Hisense H5507 Manuel utilisateur
For usage in Mexico , operation of this equipment is
subject to the following two conditions : 1 ) it is possible
that this device doesn’t cause any detrimental interference
and 2 ) this device must take any kind of interference ,
including that which may cause its malfunctioning.
NOTE
English
ES-A164908
Copyright Statement
© 2017 Hisense Company Ltd. All Rights Reserved.
All material in this User Manual is the property of Hisense Company Ltd. and its subsidiaries, and is protected under
US, CANADA, MEXICO and International copyright and/or other intellectual property laws. Reproduction or transmission
of the materials, in whole or in part, in any manner, electronic, print, or otherwise, without the prior written consent of
Hisense Company Ltd. is a violation of Hisense Company Ltd. rights under the aforementioned laws.
No part of this publication may be stored, reproduced, transmitted or distributed, in whole or in part, in any manner,
electronic or otherwise, whether or not for a charge or other or no consideration, without the prior written permission of
Hisense Company Ltd.
Requests for permission to store, reproduce, transmit or distribute materials may be made to one of the following
addresses:
USA:
Hisense USA Corporation
PO Box 3289
Suwanee, GA 30024
CANADA: Hisense Canada Co., Ltd,
2283 Argentia Road, Unit 16
Mississauga, ON, Canada, L5N 5Z2
MEXICO: Hisense Mexico S. de R.L. de C.V.
Blvd. Miguel de Cervantes Saavedra No 301
Torre Norte Piso 2, Col. Ampliación Granada
Miguel Hidalgo, Ciudad de México, C.P. 11520
Hisense, and any and all other Hisense product names, logo’s, slogans or marks are registered trademarks of Hisense
Company Ltd. and its subsidiaries. All other trademarks are the property of their respective holders.
Disclaimer Page
**Notwithstanding anything to the contrary, including in any or all descriptions, representations, statements or other
communications related to this Hisense device (hereinafter “Device”) made in any form whatsoever and at any time, some
or all of the pre-installed, or subsequently installed Application Services may not be available or capable of functioning
as intended by the provider of the Application Services in any or all usage areas for reasons outside of Hisense’s control,
including but not limited to, Internet access, local service limitations, etc. Any purchase or use of the Device, including
any Application Services, is purely at the user’s risk. Application Services are provided on an as-available basis without
warranties of any kind, either expressed or implied, that the Application Service will be uninterrupted or error-free,
including but not limited to vagaries of weather, disruption of Service, acts of God, warranties of title, local or regional
limitations, no infringement, NOR IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. No advice or information given by Hisense, providers, affiliates, or contractors or their respective employees
shall create such a warranty. Hisense specifically disclaims responsibility for any or all Application Services from
functioning at any time, and by purchasing the Device, you accept such disclaimer without any claim on Hisense. You are
solely responsible for providing an active and working connection to the Internet, along with any and all hardware and/or
software necessary to use the Hisense Device as intended.
Disclaimer:
Images throughout this document are for illustrative purposes only and may differ from the actual product.
1
Table of Contents
Connecting Devices to your TV ..............................................................................3
Connecting an antenna, cable set-top box or satellite receiver ...........................................3
Connecting an AV device with a composite video cable......................................................3
Connecting an AV device with a component video cable ....................................................4
Connecting an AV device with an HDMI cable..................................................................... 4
Connecting headphones......................................................................................................5
Connecting speakers (or other audio receivers) .................................................................5
Connecting a digital sound bar to use ARC (Audio Return Channel) .................................. 6
Connecting Your TV to a Wired or Wireless Network .............................................7
Connecting to a Wireless network ....................................................................................... 7
Connecting to a Wired (Ethernet) network...........................................................................7
Using Your TV Remote Control .................................................................................9
Shortcuts Instructions .............................................................................................11
Completing the First-Time Setup Menu..................................................................12
Basic and Advanced TV Settings ...........................................................................14
Accessing the Quick Setup Menu......................................................................................14
Picture Menu......................................................................................................................14
Sound Menu ......................................................................................................................15
Channel Menu ...................................................................................................................15
Network Menu ...................................................................................................................15
System Menu.....................................................................................................................16
About TV Menu ................................................................................................................. 17
2
Table of Contents
Parental Controls .....................................................................................................18
Getting familiar with the Home screen...................................................................20
Live TV .....................................................................................................................21
Viewing channel information..............................................................................................21
Viewing a channel list ........................................................................................................ 21
Creating a 'Favorites' list ..................................................................................................21
Viewing your ‘Favorites’ list ...............................................................................................21
Apps...........................................................................................................................22
Apps ..................................................................................................................................22
Customizing the name of your TV ..................................................................................... 23
Media .........................................................................................................................23
Panels that appear on the Media screen ...........................................................................23
File formats that are supported..........................................................................................23
Browsing content ...............................................................................................................23
Viewing Pictures as a slideshow........................................................................................23
Viewing video.....................................................................................................................24
Mirroring content from your device to the TV ......................................................24
Software updates for your TV ................................................................................25
Quick Problem-Solving Tips....................................................................................26
3
Connecting Devices to your TV
Connecting an antenna, cable set-top box or satellite receiver
To connect an antenna,cable set-top box or satellite receiver:
Connecting an AV device with a composite video cable (yellow/red/white)
You have several options for connecting your TV to different devices. The method in which you connect will be based upon the type
of cables you have and the available outputs on your device.
