HIK VISION E-series Manuel utilisateur

E-series HD Camera

User Manual

UD.6L0201D1062A01

E-series High-definition Camera·User Manual

Thank you for purchasing our product. If there are any questions, or requests,

please do not hesitate to contact the dealer.

This manual applies to

DS-2CE5512P (N)

DS-2CE5582P(N)

DS-2CE5512P (N)-IR

DS-2CE5582P(N)-IR

DS-2CE5582P (N)-IR1 (IR3)

DS-2CE1582P (N)-IR1 (IR3)

DS-2CE5512P (N)-IRP

DS-2CE5582P(N)-IRP

DS-2CE1512P (N)-IR

DS-2CE1582P(N)-IR

This manual may contain several technical incorrect places or printing errors, and

the content is subject to change without notice. The updates will be added to the

new version of this manual. We will readily improve or update the products or

procedures described in the manual.

DISCLAIMER STATEMENT

“Underwriters Laboratories Inc. (“UL”) has not tested the performance or

reliability of the security or signaling aspects of this product. UL has only tested

for fire, shock or casualty hazards as outlined in UL’s Standard(s) for Safety,

UL60950-1. UL Certification does not cover the performance or reliability of the

security or signaling aspects of this product. UL MAKES NO REPRESENTATIONS,

WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE

PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING RELATED

FUNCTIONS OF THIS PRODUCT.”

0100001030527

E-series High-definition Camera·User Manual

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and found to comply with the

limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be required to correct the

interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that

may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied accessories too

are marked with "CE" and comply therefore with the

applicable harmonized European standards listed under the

Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC, the RoHS

Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked with this

symbol cannot be disposed of as unsorted municipal waste in

the European Union. For proper recycling, return this product

to your local supplier upon the purchase of equivalent new

equipment, or dispose of it at designated collection points.

E-series High-definition Camera·User Manual

For more information see: www.recyclethis.info.

2006/66/EC (battery directive): This product contains a battery

that cannot be disposed of as unsorted municipal waste in

the European Union. See the product documentation for

specific battery information. The battery is marked with this

symbol, which may include lettering to indicate cadmium (Cd),

lead (Pb), or mercury (Hg). For proper recycling, return the battery to your

supplier or to a designated collection point. For more information see:

www.recyclethis.info.

E-series High-definition Camera·User Manual

Safety Instruction

These instructions are intended to ensure that user can use the product correctly

to avoid danger or property loss.

The precaution measure is divided into Warnings and Cautions.

Warnings: Serious injury or death may occur if any of the warnings are neglected.

Cautions: Injury or equipment damage may occur if any of the cautions are

neglected.

Warnings

Please adopt the power adapter which can meet the safety extra low voltage

(SELV) request. And source with DC 12V or AC 24V (depending on models)

according to the IEC60950-1 and Limited Power Source standard.

If the product does not work properly, please contact your dealer or the

nearest service center. Never attempt to disassemble the camera yourself.

(We shall not assume any responsibility for problems caused by

unauthorized repair or maintenance.)

To reduce the risk of fire or electrical shock, do not expose this product to

rain or moisture.

Warnings Follow these

safeguards to prevent serious

injury or death.

Cautions Follow these

precautions to prevent potential

injury or material damage.

E-series High-definition Camera·User Manual

This installation should be made by a qualified service person and should

conform to all local codes.

Please install blackouts equipment into the power supply circuit for

convenient supply interruption.

Please make sure that the ceiling can support more than 50(N) Newton

gravities if the camera is fixed to the ceiling.

Cautions

Make sure the power supply voltage is correct before using the camera.

Do not drop the camera or subject it to physical shock.

Do not touch sensor modules with fingers. If cleaning is necessary, use a

clean cloth with a bit of ethanol and wipe it gently. If the camera will not be

used for an extended period of time, put on the lens cap to protect the

sensor from dirt.

Do not aim the camera at the sun or extra bright places. A blooming or

smear may occur otherwise (which is not a malfunction however), and

affecting the endurance of sensor at the same time.

The sensor may be burned out by a laser beam, so when any laser

equipment is being used, make sure that the surface of the sensor will not

be exposed to the laser beam.

Do not place the camera in extremely hot or cold temperatures (the

operating temperature should be between -40°C ~ 60°C), dusty or damp

locations, and do not expose it to high electromagnetic radiation.

To avoid heat accumulation, good ventilation is required for a proper

operating environment.

Do not let water and any liquid flow into the camera.

E-series High-definition Camera·User Manual

While shipping, the camera should be packed in its original packing, or

packing of the same texture.

Improper use or replacement of the battery may result in hazard of

explosion. Replace with the same or equivalent type only. Dispose of used

batteries according to the instructions provided by the battery

manufacturer.

E-series High-definition Camera·User Manual

Table of Contents

1 Introduction ........................................................................ 8

1.1 Product Features ........................................................8

1.2 Appearance of Camera..................................................9

2 Installation ....................................................................... 12

2.1 Installation of DS-2CE5512P(N) and DS-2CE5582P(N) Dome Camera

..............................................................................12

2.2 Installation of DS-2CE5512P(N)-IR and DS-2CE5582P(N)-IR Dome

Camera .....................................................................18

2.3 Installation of DS-2CE5512P(N)-IRP and DS-2CE5582P(N)-IRP Dome

Camera .....................................................................21

2.4 Installation of DS-2CE1512P(N)-IR and DS-2CE1582P(N)-IR Bullet

Camera .....................................................................25

2.5 Installation of DS-2CE1582P(N)-IR1(IR3) Bullet Camera ............27

2.6 Installation of DS-2CE5582P(N)-IR1(IR3) Dome Camera ............ 29

2.7 Power Supply ..........................................................32

E-series High-definition Camera·User Manual

1Introduction

1.1 Product Features

This camera adopts high performance DIS and advanced print circuit board

design technology. It possesses of high resolution, low distortion, and low noise

features, etc. It is extremely suitable for supervisory system and image processing

system.

The main features of the E-series cameras are as follows.

High-resolution for the clear and bright image;

IR cut filter for auto day/night switching (not supported by DS-2CE5512P(N)

and DS-2CE5582P(N));

Easy to get high quality pictures and video with high SNR (Signal to Noise

Ratio) feature;

Auto-electronic shutter control to adapt to various surveillance

environments;

Auto-Gain Control for surveillance in low illumination scenario and

self-adaptive to different lightening environments;

High color rendition with Auto White Balance function;

Bullet camera adopts an advanced product design and the mounts of them

support wiring from inside out;

Bullet camera adopts three-axis (pan/tilt/rotation) adjustment for optimum

surveillance angles and position;

Dome camera adopts patent universal adjustable structure providing

convenient adjustment and high reliability.

E-series High-definition Camera·User Manual

1.2 Appearance of Camera

Figure 1-1 DS-2CE5512P(N) and DS-2CE5582P(N)

Figure 1-2 DS-2CE5512P(N)-IR and DS-2CE5582P(N)-IR
