Hisense RR220D4ARF Instructions de montage

RR220D4ARF

RR220D4ABF

RR220D4ADF

RR220D4AYF

Contents

2For your safety and correct usagebefore installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to make sure that all people using the appliance are thoroughly familiar with its operation and safety features. Save these instructions and be sure that they remain with the appliance if it is moved or sold, so that anyone using it throughout its life, will be properly informed on its usage and safety notices.For the safety of life and property, keep the precautions of these user's instructions as the manufacturer is not , responsible for damages caused by omission.Hisense RefrigeratorSafety for children and othersAccording to EN standardAccording to IEC standardThis appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. Safety and warning information.......2Description of the appliance ...........8Control panel...................................8First use an installation....................9Daily use.........................................11

Helpful hints and tips.......................12

Cleaning and care............................13What to do if... .................................14Disposal of the appliance.................15who are vulnerable people

3Hisense RefrigeratorKeep all packaging away from children as there is risk of suffocation.If you are discarding the appliance, pull the plug out of the socket, cut the connection cable (as close to the appliance as you can) and remove the door to prevent children playing from suffering an electric shock or from closing themselves inside it.If this appliance, featuring a magnetic door seals, is to replace an older appliance having a spring lock (latch) on the door or lid, be sure to make the spring lock unusable before you discard the old appliance. This will prevent it from becoming a death trap for a child.

General safety

WARNING —This appliance is intended to be used in household and similar applications such as-staff kitchen areas in shops, offices and other working environments;-farm houses and by clients in hotels, motels and other residential type environments;-bed and breakfast type environments; -catering and similar non-retail applications.WARNING — Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.WARNING — If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.WARNING — Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.WARNING — Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.WARNING — Do not damage the refrigerant circuit.WARNING — Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

4Hisense RefrigeratorWARNING — The refrigerant and insulation blowing gas are flammable. When disposing of the appliance, do so only at an authorized waste disposal centre. Do not expose to flame.WARNING —When positioning the appliance, ensure the supply cord is not trapped or damaged.WARNING —Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.RefrigerantThe refrigerant isobutene (R600a) is contained within the refrigerant circuit of the appliance, a natural gas with a high level of environmental compatibility, which is nevertheless flammable. During transportation and installation of the appliance, ensure that none of the components of the refrigerant circuit becomes damaged.The refrigerant (R600a) is flammable.If the refrigerant circuit should be damaged:-Avoid opening flames and sources of ignition.-Thoroughly ventilate the room in which the appliance is situated.WARNING — Refrigerators contain refrigerant andgases in the insulation. Refrigerant and gases must be disposed of professionally as they may cause eye injuries or ignition. Ensure that tubing of the refrigerant circuit is not damage prior to proper disposal.Replacing the illuminating lampsWARNING—The illuminating lamps must not be replaced by the user! If the illuminating lamps is damaged, contact the customer helpline for assistance.This warning is only for refrigerators that contain illuminating lamps.WARNING Risk of fire / flammable materials

5Hisense RefrigeratorDaily useDo not store flammable gass or liquids in the appliance,There is a risk of an explosion.Do not operate any electrical appliances in the appliance(e.g.electric ice cream makers,mixers etc.).When unplugging always pull the plug from the mains socket,do not pull on the cable.Do not place hot items near the plastic components of this appliance.

Electrical safety

1.The power cord must not be lengthened.2. Make sure that the power plug is not crushed or damaged. A crushed or damaged power plug may overheat and cause a fire.3. Make sure that you can access the main plug of the appliance.4. Do not pull the main cable.5. If the power plug socket is loose, do not insert the power plug. There is a risk of electric shock or fire.6.You must not operate the appliance without the interior lighting lamp cover.7.The fridge is only applied with power supply of single phase alternating current of 220~240V/50Hz. If fluctuation of voltage in the district of user is so large that the voltage exceeds the above scope, for safety sake, be sure to apply A.C. Automatic voltage regulator of more than 350W to the fridge. The fridge must employ a special power socket instead of common one with other electric appliances. Its plug must match the socket with ground wire.It is dangerous to alter the specifications or modify this product in any way. Any damage to the cord may cause a shortcircuit, fire, and/or electric shock.

