Hills NVC-DT1 Manuel utilisateur
mera
3M IR Eyeball Camera (4mm)
NVC-DT1
Quick Guide
V1.3
Quick Guide Eyeball Camera
2
2
Table of Contents
1 Overview ..........................................................................................................3
2 Installation........................................................................................................5
3 Setup using Hill’s NVR.......................................................................................9
4 Setup using remote software..........................................................................10
5 Specification ...................................................................................................13
Quick Guide Eyeball Camera
3
3
Figure 1-1 Eyeball camera overview
Table 1-1 Description
NO.
Name
1
Trim Ring
2
Enclosure
3
Mounting Base
4
Camera
5
Power interface
6
10M/100M self-adaptive Ethernet interface
6
5
4
Overview
1
Quick Guide Eyeball Camera
4
4
Table 1-2 Carton contents
Camera
Quick Guide
Drill template
Mounting hardware
3x Expansion screws
Water proof accessories for
Ethernet interface
Quick Guide Eyeball Camera
5
5
Checklist before you start
All carton contents present and are in good conditions.
Ensure power supplies are off during installation.
Power supply voltage rating as specified in product specifications.
Installation environment is as specified.
Contact your dealer if product does not function properly. Do not attempt to
repair yourself.
Wall or mounting platform is strong enough to withstand three times the
weight of the camera.
Installation
2
Quick Guide Eyeball Camera
6
6
Steps:
1. Rotate the trim ring counterclockwise to remove it from the camera.
Figure 2-1 Dissemble the camera
2. Drill the cable hole and the screw holes in the ceiling according to the
supplied drilling template.
Figure 2-2 Drilling template
3. Connect the corresponding power/video cables.
4. Fix the mounting base to the ceiling with the supplied screws.
Quick Guide Eyeball Camera
7
7
Figure 2-3 Fix the mounting base
5. Secure the camera to the mounting base.
Figure 2-4 Assemble the camera
Quick Guide Eyeball Camera
8
8
6. Fix the enclosure to camera to complete the installation.
Figure 2-5 Assemble the trim ring
7. Adjust the surveillance angle according to the figure below.
8. Rotate the trim ring clockwise to secure the camera.
Figure 2-6 3-axis adjustment
Quick Guide Eyeball Camera
9
9
The Hills Video Security IP cameras (NVC-MB1, NVC-DM1, NVC-DT1 and
NVC-DF1) have a pre-loaded protocol that works immediately with Hills Video
Security NVRs (NVR-CH4, NVR-CH8 and NVR-CH16) as soon as they are
connected.
Connect the camera via a network cable to one of the PoE network interface
sockets at the back of the NVR.
Figure 3-1 NVR –Camera connection
Please refer to User Manual of NVR to add and edit a camera.
Setup using Hills’NVR
3
Quick Guide Eyeball Camera
10
10
To view and configure the camera via LAN (Local Area Network), you need to
connect the network camera in the same subnet with your PC. Then install
the PC software to search and change the IP address of the network camera.
The following figure shows the cable connection of a network camera and a
PC:
Figure 4-1 Wiring over LAN
Set the IP address of the camera for accessing via LAN.
Steps:
1. Use PC client software to detect the online devices. Please refer to the
user manual of PC client software for detailed information.
●Search online devices automatically
After launching the PC software, it automatically searches the online
devices every 15 seconds from the subnet where your computer is located.
It displays the total number and information of the searched devices in the
Online Devices interface.
Setup using remote software
4
