SAFETY INSTRUCTIONS – HEAT SEALING EQUIPMENT

A. Protection against hazards arising from the electrical equipment

1. Safety warnings and instructions in the operators instruction sheets and

attached to the machine should be followed with care.

2. The equipment has an earthed power cable with integral 5 amp plug to

BS 1363/A fitted with a 5 amp fuse. The panel mounted fuse holder on

the machine is fitted with a 3.15A antisurge fuse for additional

protection. If either fuse fails the reason should be investigated and the

machine inspected and tested to ensure that there are no causative

faults. Higher value fuses must not be used, as they do not provide the

required level of protection.

3. Ensure that the power is switched off and the cable plug is removed

from the supply outlet before any servicing is undertaken on the

product.

4. Increased user safety can be achieved if a residual current device

(RCD) is used in the supply circuit to the heat sealer. This applies

particularly in damp conditions but the equipment must not be allowed

to get wet, either from sealing liquids, cleaning or inclement weather.

Only specially designed water resistant sealers should be used in

these circumstances. Electrical components and internal wiring, unlike

the element assembly, are not all protected by the low voltage safety

transformer, which powers the element.

5. Switch off the power supply when the machine is not attended.

6. The equipment should be regularly serviced and subjected to Portable

Appliance Test procedures in accordance with the Health and Safety

Electricity At Work regulations 1989.

7. It is essential that only approved spares be used for servicing this

equipment. Incorrect element wire can result in excessive electrical

load on internal components, which can lead, to malfunction and

failure.

Note

Hulme Martin Heat Sealing equipment satisfies the Health and Safety

requirements of the Electrical Equipment (Safety) Regulations 1994, CE Low

Voltage Directive 2006/95/EC

B. Protection against non electrical hazards

1. The equipment is designed to be operated on a flat, level surface to

ensure machine stability. In the case of chain operated machines, the

equipment should be securely screwed or clamped to the workbench

using the flanges provided, to avoid dislodging the machine when the

pedal is depressed.

2. Heat sealing machines must not be used for packing flammable or

explosive materials unless specifically modified to do so.

3. When sealing PVC and some other plastic films, which may produce

potentially harmful fumes, adequate airflow ventilation or extraction

may be required.

4. The heating element and jaws can become hot during sealing and

adequate cooling time must be allowed before touching these parts of

the machine.

5. Care should be taken on machines fitted with cutting knives that the

blade is moved to a safe position before attempting to reach between

the jaws. On hand operated machines, which are pivoted at one end of

the pressure bar the knife will slide towards the pivot point when the

pressure bar is lifted. For safety ensure that the blade is positioned at

the pivot end before lifting the pressure bar.

6. The heating cycle on impulse sealers is controlled by a timer allowing a

maximum heating time of 4 seconds. If the timer indicator light does

not go out at the selected time and heating continues, switch off the

power immediately and investigate the fault after removal or

disconnection of the element.

7. Repeated operation of the machine without sufficient cooling time

between cycles can cause accumulative heat build up in the element

resulting in poor seals, damaged elements and excessive temperatures

8. Ensure that hands and fingers are clear of the pressure bar before

actuating the foot pedal. The element will not operate until the

pressure bar is fully closed but some discomfort will result from the

pressure applied manually or by solenoid operated units.

IMPULSE SEALING EQUIPMENT

To ensure that satisfactory sealing performance is achieved and that

service life of consumable spares (such as element wire, Teflon and

rubber pressure pads) are maximised, it is necessary to understand the

operating principles of this type of equipment.

1. To adjust the heat setting for a particular thickness of material, the

power output is not varied, and varying the length of time that the

current passed through the element resistance wire effects adjustment.

The timer control allows infinitely variable time adjustment up to a

maximum of around 4 seconds.

2. When the red heating indicator light goes out the temperature has

reached its maximum and the polythene is molten to effect the weld. It

is important that before allowing the jaws to open for removal of the

polythene a short cooling time is allowed to enable the polythene to

solidify and to regain its original strength. On machines fitted with a

dual timer control, the cooling time can be pre set but on standard

machines with simple heating time control, the operator should allow

sufficient time for cooling before releasing the jaws. Depending on

material thickness a cooling time of 1 to 7 seconds is usually sufficient.

3. To complete the seal in the minimum possible time considerable power

is applied to the element for the short duration of the welding cycle.

The instantaneous temperature reached during the brief cycle is very

high, but close contact of the rubber pressure pad removes excess

temperature and prevents deterioration of the thin Teflon barrier tape.

4. It follows that if the pressure bar is released before the temperature

reduces to a level that the Teflon can withstand, it will deteriorate

rapidly and require premature replacement.

5. For this reason adequate cooling allowance is critical to the service life

of the Teflon. Although capable of withstanding up to 20,000 seals

before replacement, insufficient cooling time can cause burning within a

very short period.

6. If the Teflon is not replaced when showing signs of wear, the polythene

will stick and seal quality will deteriorate. Also the rubber pressure pad

will start to wear and if this is allowed to continue to the stage where

the surface of the pad is burnt and uneven, the resulting ‘air gap’

between the pad and element will reduce heat transfer and cause

further rapid deterioration of the Teflon. Excessive burning will

eventually result also in the element wire requiring replacement.

7. To avoid this ‘ vicious circle’ always operate the machine at the

minimum heat setting consistent with satisfactory seal quality. Allow

sufficient cooling time between each successive seal. When sealing

repetitively at high frequency reduce the heating time from its original

setting to compensate for residual heat build up in the element.