Connecting Devices to your TV
1. Connect one end of a coaxial cable (not included) to the [RF OUT] jack on the antenna, cable or satellite box. If you are using an
antenna with twin-lead cable, you may need a 300-75 Ohm adapter (not provided) to connect it to the back of your TV. Likewise,
if you are using several antennas, you may need a combiner (not provided).
2. Connect the other end of the cable to the [ANT/CABLE] jack on the side of TV.
3. Using your remote, press the [INPUT] button and select TV as the input source.
To connect an AV device with a composite video cable (not provided):
1. Use the audio and video cables to connect the composite video/audio jacks (of the external AV device) to the [AV IN] jacks
of the TV. (Video = yellow, Audio Left = white, and Audio Right = red).
2. Plug the connected devices into the AV connectors on the TV before switching it on.
3. Using your remote, press the [INPUT] button and select AV as the input source.
Figure 1. Antenna, cable set-top box or satellite receiver to the TV
Figure 2. AV device with a composite video cable
or ANT OUT
Cable Set top box
RF Out
EXTERNAL DEVICETV JACK
TV JACK
ANT/CABLE
(not included)
(not included)
(not included)
DVD Player/Recorder
Video
Camera
EXTERNAL DEVICES
Set-top box
Satellite Receiver
Satellite
antenna
cable
VCR
AV OUT
Video
L
R
White(L)White(L)
Yellow(Video)Yellow or Green(Video)
Red(R)Red(R)
Audio Cable
L R
AV IN
VIDEO AUDIO
Y PBPR
COMPONENT IN
4
Connecting Devices to your TV
DVD Player/Recorder
Video
Camera
EXTERNAL DEVICES
Set-top box
Satellite Receiver
Satellite
antenna
cable
VCR
White(L) White(L)
Red(R) Red(R)
Audio Cable
Component Cable
Component
R
L
PR
PB
Y
Red(PR/CR)Red(PR/CR)
Blue(PB/CB) Blue(PB/CB)
Green(Y) Green(Y)
HDMI
HDMI
EXTERNAL DEVICES
DVD
Set-top Box
HDMI Cable
NOTES
•Because the HDMI connector provides video and audio signals, it is not necessary to connect an audio cable.
•The HDMI cable will not supplied with the product.
•We strongly recommend to use HDMI Cable with 2 cores as shown in the figure.
NOTE
One AV device can be connected to the TV using a component video or composite video cable.
TV JACK
TV JACK
Connecting an AV device with a component video cable (red/blue/green)
To connect an AV device with a component cable (which is red/blue/green):
1. Use a component video cable (not provided) to connect the component output jacks of the external device to the YPBPR jacks
for the TV. Use an audio cable to connect the component audio jacks of the external device to the TV AUDIO (L/R) jacks.
2. Plug the connected devices into the YPBPR and L/R ports on the TV before switching it on.
3. Using your remote, press the [INPUT] button and select COMPONENT as the input source.
Figure 3. AV device with a component video cable
Connecting an AV device with an HDMI cable
This type of connection supports digital connections between HDMI-enabled AV devices such as a Personal Video Recorder (PVR),
DVD, Blu-Ray, AV receiver and digital devices. In addition, some devices (such as a PVR or DVD player) require an HDMI signal to
be set to Output in the settings of the device.
Please refer to the User Manual that came with your device for step-by-step instructions.
To connect an AV device with an HDMI cable:
1. Use an HDMI cable to connect the [HDMI] output port of the AV device to the [HDMI] jack of the TV.
2. Plug the connected devices into the power socket.
3. Using your remote, press the [INPUT] button and select the corresponding HDMI input.
Figure 4. AV device with an HDMI cable
(not included)
(not included)
L R
AV IN
VIDEO AUDIO
Y PBPR
COMPONENT IN
5
Connecting Devices to your TV
EXTERNAL DEVICES
EXTERNAL DEVICES
Powerless
Bass Speaker
Speaker
Audio Amplier
Digital Sound Bar
DIGITAL
AUDIO OUT
Connecting speakers (or other audio receivers)
To connect speakers (or other audio receivers) with an audio cable:
Connecting headphones
1. Use an audio cable (not provided) to connect the [DIGITAL AUDIO IN] jack of the audio receiver device to the [DIGITAL AUDIO
OUT] jack of the TV. Another option is to use an RCA Y-cable (1/8”-stereo mini to L/R phono) to connect an analog sound
system to the [AUDIO OUT] jack of the TV.
