Hisense H299BME Manuel utilisateur
H299BME
H359BME
H299BME-WD
H359BME-WD
EN User manual 2
USER’S OPERATION MANUAL
H299BI-WD
H299BI
H359BI
H359BI-WD
H360BMI-WD
Contents
Safety and warning information…........2
Control panel.........................………....8
First use and installation.....….......…...9
Description of the appliance.........…..11
Daily use...................……….…….......13
Reversing the door………....………...16
Helpful hints and tips………...……….19
Cleaning and care……….……………20
Trouble shooting………………………22
Disposal of the appliance……………23
2
For your safety and correct usage, before installing and first
using the appliance, read this user manual carefully, including
its hints and warnings. To avoid unnecessary mistakes and
accidents, it is important to make sure that all people using the
appliance are thoroughly familiar with its
operation and safety features. Save these instructions and be
sure that they remain with the appliance if it is moved or sold,
so that anyone using it throughout its life, will be properly
informed on its usage and safety notices.
For the safety of life and property, keep the precautions of
these user's instructions as the manufacturer is not
responsible for damages caused by omission.
Hisense Refrigerator
Safety for children and otherswho are vulnerable people
According to EN standard
This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
According to IEC standard
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
3
Hisense Refrigerator
Keep all packaging away from children as there is risk of
suffocation.
If you are discarding the appliance, pull the plug out of the
socket, cut the connection cable (as close to the appliance
as you can) and remove the door to prevent children playing
from suffering an electric shock or from closing themselves
inside it.
If this appliance, featuring a magnetic door seals, is to
replace an older appliance having a spring lock (latch) on the
door or lid, be sure to make the spring lock unusable before
you discard the old appliance. This will prevent it from
becoming a death trap for a child.
General safety
WARNING —This appliance is intended to be used in
household and similar applications such as
-staff kitchen areas in shops, offices and other working
environments;
-farm houses and by clients in hotels, motels and other
residential type environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
WARNING — Do not store explosive substances such as
aerosol cans with a flammable propellant in this appliance.
WARNING — If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
WARNING — Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction.
WARNING — Do not use mechanical devices or other
means to accelerate the defrosting process, other than those
recommended by the manufacturer.
WARNING — Do not damage the refrigerant circuit.
WARNING — Do not use electrical appliances inside the
food storage compartments of the appliance, unless they are
of the type recommended by the manufacturer.
4
Hisense Refrigerator
WARNING — The refrigerant and insulation blowing gas are
flammable. When disposing of the appliance, do so only at
an authorized waste disposal centre. Do not expose to
flame.
WARNING —When positioning the appliance, ensure the
supply cord is not trapped or damaged.
WARNING —Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the appliance.
Refrigerant
The refrigerant isobutene (R600a) is contained within the
refrigerant circuit of the appliance, a natural gas with a high
level of environmental compatibility, which is nevertheless
flammable. During transportation and installation of the
appliance, ensure that none of the components of the
refrigerant circuit becomes damaged.
The refrigerant (R600a) is flammable.
Warning: Risk of fire
If the refrigerant circuit should be damaged:
-Avoid opening flames and sources of ignition.
-Thoroughly ventilate the room in which the appliance is
situated.
WARNING — Refrigerators contain refrigerant andgases in
the insulation. Refrigerant and gases must be disposed of
professionally as they may cause eye injuries or ignition.
Ensure that tubing of the refrigerant circuit is not damage
prior to proper disposal.
Replacing the illuminating lamps
WARNING—The illuminating lamps must not be replaced by
the user! If the illuminating lamps is damaged, contact the
customer helpline for assistance.
This warning is only for refrigerators that contain illuminating
lamps.
5
Hisense Refrigerator
Daily use
Do not store flammable gass or liquids in the appliance,
There is a risk of an explosion.
Do not operate any electrical appliances in the appliance
(e.g.electric ice cream makers,mixers etc.).
When unplugging always pull the plug from the mains
socket,do not pull on the cable.
Do not place hot items near the plastic components of this
appliance.
Electrical safety
1.The power cord must not be lengthened.
2. Make sure that the power plug is not crushed or damaged.
A crushed or damaged power plug may overheat and cause a
fire.
3. Make sure that you can access the main plug of the
appliance.
4. Do not pull the main cable.
5. If the power plug socket is loose, do not insert the power
plug. There is a risk of electric shock or fire.
6.You must not operate the appliance without the interior
lighting lamp cover.
