Features:
Description:
True Multiplex 6 Channel Distributed Audio
Modular System - components added as needed
Integrated 2 Channel Digital Message Repeater
Live Microphone Page to any zone
Fast RS-485 Communication Protocol
Easy Installation and Operation
Natural Sound Voice Recordings
Built in Alarm and Alert Signals
Up to 4 Minute Message Capacity
Works with 12VDC or 24VDC Fire Alarm Panel
Works with Analog/Addressable and
Microprocessor based Fire Alarm Panels.
3 Minute Message Restart on Microphone Key
Made in the USA.
Fully Supervised
The Hochiki FNV High Rise Evacuation System
operates in conjunction with the Fire Alarm Control
Panel (FACP) in a building to provide automatic
response to life safety emergencies.
The Hochiki FNV includes all necessary features
to provide an effective voice evacuation system.
The Hochiki FNV can be custom configured to
satisfy the needs of any high rise application.
Fire department authorities can easily take
command of evacuation or relocation procedures
and emergencies. Building management and fire
brigades can monitor and control emergency
response even before the professionals arrive
The FNV system includes capacity for 6 channels
of simultaneous audio. This provides for
evacuation, stay-in-place, or other public address
announcements and automatic messages.
Fire Fighter Phones or Warden Stations may be
included as required.
System Configuration:
Basic System Includes:
Master Panel (FNV-MP)
Master Mic Control
16 switch control points
Dual Channel DMR
High speed communication loop
Distributed Panel (FNV-DP)
4 Output Zones (may be configured for 8)
Dual Channel Audio Interface
Dual Channel Amplification
Optional
Integrated Fire Phone
Area-of-Rescue (Future Option)
Fan and Damper system control (Future Option)
Number of distributed panels to be
determined by building specifications
Maximum System Configuration
Up to 250 Distributed Panels (FNV-DP)
And up to 1000 monitor and control points
PAGING
CONTROL
SYSTEM
RESET
PAGE
ALL-CALL
FAULT
SILENCE
LISTED
1.2
VoiceNET
High Rise Voice
Evacuation System
7051 Village Drive, Suite 100 Buena Park, CA 90621-2268 714.522.2246 www.hochiki.com
