HIK VISION DS-7200-SH Manuel utilisateur

Digital Video Recorder

User

Manual

UD.

0202D1307A01

User Manual of DS-7200-SH/SV/SL and DS-7300/8100-SH Series DVR

Hikvision® Network Digital Video Recorder User’s Manual

This manual, as well as the software described in it, is furnished under license and may be used or copied only in

accordance with the terms of such license. The content of this manual is furnished for informational use only, is subject

to change without notice, and should not be construed as a commitment by Hikvision Digital Technology Co., Ltd.

(Hikvision). Hikvision assumes no responsibility or liability for any errors or inaccuracies that may appear in the book.

Except as permitted by such license, no part of this publication may be reproduced, stored in a retrieval system, or

transmitted, in any form or by any means, electronic, mechanical, recording, or otherwise, without the prior written

permission of Hikvision.

HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE

IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,

REGARDING THE HIKVISION SOFTWARE. HIKVISION DOES NOT WARRANT, GUARANTEE, OR MAKE

ANY REPRESENTATIONS REGARDING THE USE OR THE RESULTS OF THE USE OF THE HIKVISION

SOFTWARE IN TERMS OF ITS CORRECTNESS, ACCURACY, RELIABILITY, CURRENTNESS, OR

OTHERWISE. THE ENTIRE RISK AS TO THE RESULTS AND PERFORMANCE OF THE HIKVISION

SOFTWARE IS ASSUMED BY YOU. THE EXCLUSION OF IMPLIED WARRANTIES IS NOT PERMITTED BY

SOME STATES. THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.

IN NO EVENT WILL HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO

YOU FOR ANY CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES (INCLUDING DAMAGES FOR

LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, AND THE

LIKE) ARISING OUT OF THE USE OR INABILITY TO USE THE HIKVISION SOFTWARE EVEN IF HIKVISION

HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES DO NOT

ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL

DAMAGES, THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.

User Manual of DS-7200-SH/SV/SL and DS-7300/8100-SH Series DVR

Regulatory information

FCC information

FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case

the user will be required to correct the interference at his own expense.

FCC conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the

applicable harmonized European standards listed under the Low Voltage Directive 2006/95/EC, the EMC Directive

2004/108/EC, the RoHS Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in

the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new

equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info.

2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in

the European Union. See the product documentation for specific battery information. The battery is marked with this

symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return

the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info.

User Manual of DS-7200-SH/SV/SL and DS-7300/8100-SH Series DVR

Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact

dealer.

This manual is applicable to the following models:

DS-7204HVI-SH, DS-7208HVI-SH, DS-7216HVI-SH, DS-7224HVI-SH, DS-7232HVI-SH;

DS-7204HFI-SH, DS-7208HFI-SH, DS-7216HFI-SH;

DS-7204HWI-SH, DS-7208HWI-SH, DS-7216HWI-SH, DS-7224HWI-SH, DS-7232HWI-SH;

DS-7204HVI-SV, DS-7208HVI-SV, DS-7216HVI-SV;

DS-7204HWI-SV;

DS-7208HWI-SL, DS-7216HWI-SL;

DS-7304HFI-SH, DS-7308HFI-SH, DS-7316HFI-SH, DS-7324HFI-SH, DS-7332HFI-SH;

DS-7304HWI-SH, DS-7308HWI-SH, DS-7316HWI-SH, DS-7324HWI-SH, DS-7332HWI-SH;

DS-7324HI-SH, DS-7332HI-SH;

DS-8124HCI-SH, DS-8132HCI-SH; DS-

8124HFSI-SH, DS-8132HFSI-SH; DS-

8124HWSI-SH, DS-8132HWSI-SH.

This manual may contain several technically incorrect places or printing errors, and the content is subject to

change without notice. The updates will be added into the new version of this manual. We will readily

improve or update the products or procedures described in the manual.

User Manual of DS-7200-SH/SV/SL and DS-7300/8100-SH Series DVR

Preventive and Cautionary Tips

Before connecting and operating your device, please be advised of the following tips:

•Ensure unit is installed in a well-ventilated, dust-free environment.

•Unit is designed for indoor use only.

•Keep all liquids away from the device.

•Ensure environmental conditions meet factory specifications.

•Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of dropping it

may cause damage to the sensitive electronics within the unit.

•Use the device in conjunction with an UPS if possible.

•Power down the unit before connecting and disconnecting accessories and peripherals.

•A factory recommended HDD should be used for this device.

•Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or

equivalent type only. Dispose of used batteries according to the instructions provided by the battery

manufacturer.

User Manual of DS-7200-SH/SV/SL and DS-7300/8100-SH Series DVR

Product Key Features

General

PAL/NTSC adaptive video inputs.

H.264 video compression with high reliability and superior definition.

Encoding at up to WD1 (PAL: 960

576, NTSC: 960

480) resolution for DS-7200HWI-SH,

DS-7204HWI-SV, DS-7200HVI-SV, DS-7200HWI-SL, DS-7224/7232HVI-SH,

DS-7300HWI-SH, DS-7300HI-SH, DS-8100HCI-SH and DS-8100HWSI-SH models; and up to

4CIF resolution for DS-7204/7208/7216HVI-SH, DS-7200HFI-SH, DS-7300HFI-SH, and

DS-8100HFSI-SH models.

Each channel supports dual-stream.

Independent configuration for each channel, including resolution, frame rate, bit rate, image

quality, etc.

Input and output video quality is configurable.

Normal and event recording parameters configurable per individual camera.

Encoding for audio/video composite stream or video stream; audio and video synchronization

during composite stream encoding.

Watermark technology.

Local Monitoring

Simultaneous HDMI/VGAand CVBS outputs.

HDMI/VGA output at up to 1920

1080P resolution.