2. Plug the connected devices into the main power socket before switching on the TV.
You can connect headphones to the [AUDIO OUT] port on your TV. While the headphone is connected, the sound from the built-in
speakers will be disabled.
Figure 5. Headphones to the TV
Figure 6. Audio receiver with audio cable
TV JACK
Audio Cable
(not included)
TV JACKS
White(L)
Red(R)
Audio Cable
(not included)
Audio Cable
(not included)
If you prefer to use Audio Return Channel, then follow the steps on the next page under 'Connecting a digital sound bar to
use Audio Return Channel'.
NOTE
• When a digital audio system is connected to the [DIGITAL AUDIO OUT]jack, decrease the TV and system volume.
• 5.1 CH (channel) audio is available when the TV is connected to an external device that supports a 5.1 channel surround sound
• You can receive 5.1 channel audio in one of two ways. The first way is to connect the [DIGITAL AUDIO OUT] jack from the
device to the Amplifier. The second way is to connect the [DIGITAL AUDIO OUT] jack on the back of the TV to the [Optical]
port on the Amplifier. After you’ve completed one of the two methods then be sure to go into the Advanced Audio Settings of the
TV and select RAW to receive the 5.1 channel audio. You will need to also go into the sound or audio settings of your device to
ensure it is set to 5.1 Channel output. It may read ‘Bitstream’, ‘RAW’ or ‘Digital’.
NOTES
AUDIO
OUT
AUDIO
OUT
6
Connecting Devices to your TV
Connecting a digital sound bar to use ARC (Audio Return Channel)
If you'd like to use the Audio Return Channel (ARC) feature to have sound sent from the TV back down an HDMI cable to a digital
sound bar, then you will need to connect the cable to the [HDMI (ARC)] port. By using this feature, you will also be able to control
the sound bar with your TV remote instead of having to use multiple remotes for each device.
Only digital sound bars that require a wired connection are compatible with the Smart TV.
To connect a digital sound bar with an HDMI cable:
1. Connect the cable that’s attached to the soundbar to the HDMI (ARC) port on the TV.
2. Turn on the sound bar by pressing the Power button.
3. Press the [Quick Setup menu] button on your remote and go to System > CEC Function
4. Turn on the CEC Control setting.
5. Select Sound > Advance Audio Settings > TV Speaker & ARC and select ARC First.
6. If the device has an ‘Input Selector’ feature then make sure to change it to ‘TV’.
EXTERNAL DEVICES
Digital Sound Bar
HDMI
Figure 7. Digital Sound Bar to the HDMI (ARC) port
TV JACK
HDMI Cable
(not included)
NOTE
Table des matières
Autres manuels Hisense TV
Hisense
Hisense 32A5KQ Manuel utilisateur
Hisense
Hisense 50K610GW Manuel utilisateur
Hisense
Hisense Roku TV 40H4G Manuel utilisateur
Hisense
Hisense 75P7 Manuel utilisateur
Hisense
Hisense LCD3201EU Manuel utilisateur
Hisense
Hisense TC24FS2H Manuel utilisateur
Hisense
Hisense GM642XF Manuel utilisateur
Hisense
Hisense A87H Manuel utilisateur
Hisense
Hisense 24D33 Manuel utilisateur
Hisense
Hisense 55U8HAU Manuel utilisateur
Hisense
Hisense 32D33 Manuel utilisateur
Hisense
Hisense N3000 Manuel utilisateur
Hisense
Hisense 85Q8 Manuel utilisateur
Hisense
Hisense 55U7HAU Manuel utilisateur
Hisense
Hisense 50K360G Manuel d'utilisation
Hisense
Hisense HE32M2160HTS Manuel utilisateur
Hisense
Hisense 32M2160 Manuel utilisateur
Hisense
Hisense 40D50 Manuel utilisateur
Hisense
Hisense HL55V89PZ Manuel utilisateur
Hisense
Hisense K300 Series Manuel utilisateur
Manuels TV populaires d'autres marques
Philips
Philips Colour Television Manuel utilisateur
Toshiba
Toshiba 27A10 Manuel utilisateur
Philips
Philips 42PF9630A/37 Manuel utilisateur
Hitachi
Hitachi 32FX48B Manuel utilisateur
DAEWOO ELECTRONICS
DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur
Changhong Electric
Changhong Electric uhd55b6000is Manuel utilisateur
