HISENSED90TechnicalSpecifications CONFIDENTIAL

Technical Specifications

CDMA & GSM Dual Mode

Mobile Handset

Model: D90

Version 1.0

2008-06-03

Qingdao Hisense Communications Co., Ltd.

HISENSED90TechnicalSpecifications CONFIDENTIAL

ProprietaryInformationofHisense

Table of Contents

1. Product Introduction..............................................................................................2

2. General Features....................................................................................................2

3. Appearance...........................................................................................................2

4. Hardware Specification...........................................................................................3

5. Software Specification............................................................................................4

6. Technical Specifications..........................................................................................8

7. Accessories............................................................................................................9

8. A Complete Set of Product......................................................................................9

9. Criterion and Standard Regarding Green Environmental Protection Handset Materials10

HISENSED90TechnicalSpecifications CONFIDENTIAL

1. Product Introduction

D90 CDMA2000 1X digital mobile handset is a CDMA2000 1X digital mobile terminal

product developed by Hisense itself. D90 is based on Qualcomm QSC6020 and MTK6223

chipset and works at CDMA: 800MHz and GSM: 900/1800/1900MHz frequency bands,

D90 is also compatible with the IS-95A/B, CDMA2000 1X and GSM network environment.

D90 is a bar type handset, dual network mode, touch panel, multi-media and camera

functionsareprovided;

The feature highlights of D90 are dual network standby simultaneously, data service and

charming metal style design.

2. General Features

Product Model HS-D90

Form Factor Bar Type with built-in Antenna

Dimensions（H×W×D）113.4*54.8*17.2mm

Weight Standard Approx 120g

Appearance Color Black

Product Orientation Mid-End

Target Market Global Market

3. Appearance

This ID is only for reference, the products are subject to finally evaluated and confirmed

appearance.

ProprietaryInformationofHisense

HISENSED90TechnicalSpecifications CONFIDENTIAL

ProprietaryInformationofHisense

4. Hardware Specification

Network CDMA+GSM

Frequency Band CDMA: 800MHz

GSM: 900/1800/1900 MHz

Solution CDMA: Qualcomm QSC6020

GSM: MTK MT6223

Working Mode R-UIM

Vocoder 8K EVRC

Peak Data Rate 153.6kbps

Main Processor ARM9Processor Multi-Processor C627

ROM 256Mbits NAND for CDMA, 64Mbits for

GSM

RAM 64Mbits SDRAM+32Mbits SDRAM

Memory

Available User Memory Space TBD

Removable Memory

Card Micro SD card

Physical Dimension 2.4”(AA)

Resolution QVGA

Color Depth 256K

Type TFT

Main LCD

Touching Screen Type Yes, resistance

Sub-LCD No

Backlight Type LED

Keypad Area 23Number of Keystroke Side key 4

Keystroke Backlight Yes, blue

Sensor of Saving

Energy No

Ring Chipset No

Camera Yes,1.3M

Flash Lamp No

Infra-Red No

Bluetooth Yes, voice

Power off Clock Yes

Vibrator Motor Yes

FM No

Data Port 5 Pin Mini USB

Power Supply Port 5 Pin Mini USB

Antenna Built-in

Vehicle Power Adapter No

Indicator No

HISENSED90TechnicalSpecifications CONFIDENTIAL

ProprietaryInformationofHisense

Speaker 2 Speakers

Headset Yes, Stereo

Lanyard Hole No

Type Li-IonBattery Capacity Standard 1400mAh

Slot 3 (UIM, SIM , Micro SD card)

Charging Time <180 Minutes Subject to finally test result

Standby Time 100 Hours

Talking Time 180 Minutes

5. Software Specification

Basic Specification

Operating System REX

EnglishLanguage Others as customers’ requirements

Polish input mode (word by word)

Polish input mode (Character by character)

English

ABC

Numeral

Punctuation

Input Solutions

Handwriting and Virtual Qwerty Keypad

Copy

Paste

English Phrase

Text Editing Assistant Tools

Expression Punctuation

Contacts

Capacity 1000

VCARD Yes

Name

Phone Number 1

Phone Number 2

Home Number

Office Number

E-Mail

Website Address

Remark

Group

Content of Items

Ringtone

Group Numbers 20

Group Rings Identification Yes

HISENSED90TechnicalSpecifications CONFIDENTIAL

ProprietaryInformationofHisense

Rings Priority Individual Rings>Group Rings>Common Rings

Phone Number Length 32 digits

Extension Input P/T

By Initial Letters

By Name

By Group

Inquiry Method

Proximity Search

Delete Single EntryDelete Entries Optional Delete

Entries Copy Yes, between phone and card, card and card.

