HIPOTRONICS OC-DI Series Manuel utilisateur

Operating Instructions

OC-DI Series

Digital Interface

Oil Testers

Version 1.0

No. 145896

Title

Digital Interface Oil Testers

Date

06/2018

Revision History

V0.1

03/2018

Initial draft of the document

III

This equipment contains exposed terminals carrying hazardous

voltages. There are no user serviceable components in the unit.

All repairs and upgrades that require the unit to be opened must

be referred to HIPOTRONICS or one of their nominated agents.

HIPOTRONICS and its sales partners refuse to accept any responsibility for consequential or

direct damage to persons and/or goods due to the lack of observance of instructions contained

herein or due to incorrect use of the equipment.

Further be aware that safety is the responsibility of the user!

Any correspondence regarding this instrument should include the exact type number,

instrument serial number and firmware version number. With the exception of the firmware

version number, this information can be found on the registration plate on the right panel of the

instrument. The firmware version can be found in the bottom right corner of the settings window.

Unauthorized opening of the unit may damage the EMI protection of the system and will reduce

its resistance to interference and transients. It may also cause the individual unit to be no longer

compliant with the relevant EMC emission and susceptibility requirements. If the unit has been

opened, the calibration will be rendered invalid and the warranty will be void.

Note

HIPOTRONICS has a policy of continuing improvement on all their products. The design of this

instrument will be subject to review and modification over its life. There may be small

discrepancies between the manual and the operation of the instrument, particularly where

software has been upgraded in the field.

HIPOTRONICS retains the right to modify the functionality, specification or operation of the

instrument without prior notice.

electronic without the prior written permission of HIPOTRONICS.

2018, HIPOTRONICS, USA

WARNING

Before operating the instrument, be sure to read and fully

understand the operating instructions. This instrument produces

hazardous voltages. It is the responsibility of the user to ensure

that the system is operated in a safe manner.

Manual Conventions

In the manual, the following conventions are used:

Indicates hazards.

There is a risk of equipment damage or personal injury or death. Carefully read and follow

the instructions. Be sure to follow any safety instructions given in addition to those for the

site at which tests are being performed.

Foreword

Welcome, new user of the “OC-DI Series”. Thank you for placing your confidence in our

product.

With the purchase of this measuring instrument you have opted for all the advantages that have

built a world-wide reputation for a HIPOTRONICS Instrument: robustness, performance and

quality. As a result, this instrument provides a solution which achieves the optimal combination

of traditional know-how and leading edge technology.

This operating manual is designed for completeness and easy location of the required

information. Customers who already have experience with this kind of equipment will find this

document to be of assistance as an extended help.

If you find a mistake or inconsistency in the operating manual then please feel free to inform our

Customer Support department with your corrections so that other users may benefit.

