GuestCall® Paging w/CommPass Pagers
Quick Setup Guide
Components
• JTECH Transmier
Applies to models: IQ Base, NEO, IStaon
• CommPass Pagers
• CommPass Charger
Lock the antenna to the connector on the
transmier by placing the antenna on the
connector and twisng le to lock in place.
Step 1
Plug the power supply into the transmier and
then into a standard 110-240v outlet. A surge
protector is recommended.
Step 2
Compile charger bases and connector wires if
applicable. Plug charger power supply into
charger and then into a standard outlet. Surge
protecon is recommended for charging bases.
Step 3
Add pagers to slots. You will see a BLUE light on
each pager. This light indicates the charging
status.
Step 4 • ‘LO’ on the number display: Baery is below 20% charged and SHOULD NOT be used.
• Flashing BLUE: Pager is charging and CAN BE used.
• Solid BLUE: Pager is fully charged.
• Allow 4 hours for a complete charge of the pagers.
Connector Wire