7.The fridge is only applied with power supply of single phase
alternating current of 220~240V/50Hz. If fluctuation of voltage
in the district of user is so large that the voltage exceeds the
above scope, for safety sake, be sure to apply A.C. Automatic
voltage regulator of more than 350W to the fridge. The fridge
must employ a special power socket instead of common one
with other electric appliances. Its plug must match the socket
with ground wire.
It is dangerous to alter the specifications or modify this
product in any way.
Any damage to the cord may cause a shortcircuit, fire, and/or
electric shock.
6
Hisense Refrigerator
Do not place food products directly against the air outlet on
the rear wall.
Store pre-packed frozen food in accordance with the frozen
food manufacture’s instructions.
The appliances manufactures storage recommendations
should be strictly adhered to.Refer to relrelevant instructions
for storage.
Do not place carbonated or fizzy drinks in the freeze
compartment as it creates pressure on the container,which
may cause it to explode,resulting in damage to the
appliance.
Frozen food can cause frost burns if consumed straight from
the freezer compartment.
Do not place the appliance in direct sunlight.
Keep buring candles,lamps and other items with naked
flames away from the appliance so that do not set the
appliance on fire.
The appliance is intended for keeping food stuff and/or
beverages in normal household as explained in this
instruction booklet The appliance is heavy.Care should be
taken when moving it.
Do not remove nor touch items from the freezer
compartment if your hands are damp/wet,as this could cause
skin abrasions or frost/freezer burns.
Never use the base,drawers, doors etc. to stand on or as
supports.
Frozen food must not be refrozen once it has been thawed
out.
Do not consume ice popsicles or ice cubes straight from
the freezer as this can cause freezer burn to the mouth
and lips.
To avoid items falling and causing injury or damage to
the appliance, do not overload the door racks or put too
much food in the crisper drawers.
caution!
Care and cleaning
7
Hisense Refrigerator
Adequate air circulation should be around the appliance,
lacking this leads to overheating. To achieve sufficient
ventilation, follow the instructions relevant to installation.
Wherever possible the back of the product should not be too
close to a wall to avoid touching or catching warm parts
(compressor, condenser) to prevent the risk of a fire, follow
the instructions relevant to installation.
The appliance must not be locate close to radiators or
cookers.
Make sure that the mains plug is accessible after the
installation of the appliance.
Service
Any electrical work required to do the servicing of the
appliance should be carried out by qualified electrician or
competent person.
This product must be serviced by an authorized Service
Center, and only genuine spare parts must be used.
1)If the appliance is Frost Free.
2)If the appliance contains freezer compartment.
Installation Important!
For electrical connection carefully, follow the instructions
given in this manual.
Unpack the appliance and check if there are damages on it.
Do not connect the appliance if it is damaged. Report
possible damages immediately to the place you bought it. In
this case retain packing.
It is advisable to wait at least four hours before connecting
the appliance to allow the oil to flow back in the compressor.
Before maintenance, switch off the appliance and disconnect
the mains plug from the mains socket.
Do not clean the appliance with metal objects, steam
cleaner, ethereal oils, organic solvents or abrasive
cleansers.
Do not use sharp objects to remove frost from the appliance.
Use a plastic scraper.
8
Hisense Refrigerator
Control panel
Starting up and temperature regulation
The temperature selector knob is located
on the top of the refrigerator compartment.
Setting 0 means:
Off.
Clockwise rotate the knob to turn on the
appliance
Setting 1 means:
Highest temperature, warmest setting.
Setting 7 (end-stop) means:
Lowest temperature, coldest setting.
Normally we advise you select setting of 3 or
4, if you want the temperature warmer or
colder please turn the knob to lower or
higher setting accordingly.
Important! High ambient temperatures (e.g.
on hot summer days) and a cold setting
(position 6 to 7) may cause the compressor
to run continuously or even non-stop!
Reason: when the ambient temperature is
high, the compressor must run continuously
to maintain the low temperature in the
appliance.
Insert the plug of the connection lead into
the plug socket with protective earth
contact. When the refrigerator
compartment door is opened, the internal
lighting is switched on.
First use and installation
Cleaning before use
Before using the appliance for the first
time, wash the interior and all internal
accessories with lukewarm water and
some neutral soap in order to remove the
typical smell of a brand new product, then
dry thoroughly.
Installation Positioning
Warning! Before installing, read the
instructions carefully for your safety
and the correct operation of the appliance.