View Memory Status Yes

Calling

Voice Dialing No

IP Dialing Yes, 5

Speed Dialing Yes, 20

Name

Number

Incoming Call Display

Network

Name

Number

Outgoing Call Display

Network

Incoming Call Mute Yes

Call Restriction Yes

Hands Free Yes

Talk Time Display Yes

Talk Time Record Yes

Record Voice during Talking No

Record Voice when Standby Yes

Voice Message Yes

DTMF Dialing during Talking Yes

Pressing “answer key”Answer Mode Any key

Auto-answer by headset Yes

Call WaitingSupplementary Service

CDMA Call Forwarding

Call Waiting

Call Forwarding

GSM Network Service

Call Restriction

Dialed 100

Received 100

Call Records

Missed 100

SMS

HISENSED90TechnicalSpecifications CONFIDENTIAL

ProprietaryInformationofHisense

Inbox 300Capacity Outbox 100

Max Length English 160

Long SMS Yes

Auto Concatenate Yes

Voice Message Yes

Max 20 entriesSMS Group Sending Delivery Report

Contacts Team Group

Sending Yes

Delete Single EntrySMS Delete Optional Delete

Reserved Phrase Yes

Message Restriction Yes

PhoneDefault Memory Setting UIM Card

View Memory Status Yes

MMS No

PIM

Alarm Clock Yes, Power off Alarm Clock

Stopwatch Yes

Scheduler Yes

Notepad Yes

Calculator Yes

Calendar Yes

World Time Yes

Converter Yes

Reminding Yes

State Number Search No

Puzzle box

Tetris

Games

Gobang

Multi-Media Yes 1.3 M

Format JPG

Digital Zoom Yes

Brightness Adjustment Yes

Effect Yes

Frame No

Self Shoot Yes

Sequence mode Yes

Camera

Quality Normal/Fine/Super

Video Shoot Format Mp4, 3GP

HISENSED90TechnicalSpecifications CONFIDENTIAL

ProprietaryInformationofHisense

Size 240*192

Time According to memory space

Frame Rate Max 15fps

Brightness Yes

Focal length Yes

Audio Play Mp3, MIDI

Video Play MPEG4, 3GP

Multi-Media Player Yes

Data Service

BREW No

Modem Yes

WAP WAP 2.0

JAVA No

Display Information

Power on/off Animation Yes

Standby Time Display Yes/Optional

Provider Info. Display Yes/Optional

Static Pic 4Wallpapers Display Optional Pic BMP

Customization Interface Theme Yes

Function Display Yes

CDMA Signal Strength

GSM Signal Strength

In Talking

Keypad Lock/Phone Lock

Roaming CDMA

Roaming GSM

1X Icon

WAP Service Icon

WAP Push Icon

Micro SD card

Bluetooth

SMS

Voice Message

Profile Mode

Alarm Clock

Icon Indicating

Battery

No. of Inte

rated Rin

Tones 15

No. of Polyphonics 64

Format Mp3/MIDI

Incoming Rings

SMS Prompt

Ring tone Setting

Keystroke

HISENSED90TechnicalSpecifications CONFIDENTIAL

ProprietaryInformationofHisense

Ring tonesVolume Adjustment Receiver

Power on/off Rings On/Off

Personal Ring Yes

Group Ring Yes

Priority Group>Common

Rings

Vibration

Alert Mode

Rings+Vibration

Warning in low battery Yes

Standard

Quiet

In Meeting

Profile Modes

In Out Door

Security Setting

Phone Lock Yes

PIN Setting Yes

Others

Auto Power on/off Yes

Keypad Lock Yes

Emergency Call Yes

Reset Yes

U-disk Yes

PC Sync Software Yes

6. Technical Specifications

Communication Protocols and Technical Indices

Mode of Access CDMA(Code Division Multiple Access)

CDMA Protocol IS-2000, CDMA 2000 1X

Transmitting Frequency 824～849MHz

Receiving Frequency 869～894MHz

Receiving Sensitivity ≤-104dBm

Communication Protocols and Technical Indices

Mode of Access GSM

Transmitting Frequency 890～915MHz, 1710~1785MHz, 1850~1910MHz

Receiving Frequency 935～960MHz, 1805~1880MHz, 1930~1990MHz

Receiving Sensitivity ≤-102dBm

Power Consumption

Item Standard

Talking Time ≤180 Minutes

HISENSED90TechnicalSpecifications CONFIDENTIAL

ProprietaryInformationofHisense

Standby Time ≤100 Hours

Charging Time ≤3 Hours

Standby Current

(both CG standby)

≤12mA

Working Condition

Item Description

Working Temperature -20 ℃～+60 ℃

Storage Temperature -30 ℃～+70 ℃

Humidity 5%~95%

7. Accessories

Travel Charger Voltage AC 100~240VInput Frequency 50~60Hz

Voltage 5V Output Max. current 730mA

59.5*27.24*42.1mmSize Approx 60g

Input Plug Type –A (others as requested)

Humidity 5%~95%

Battery

Item Description

Type Li-Ion

Capacity 1400mAh

Rated Voltage 3.7V

8. A Complete Set of Product

No. Name Qty. Remark

1 Mobile Phone Body 1 Without battery

2 Battery 1

3 Travel Charger Head 1 Form a charger with data cable

4 Data Cable 1

5 Headset 1

6 Driver Disk 1

7 User Manual 1