8. The micro switch is set to avoid application of power to the element

until the rubber pad is fully aligned and pressed closely to the Teflon to

allow the necessary heat transfer. The rubber pressure pad is

sufficiently pliable to accommodate several thickness’ of polythene, but

accidental closure onto thicker objects or attempting to seal bubble

pack material and heavy paper laminate gusseted materials will cause

deterioration of the Teflon for the reasons explained previously.

9. The rubber pressure pad, and element wire strip are easily replaceable,

but care in operating and maintenance of the Teflon barrier tape can

extend the service interval before element reconditioning becomes

necessary.

10. If the machine fails to seal, but the on off switch and indicator lights

show that the power and timer circuits are operating correctly, unplug

the element and check the condition of the resistance wire and Teflon.

Simple replacement of these low cost consumable spares will normally

restore the full performance of the equipment.

HM3000CDM POLYTHENE HEAT SEALER

OPERATING INSTRUCTIONS

General

Before connecting the machine to the electricity supply, check the operating

voltage on the name plate attached to the base of the machine.

The wires in the mains lead are coloured in accordance with the following

code:

Green & Yellow Earth

Blue Neutral

Brown Live

Ensure that the machine is correctly earthed and connected to the mains

supply with a 5 amp fused plug.

The heating element operates at a reduced safety voltage and the machine

has its own 3.15 amp internal fuse, accessible at the rear of the body.

Installati n

For transportation purposes the black handle has been fitted to the upper arm

in the reverse position. Before operating the machine this handle should be

fitted to the correct position.

Operating Instructi ns

Switch on the machine using the amber on/off switch on the side of the

machine. Check that the switch lights up to indicate that the machine is

powered.

The HM3000CDM impulse sealer is fitted with a dual electronic timer

controlling the heating and cooling cycles. When sufficient pressure is applied

to the pressure bar, the audible ‘click’ of the microswitch and the illumination

of the red LED indicator lights will confirm that the machine is correctly

adjusted and that power is being applied to heat up the element.

The heating time is variable between 0 and 3.5 seconds using the external

control knob. The cooling cycle is also adjustable to allow a sufficient cooling

time before the pressure bar is released.

Once the pressure bar has been depressed, the magnet will hold the bar

down until both neon lights go out. This should prevent the possibility of

insufficient cooling which can result in premature wear of the teflon barrier

tape and other consumable spares.

To extend the service life of the consumable items, always operate at the

minimum setting consistent with good seals and allow adequate cooling time

before removal of the bag.

Setting the Heating Time

Switch on the machine and set the timer control to position No. 2. Place the

polythene bag between the jaws and depress the upper jaw to the preset stop

point. The timer light will illuminate for a period of approximately one second.

Allow a further two seconds to cool before releasing the pressure from the

sealed bag. Examine the seal and progressively increase the heating and

cooling time until satisfactory seal strength is achieved.

Maintenance

The complete element assembly can be unplugged (without tools) from the

machine body so that it can be replaced with a new or reconditioned unit.

Removal of the Teflon barrier tape from the displaced element enables the

wire to be inspected and replaced if kinked or damaged. When rewiring the

element, ensure that the wire passes over the pins, down through the hole at

each end of the bar and up through the contact pin hole. Secure one end with

the nut and washer and tension the wire strip before tightening the remaining

nut. This ensures that any excess wire is on the top of the element. It is

important that this excess is removed to avoid any risk of a short circuit to the

metal body that can result in damage to the timer circuit.

To replace the pressure pad, fit approximately 30mm at each end of the

pressure bar and work the pad into the gap working towards the centre.

SPARES

The following consumable spares will enable the machine to be serviced as

required.

300211 Element Assembly complete each

300203 Teflon Barrier Tape pkt 5

300205 Rubber Pressure Pad each

300204 Underwire Insulating tape pkt 5

300206 Resistance wire strips pkt 5

490 Cutter blades pkt 10

445 Safety cutter Assembly each

When ordering spares please quote the serial number of the machine as

printed on the plate on the base of the machine. If special modifications such

as wide seal elements have been fitted to the machine ensure that the spares

department are informed when ordering these parts.

Spares Items F r 3000

Element Bar Assy 300211

Teflon Barrier Tape

300203

Element Wire Strip

300206

Insulation Tape 300204

Soft Rubber Pad 300205

Black Neoprene Pad

300265

Safety Cutter Assy

445

Cutter Blades 490

Table des matières

Autres manuels HM Electronics Food Saver

HM Electronics

HM Electronics HM2950 Manuel utilisateur

Manuels Food Saver populaires d'autres marques

Sonics

Sonics T202WD Manuel utilisateur

ABGENE

ABGENE ALPS 50V Manuel utilisateur

Teknika

Teknika MUL-331 Manuel utilisateur

MELAG

MELAG MELAseal 200 Manuel utilisateur

FoodSaver

FoodSaver FS1000 Series Manuel utilisateur

Thermopatch

Thermopatch NL-30 Manuel utilisateur

Signode

Signode B-250 Mode d’emploi

AmeriVacS

AmeriVacS AVS-20 Manuel utilisateur

FoodSaver

FoodSaver V1085 Manuel utilisateur

Deni

Deni Freshlock 1831 Manuel utilisateur

CASO DESIGN

CASO DESIGN VC150 Instructions d'installation

Atmovac

Atmovac Santa Ana Manuel utilisateur

WAAGE

WAAGE SV-FOOD Manuel

VacuWare

VacuWare Fresh Manuel

Melissa

Melissa 16310179 Manuel utilisateur

Heinner

Heinner HAV-130WH Manuel utilisateur

NUTRICHEF

NUTRICHEF PKVS50STS Manuel utilisateur

U-Line

U-Line H-57 Mode d’emploi
