6
Long press“ ”key enter parameter interface，enter parameter no. “P79”, appear “0”，
press“ ”key exchange to “3”，press“ ”key will appear “yes”【press“ ”key will adjust to
“no”】，and press“ ” key for resetting original parameter。
8. Pattern design setting mode：
Under normal sewing mode ，long press key 2 seconds ，the screen appear “d1” ，
press key exchang to d1-d9 pattern，choose your pattern no. and press S for setting，the
screen appear “1 3.0 01”，now setting the stitching and gauge data for first stage，press left/right key
to select setting data；after setting one stage，press left/right key move to left data，press +/- key move
to other data setting，if current stitch is zero, can not go on next stage setting；After finish all the data of
stitching and gauge，press key for saving and return back to “d1” interface，press key for exit
and no save。Press key return back to normal mode。
Remark：
（1）The function is used for setting pattern design，could setting 9 kind of patterns，16 teams each
patterns；Under sewing mode，the pattern is as gauge。
（2）Pattern sewing mode，if stopping during sewing，after press reverse button，the pattern sewing
will be begin from zero。（fit for corner bend）
III.System parameter table
NO Project Content Setting
range
The
defaul
t
value
level
P-01 Sewing speed Set sewing speed 200~5000(rp
m) 4100 1
P-02 Soft start function Sewing few stitches at sewing start function
0：Invalid 1~9：Soft start stitches 0~9 2 1
P-04 Fixed-length seam
sewing speed Set fixed-length seam sewing speed 200~4000(rp
m) 3000 1
P-06 Zero pitch correction
value
When the needle pitch is set to 0mm,fine the value
so that the actual sewing needle pitch is zero 50~150 100 2
P-07
Positive needle
distance correction
value
Magnification positive sewing distance
(Sewing needle fixed distance) 50~150(%) 100 2
P-08 Anti-needle distance
correction value
Enlarge reverse stitches Distance Scale (Sewing
needle fixed distance) 50~150(%) 100 2
P-09 Back stitch speed
limitation
can keep needle from breaking while backstitching 500~1500 800 1
P-10
Set the length of the
stitch from the set
number
0:Set the number of stitches to set the value
1:When the length is set to self-made, the number
is the number of the pattern, that is, the total
0/1 1 1