This refrigerating appliance is not intended to be used as a

built-in appliance.

Note: Children aged from 3 to 8 years are allowed to load and

unload refrigerating appliances.(This clause applies only to the

EU region.)

Description of the appliance 1. Freezer chamber2. Ice tray(in Freezer chamber )3.!"#$%"&&'%()"*

4. Lamp cover5. LED light(in the lamp cover)6. Control knob7. Storage shelves8. Wine rack9. Crisper cover10.Crisper11.Door12. Door racks13. Adjustable feetView of the applianceControl panel Note: Due to continual modification of our products, your refrigerator may be slightly different from this instruction Manual, but its functions and usage methods remain the same.Starting up and temperature regulationInsert the plug of the connection lead into the plug socket with a protective grounding contact. When the refrigerator compartment door is opened, the internal lighting is switched on.The temperature selector knob is located on the back side of the refrigerator compartment.Setting “off” means no coolingTurn the temperature control to “off” positionstops the cooling cycle,but does not shut off the power of the refrigerator.Setting “1” meansHighest temperature, warmest setting.Setting “7” (end-stop) meansLowest temperature, coldest setting.Important! High ambient temperatures (e.g. on hot summer days) and a cold setting (position 6 to 7) may cause the compressor to run continuously or even non-stop!Reason: When the ambient temperature is high, the compressor must run continuously to maintain the low temperature in the appliance. Warning! Don’t try to repair the applianceand change the LED light yourself. If the LED light can’t work, please contact your specialist dealer or your local Customer Service Center to change it.Important! Normally, we advise you select a setting of 2, 3 or 4; if you want the temperature higher or lower, please turn the knob to a warmer or colder setting accordingly. When you turn the knob to a colder setting, this can lead to the more energy efficiency. Otherwise, it would result the consumption of energy.123456789101112138

Note: To get the best energy efficiency of this product, please place all shelves,drawers on

their original position as the illustration above.

Note: High temperature setting will accelerate

food waste.

• For optimum food preservation, a medium

setting is generally the most suitable.

there to be 50-70mm separating the back of the First use an installation lower base cover Maximum performance and safety are guaranteed by maintaining the correct indoor temperature for the class of unit concerned, as specified on the rating plate.This appliance performs well from N to ST. The appliance may not work properly if it is left for a longer period at a temperature above or below the indicated range.Important! It is necessary to have good ventilation around the fridge to allow for the dissipation of heat, high efficiency an low sufficiently cleared space should be available around the fridge. It is advisable for fridge to the wall at least 100mm of space on its two sides, a height of over 100mm from its top and a clear space in front to allow the doors to open 160°.Appliances must not be exposed to rain. Sufficient air must be allowed to circulate in the low rear section of the appliance, as poor air circulation can affect performance. Built-in appliances should be positioned away from heat sources such as heaters and direct sunlight.screw provided in a plastic bag with your appliance, you can install these accessories according to the following procedure.Note:There is no need to install these accessories under normal usage.Only under the extreme circumstances, cabinet empty while load on door with total mass of 15 kg and opening the door about 90 degree ,this refrigerator may take risk of tipping. Then rubber supporting pad should be fastened to the lower base cover to steady this appliance. Installing the rubber supporting Before using the appliance for the first time, wash the interior and all internal accessories with lukewarm water and meutral soap in order to remove the typical smell of a brand new product, then dry thoroughly.Installation PositioningWarning! Before installing, read the instruction carefully for your safety and the correct operation of appliance. Position the appliance away from sources of heat such as stoves, radiators, direct sunlight, etc.Cleaning before use1.Tilt appliance to find screw hole on the left of lower base cover. 140°980mm

664mm978mm

50-70mm

100mm

100mm100mm9
