HIK VISION DS-2CD2012-I Manuel utilisateur

HikvisionTechnicalManual

Network Camera

Technical Manual

HikvisionTechnicalManual

Notices

The information in this documentation is subject to change without notice and does not represent any

commit ment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data

that may appear in this documentation. The product(s) described in this documentation are furnished

subject to a license and may only be used in accordance with the terms and conditions of such license.

This documentation is issued in strict confidence and is to be used only for the purposes for

which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or

be used for any other purpose without prior written consent of HIKVISION and then only on the

condition that this notice is included in any such reproduction. No information as to the contents or

subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,

shall be given ora lly or in writing or shall be communicated in any manner whatsoever to any third party

being an individual, firm, or company or any employee thereof without the prior written consent of

HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use

this product. HIKVISION reserves the right to make changes to its products as circumstances may

warrant, without notice.

This documentation is provided “as-is,” without warranty of any kind.

Please send any comments regarding the documentation to:

overseabusiness@hikvision.com

Find out more about HIKVISION at www.hikvision.com

HikvisionTechnicalManual

DS-2CD2012-I

Key Features

Up to 1.3 megapixel (1280 × 960) resolution

Standard video compression with high compression ratio

Progressive scan CMOS, capture motion video without incised margin

Support dual stream, and the sub-stream for mobile surveillance

High-performance and long service life Infrared LED, Approx. 20 to 30 meters IR range

IR cut filter with auto switch

PoE (Power over Ethernet)

Ingress Protection level: IP66

Auto-iris, electronic shutter for different surveillance environments

Other functions: heartbeat, alarm, reset button, mirror, etc.

Specification

Model

Parameter

DS-2CD2012-I

1.3 Megapixel CMOS ICR Infrared Network Mini Bullet Camera

Camera

Image Sensor

1/3" Progressive Scan CMOS

Min. Illumination

0.01 Lux @ (F1.2, AGC ON) ,0 Lux with IR

Shutter Speed

1/25 s to 1/100,000 s

Lens

6mm@ F2.0 (4mm, 12mm optional)

Lens Mount

M12

Day &Night

IR cut filter with auto switch

Digital Noise

Reduction

3D DNR

Compression Standard

HikvisionTechnicalManual

Video Compression

H.264/ MPEG4/ MJPEG

Video Bit Rate

32 Kbps –16 Mbps

Dual Stream

Yes


Max. Resolution

1280 x 960

Frame Rate

50 Hz: 25 fps (1280 × 960), 25 fps (1280 x 720)

60 Hz: 30 fps (1280 × 960), 30 fps (1280 x 720)

Image Settings

Saturation, Brightness, Contrast adjustable by client software or web

browser

Network

Network Storage

NAS (iSCSI optional)

Alarm Trigger

Motion detection, Tampering alarm, Storage exception

Protocols

TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP,UPnP,

ICMP,IGMP,SNMP, FTP, 802.1x, QoS, HTTPS ( SIP,SRTP,IPv6 optional )

Security

User Authentication, Watermark

Standard

ONVIF, PSIA, CGI

Interface

Communication

Interface

1 RJ45 10M/100M Ethernet interface

General

Operating Conditions

-10 °C - 60 °C (-13 °F –140 °F)

Humidity 95% or less (non-condensing)

Power Supply

12 V DC ± 10%

PoE (802.3af)

Power Consumption

Max. 4 W

Ingress Protection

level

IP66

IR Range

Approx. 20 to 30 meters

Dimensions

60.4 x 76.5 x 138.1mm

Weight

300g

Order Models

DS-2CD2012-I

HikvisionTechnicalManual

Dimensions

Unit: mm
