HIMA HIMatrix GEH 01 Manuel utilisateur

HIMatrix

Safety-Related Controller

GEH 01 Manual

HIMA Paul Hildebrandt GmbH + Co KG

Industrial Automation

Rev. 2.00 HI 800 183 E

HI 800 183 E Rev. 2.00 (1334)

All HIMA products mentioned in this manual are protected by the HIMA trade-mark. Unless noted otherwise,

this also applies to other manufacturers and their respective products referred to herein.

HIMax®, HIMatrix®, SILworX®, XMR®and FlexSILon®are registered trademarks of HIMA Paul Hildebrandt

GmbH + Co KG.

All of the instructions and technical specifications in this manual have been written with great care and

effective quality assurance measures have been implemented to ensure their validity. For questions, please

contact HIMA directly. HIMA appreciates any suggestion on which information should be included in the

manual.

Equipment subject to change without notice. HIMA also reserves the right to modify the written material

without prior notice.

For further information, refer to the HIMA DVD and our website at http://www.hima.de and

http://www.hima.com.

Contact

HIMA contact details:

HIMA Paul Hildebrandt GmbH + Co KG

P.O. Box 1261

68777 Brühl, Germany

Phone: +49 6202 709-0

Fax: +49 6202 709-107

E-mail: [email protected]

Type of change

Revision

index Revisions technical editorial

1.00 Added: Configuration with SILworX X X

1.01 Revised: Table 5 Product Data X X

2.00 Added: GEH 014 X X

GEH 01 Table of Contents

HI 800 183 E Rev. 2.00 Page 3 of 26

Table of Contents

1Introduction 5

1.1 Structure and Use of this Manual 5

1.2 Target Audience 6

1.3 Formatting Conventions 6

1.3.1 Safety Notes 6

1.3.2 Operating Tips 7

2Safety 8

2.1 Intended Use 8

2.1.1 Environmental Requirements 8

2.1.2 ESD Protective Measures 8

2.2 Residual Risk 9

2.3 Safety Precautions 9

2.4 Emergency Information 9

3Product Description 10

3.1 Safety Function 10

3.2 Equipment, Scope of Delivery 10

3.3 Type Label 10

3.4 Structure 11

3.5 Product Data 13

3.5.1 Product Data GEH 014 13

4Start-up 14

4.1 Mounting 14

4.1.1 Mounting the GEH 01 Subrack in Zone 2 14

5Operation 16

6Maintenance 17

6.1 Replacing Fans 17

7Decommissioning 18

8Transport 19

9Disposal 20

Appendix 21

Glossary 21

Index of Figures 22

Index of Tables 23

Index 24

Table of Contents GEH 01

Page 4 of 26 HI 800 183 E Rev. 2.00

GEH 01 1 Introduction

HI 800 183 E Rev. 2.00 Page 5 of 26

1 Introduction

This manual describes the technical characteristics of the subrack and its use. It provides

information on how to install, start up and configure the module.

1.1 Structure and Use of this Manual

The content of this manual is part of the hardware description of the HIMatrix programmable

electronic system.

This manual is organized in the following main chapters:

Introduction

Safety

Product Description

Start-up

Operation

Maintenance

Decommissioning

Transport

Disposal

iThis manual usually refers to the plug-in cards of a modular controller as modules.

Modules is also the term used in SILworX.

Additionally, the following documents must be taken into account:

Name Content Document number

HIMatrix System Manual

Compact Systems Hardware description of the HIMatrix

compact systems HI 800 141 E

HIMatrix System Manual

Modular System F60 Hardware description of the HIMatrix

modular system HI 800 191 E

HIMatrix Safety Manual Safety functions of the HIMatrix system HI 800 023 E

HIMatrix Safety Manual for

Railway Applications Safety functions of the HIMatrix system

using the HIMatrix in railway

applications

HI 800 437 E

SILworX Online Help Instructions on how to use SILworX -

ELOP II Factory

Online Help Instructions on how to use ELOP II

Factory, Ethernet IP protocol -

SILworX First Steps Introduction to SILworX using the

HIMax system as an example HI 801 103 E

ELOP II Factory First Steps Introduction to ELOP II Factory HI 800 006 E

Table 1: Additional Relevant Documents

The latest manuals can be downloaded from the HIMA website at www.hima.com. The revision

index on the footer can be used to compare the current version of existing manuals with the

Internet edition.

1 Introduction GEH 01

Page 6 of 26 HI 800 183 E Rev. 2.00

1.2 Target Audience

This document addresses system planners, configuration engineers, programmers of

automation devices and personnel authorized to implement, operate and maintain the modules

and systems. Specialized knowledge of safety-related automation systems is required.