Position the appliance away from sources
of heat such as stoves, radiators, direct
sunlight, etc.
This performs well in . The
appliance may not work properly if it is left
for a longer period at a temperature above
or below the indicated range.
appliance ST
Maximum performance and safety are
guaranteed by maintaining the correct
indoor temperature for the class of unit
concerned, as specified on the rating
plate.
Important!
For this
reason, a space should
be available around the . It is
It is necessary to have good
ventilation around the refrigerator to allow
for the dissipation of heat, high efficiency
and low power consumption.
sufficiently cleared
refrigerator
advisable for there to be mm separating 50-70
the back of the to the wall at
least 100mm of space on its two
of over 1 00mm from its top and a
clear space in front to allow the doors to
open 145°.
refrigerator
sides, a
height
100mm
50-70mm
100mm 100mm
W
D
D1
W1
145
≥100 ≥100
WW1 DD1
550 462 552 1072
Relevant information(Constant/mm)
Appliances must not be exposed to rain.
Sufficient air must be allowed to circulate
in the lower rear section of the appliance,
as poor air circulation can affect perfor-
mance. Built-in appliances should be
positioned away from heat sources such
as heaters and direct sunlight.
Climate class Ambient temperature
SN
N
ST
T
+10°C to +32°C
+16°C to +32°C
+16°C to +38°C
+16°C to +43°C
Hisense Refrigerator
9
Hisense Refrigerator
It is only applicable to H360BMI-WD
Installing the rubber supporting
s crew provided in a plastic bag with your
appliance, you can install these accessories
according to the following procedure.
lo wer base cover
Note:
There is no need to install these accessories
under normal usage. Only under the extreme
circumstances, cabinet empty while load on
door with total mass of 16 kg and opening the
door about 90 degree , this refrigerator may
take risk of tipping. Then rubber supporting
pad should be fastened to the lower base
cover to steady this appliance.
1. Tilt appliance to find screw hole on the
left of lower base cover.
cro ss
screwdrawer
rubber supporting pad
scr ew
2. Put screw into the hole of rubber
supporting pad.
3.Make screw in alignment with the hole on
lower base cover . Fasten rubber
supporting pad to the base cover firmly by
a cross screw driver (self-provided).
Leveling
Electrical connection
The appliance should be level in order to
eliminate vibration. we recommend that you
level the appliance by the following steps.
1.Roll the refrigerator into place.
2.turn the adjustable feet (with your fingers
or a suitable screw driver) until it touches
the floor.
3.Tilt back the top backwards for about 10-
15mm or 0.5°by turn the feet. This will allow
the doors to self-close providing a consistent
closed seal.
4.Whenever you want to move the
appliance, remember to turn the feet back
up so that the appliance can roll freely.
Reinstall the appliance when relocating.
Caution! Any electrical work required to
install this appliance should be carried out by
a qualified or personnel.authorized
Warning! This appliance must be grounded.
The manufacturer declines any liability should
these safety measures not be observed.
5°
10
Ce manuel convient aux modèles suivants
8
Table des matières
Langues :
Autres manuels Hisense Réfrigérateur
Hisense
Hisense HR6TFF534SD Instructions de montage
Hisense
Hisense H310US Instructions de montage
Hisense
Hisense RB400N4ACD Instructions de montage
Hisense
Hisense RB291D4CWF Instructions de montage
Hisense
Hisense RF200D4CSE Instructions de montage
Hisense
Hisense HRQ215N6BVD Manuel utilisateur
Hisense
Hisense HRBM417S Instructions de montage
Hisense
Hisense RB329N4AWE Instructions de montage
Hisense
Hisense HRTF326S Instructions de montage
Hisense
Hisense WMS017M6XBE Manuel utilisateur
Hisense
Hisense RS868N4ASV Instructions de montage
Hisense
Hisense BCD-543WPAZR/HC1(E) Manuel utilisateur
Hisense
Hisense RT161D4ADE Instructions de montage
Hisense
Hisense HRWC30 Instructions de montage
Hisense
Hisense RR106D4CBF Instructions de montage
Hisense
Hisense HRAF328 Instructions de montage
Hisense
Hisense RF225A3CSE Instructions de montage
Hisense
Hisense RF210N6ASE Manuel utilisateur
Hisense
Hisense RL423N4CW2 Instructions de montage
Hisense
Hisense RQ768N4ABU Instructions de montage
