 18,000 M (60,000 feet)

•Velocity: Max 515 M./sec ( 1000 knots)

•Acceleration: Max 4G

•Vibration: 20 M/ second3, Max.

Buttons 1 Power switch, 2 Buttons (Menu and Confirm)

LCD display

page

•System and satellite positioning status

•Time

•Position

•Velocity

•Distance measurement

•Setup

HOLUX Wireless GPS Logger M-241 User’s Manual

5. Icons & Indicators

Position Icon Descriptions Position Icon Descriptions

1 Log by Time 2 Measure Distance On

1 Log by Distance 4 Lock On

3 Log On 7 Device & PC Connected

4 Waypoint 8 Battery is Full

6 GPS Fix 8 Battery is exhausted

5 Bluetooth Connection