1.3 Formatting Conventions

To ensure improved readability and comprehensibility, the following fonts are used in this

document:

Bold To highlight important parts

Names of buttons, menu functions and tabs that can be clicked and used

in the programming tool.

Italics For parameters and system variables

Courier Literal user inputs

RUN Operating state are designated by capitals

Chapter 1.2.3 Cross references are hyperlinks even though they are not particularly

marked. When the cursor hovers over a hyperlink, it changes its shape.

Click the hyperlink to jump to the corresponding position.

Safety notes and operating tips are particularly marked.

1.3.1 Safety Notes

The safety notes are represented as described below.

These notes must absolutely be observed to reduce the risk to a minimum. The content is

structured as follows:

Signal word: warning, caution, notice

Type and source of risk

Consequences arising from non-observance

Risk prevention

The signal words have the following meanings:

Warning indicates hazardous situation which, if not avoided, could result in death or serious

injury.

Caution indicates hazardous situation which, if not avoided, could result in minor or modest

injury.

Notice indicates a hazardous situation which, if not avoided, could result in property damage.

NOTE

Type and source of damage!

Damage prevention

SIGNAL WORD

Type and source of risk!

Consequences arising from non-observance

Risk prevention

GEH 01 1 Introduction

HI 800 183 E Rev. 2.00 Page 7 of 26

1.3.2 Operating Tips

Additional information is structured as presented in the following example:

iThe text corresponding to the additional information is located here.

Useful tips and tricks appear as follows:

TIP The tip text is located here.

2 Safety GEH 01

Page 8 of 26 HI 800 183 E Rev. 2.00

2 Safety

All safety information, notes and instructions specified in this document must be strictly

observed. The product may only be used if all guidelines and safety instructions are adhered to.

This product is operated with SELV or PELV. No imminent risk results from the product itself.

The use in Ex-Zone is permitted if additional measures are taken.

2.1 Intended Use

HIMatrix components are designed for assembling safety-related controller systems.

When using the components in the HIMatrix system, comply with the following general

requirements.

2.1.1 Environmental Requirements

Requirement type Range of values 1)

Protection class Protection class III in accordance with IEC/EN 61131-2

Ambient temperature 0...+60 °C

Storage temperature -40...+85 °C

Pollution Pollution degree II in accordance with IEC/EN 61131-2

Altitude < 2000 m

Housing Standard: IP20

Supply voltage 24 VDC

1) The values specified in the technical data apply and are decisive for devices with extended

environmental requirements.

Table 2: Environmental Requirements

Exposing the HIMatrix system to environmental conditions other than those specified in this

manual can cause the HIMatrix system to malfunction.

2.1.2 ESD Protective Measures

Only personnel with knowledge of ESD protective measures may modify or extend the system

or replace devices.

NOTE

Device damage due to electrostatic discharge!

When performing the work, make sure that the workspace is free of static, and wear

an ESD wrist strap.

If not used, ensure that the device is protected from electrostatic discharge, e.g., by

storing it in its packaging.

GEH 01 2 Safety

HI 800 183 E Rev. 2.00 Page 9 of 26

2.2 Residual Risk

No imminent risk results from a HIMatrix system itself.

Residual risk may result from:

Faults related to engineering

Faults related to the user program

Faults related to the wiring

2.3 Safety Precautions

Observe all local safety requirements and use the protective equipment required on site.

2.4 Emergency Information

A HIMatrix system is a part of the safety equipment of a site. If a device or a module fails, the

system enters the safe state.

In case of emergency, no action that may prevent the HIMatrix systems from operating safely is

permitted.

3 Product Description GEH 01

Page 10 of 26 HI 800 183 E Rev. 2.00

3 Product Description

The subrack is intended for being equipped with modules of the F60 system. Slots 1 and 2 are

reserved for the power supply module and central module, respectively. Any type of F60

modules can be plugged in to slots 3...8.

3.1 Safety Function

No safety function is performed by the subrack.

3.2 Equipment, Scope of Delivery

The following table specifies the available components:

Designation Description

GEH 01 Subrack (earth grid, 2 fans, slots for power supply module, central

module and 6 I/O modules)

GEH 014 Subrack (earth grid, 2 fans, slots for power supply module, central

module and 6 I/O modules)

Operating temperature: -25...+70 °C (temperature class T1),

Vibration and shock tested according to EN 50125-3 and EN 50155,

class 1B according to IEC 61373

BLK 01 Cover plate for unused slots

Table 3: Available Variants

3.3 Type Label

The type plate contains the following details:

Product name

Bar code (1D or 2D code)

Part no.

Production year

Hardware revision index (HW Rev.)

Firmware revision index (FW Rev.)

Operating voltage

Mark of conformity

Figure 1: Sample Type Label