Contents

Manual Conventions IV

1Introduction 8

1.0 Receiving Instructions.................................................................................. 8

1.1 General........................................................................................................ 8

1.2 Scope of Supply........................................................................................... 8

1.2.1 Standard Scope of Supply............................................................... 8

1.3 Technical Data: OC60-DI............................................................................. 9

1.3.1 Physical and Environmental Specifications..................................... 9

1.3.2 Measurement .................................................................................. 9

2Safety 10

2.0 General...................................................................................................... 10

2.1 Essential Safety Recommendations .......................................................... 10

2.2 Summary.................................................................................................... 11

3Theory 12

3.0 Introduction................................................................................................ 12

3.1 Pre-Loaded Test Standards....................................................................... 12

3.2 Application ................................................................................................. 12

4Oil Tester Ports 13

4.0 Ports .......................................................................................................... 13

5Connection and Setup 14

5.0 Ground Connections.................................................................................. 14

5.1 Prepare Oil Test......................................................................................... 14

5.2 Main Menu................................................................................................. 15

5.3 Basic Mode................................................................................................ 16

5.4 Multi-Step Mode......................................................................................... 18

5.5 Reports ...................................................................................................... 20

5.6 Settings...................................................................................................... 21

6Troubleshooting 22

6.0 Diagnostics ................................................................................................ 22

6.1 Warning and Error Messages .................................................................... 22

7Miscellaneous 23

7.0 Care and Maintenance............................................................................... 23

7.0.1 Cleaning the Instrument................................................................ 23

7.0.2 Instrument Calibration................................................................... 23

VII

7.1 Instrument Storage .................................................................................... 23

7.2 Packing and Transport............................................................................... 24

7.3 Recycling ................................................................................................... 24

8Customer Support 25

9Appendix 26

9.0 Declaration of Conformity........................................................................... 26

9.1 Hipotronics, Inc.......................................................................................... 26

9.2 Warranty .................................................................................................... 27

9.3 Returned Material (RMA)..............................Error! Bookmark not defined.

1 Introduction

1.0 Receiving Instructions

When received, any possible transport damage should be noted. A written record should be made of

any damage. A suitable remark should be recorded on the delivery documents.

A claim for damage must be reported immediately to the transport company and to the Customer

Support Department of HIPOTRONICS or the local agent. It is essential to retain the damaged

packing material until the claim has been settled.

Check the contents of the shipment for completeness immediately after receipt (See chapter “Scope

of Supply”). If the shipment is incomplete or damaged, then this must be reported immediately to the

transport company and the Customer Support Department of HIPOTRONICS or the local agent.

Repair or replacement of the instrument can then be organized immediately.

1.1 General

The OC60-DI Liquid Dielectric Tester accurately and reliably tests dielectric strength of insulating

liquids used in a wide variety of electrical apparatus. The rugged, lightweight and portable design

ensures years of safe and trouble-free operation both in the field and in the laboratory.

1.2 Scope of Supply

1.2.1 Standard Scope of Supply

The following items are supplied with the standard instrument:

Qty

Description

Oil Tester Instrument

Power Cord

Operation Manual in English

Calibration Certificate

1 Introduction

1.3 Technical Data: OC60-DI

1.3.1 Physical and Environmental Specifications

Operating temperature

14…122° F (-10 .. 50°C)

Storage temperature

-4…158° F (-20 .. 70°C)

Humidity

5 ... 95 % r.h. non-condensing

Dimensions (W x D x H)

OC60-DI: 16” x 13” x 15” (41cm x 33cm x 38cm)

Weight

OC60-DI: 60lbs (25kg)

1.3.2 Power Specifications

Power Input

90 –264VAC 50 or 60Hz 200VA

Battery Power

12VDC NiMH 8.4Ah

1.3.3 Measurement

Breakdown Voltages

Accuracy: +/- 2% F.S.

Resolution: 0.1kV

Voltmeter

Accuracy: +/- 1% F.S.

Resolution: 0.1kV

2 Safety



Remember:

Hazardous voltage can shock, burn or cause death !

The unit should only be operated after carefully reading the user manual, which is an

integral part of the instrument.

HIPOTRONICS and its sales partners refuse to accept any responsibility for consequential

or direct damage to persons and/or goods due to none observance of instructions

contained herein or due to incorrect use of the equipment.

Further be aware that Safety is the responsibility of the user!

2.0 General

Safety is the most important aspect when working on or around high voltage electrical equipment.

Personnel whose working responsibilities involve testing and maintenance of the various types of high

voltage equipment must have understood the safety rules written in this document and the associated

safety practices specified by their company and government. Local and state safety procedures

should also be consulted. Company, regional or national regulations must be fulfilled beyond

HIPOTRONICS recommendations.

If the instrument is damaged or it is possible that damage has occurred, for example during

transportation, do not apply any voltage. The instrument may only be used under dry operating

conditions.

Do not open the unit; it contains no user replaceable parts.

People with heart pacemakers should not be in the vicinity of this system during operation.

Safety is the responsibility of the user. Always operate the equipment in accordance with

the instructions, always paying full attention to local safety practices and procedures.

This equipment must be operated only by trained and competent personnel who are aware

of the dangers and hazards involved in testing transformers.

2.1 Essential Safety Recommendations

Every terminal should be checked and verified before connection of the instrument. Ground

connections may be left in place.