1/4/6/8/9/16/25/36-division live view is supported, and the display sequence of screens is

adjustable.

Live view screen can be switched in group, and manual switch and automatic cycle view is also

provided, the interval of automatic cycle can be adjusted.

Quick setting menu is provided for live view.

The selected live view channel can be shielded.

Motion detection, tamper-proof, video exception and video loss alarm functions.

Privacy mask.

Multiple PTZ protocols supported; setting and calling of PTZ preset, patrol and pattern.

Zooming in by clicking the mouse and PTZ tracing by dragging mouse.

HDD Management

1 SATA hard disk can be connected to DS-7200HVI-SH, DS-7200HVI-SV, DS-7204HFI-SH,

DS-7204HWI-SV and DS-7204HWI-SH, DS-7200HWI-SL models, 2 SATA hard disks to

DS-7208/7216HFI-SH, DS-7208/7216HWI-SH, DS-7224/7232HVI-SH and

DS-7224/7232HWI-SH models, up to 4 SATA hard disks to DS-7300-SH, and up to 8 SATA

hard disks to DS-8100-SH; with a maximum of 4TB storage capacity for each disk.

8 network disks (8 NAS disks, or 7 NAS disks+1 IP SAN disk) can be connected.

HDD group management.

Support HDD standby function.

HDD property: redundancy, read-only, read/write (R/W).

HDD quota management; different capacity can be assigned to different channel.

Recording and Playback

Holiday recording schedule configuration.

User Manual of DS-7200-SH/SV/SL and DS-7300/8100-SH Series DVR

Normal and event video encoding parameters.

Multiple recording types: manual, normal, motion, alarm, motion/alarm and motion & alarm.

Note: The alarm, motion/alarm and motion & alarm recording types are provided for

DS-7224/7232HVI-SH, DS-7224/7232HWI-SH, DS-7300-SH and DS-8100-SH models only.

8 recording time periods with separated recording types.

Pre-record and post-record for motion detection for recording, and pre-record time for schedule

and manual recording.

Searching record files by event.

Customization of tags, searching and playing back by tags.

Locking and unlocking record files.

Local redundant recording.

Searching and playing back record files by channel number, recording type, start time, end time,

etc.

Smart search for the selected area in the video.

Zooming in when playback.

Playing reversely.

Support pause, speed up, speed down, skip forward, and skip backward when playback, locating

by dragging the mouse.

4/8/16-ch synchronous playback.

Backup

Export video data by USB, SATA or eSATA storage device.

Note: The eSATAis supported by DS-7300-SH and DS-8100-SH models only.

Export video clips when playback.

Management and maintenance of backup devices.

Alarm and Exception

Configurable arming time of alarm input/output (for DS-7224/7232-SH, DS-7300-SH and

DS-8100-SH models).

Alarm for video loss, motion detection, tampering, abnormal signal, video input/output standard

mismatch, illegal login, network disconnected, IP confliction, abnormal record, HDD error, and

HDD full, etc.

Alarm event triggers full screen monitoring, audio alarm, notifying surveillance center and

sending email.

Automatic restore when system is abnormal.

Other Local Functions

Operable by mouse, IR remote control or front panel (for DS-7300-SH and DS-8100-SH).

Three-level user management; admin user is allowed to create many operating accounts and

define their operating permission, which includes the limit to access any channel.

Operation, exceptions and log recording and searching.

Import and export of device configuration information.

Network Functions

1 self-adaptive 10M/100M network interface for DS-7204/7208/7216-SH/SV/SL, and 1

self-adaptive 10M/100M/1000M network interface for DS-7224/7232-SH, and DS-7300-SH,

and 2 self-adaptive 10M/100M/1000M network interfaces for DS-8100-SH models.

IPv6 is supported.

TCP/IP protocol, PPPoE, DHCP, DNS, DDNS, RTSP, NTP, SADP, SMTP, SNMP, UPnP™, NFS,

User Manual of DS-7200-SH/SV/SL and DS-7300/8100-SH Series DVR

and iSCSI are supported.

TCP, UDP and RTP for unicast.

Remote search, playback, download, locking and unlocking of the record files, and downloading

files broken transfer resume.

Remote parameters setup; remote import/export of device parameters.

Remote viewing of the device status, system logs and alarm status.

Remote locking and unlocking of control panel and mouse.

Remote HDD formatting and program upgrading.

Remote system restart.

RS-232 and RS-485 transparent channel transmission.

Note: RS-232 serial port is provided for DS-7300-SH and DS-8100-SH models only.

Alarm event and exception information can be sent to the remote host.

Remotely start/stop recording.

Upgrade by remote FTP server.

Remote PTZ control.

Two-way audio and voice broadcasting.

Embedded WEB server.

Development Scalability:

SDK for Windows and Linux system.

Source code of application software for demo.

Development support and training for application system.

User Manual of DS-7200-SH/SV/SL and DS-7300/8100-SH Series DVR

TABLE OF

CONTENTS

Product Key Features.........................................................................................................5

C H AP T E R 1......................................................................................................................12

Introduction.............................................................................................................................12

1.1 Front Panel.................................................................................................................13

1.2 IR Remote Control Operations...................................................................................18

1.3 USB Mouse Operation...............................................................................................20

1.4 Input Method Description..........................................................................................20

1.5 Rear Panel..................................................................................................................21

1.6 Starting Up and Shutting Down the Device...............................................................26

C H AP T E R 2......................................................................................................................27

Getting Started.......................................................................................................................27

C H AP T E R 3......................................................................................................................32

Live View.................................................................................................................................32

3.1 Introduction of Live View..........................................................................................33

3.2 Operations in Live View Mode..................................................................................34

3.2.1 Front Panel Operation.....................................................................................34

3.2.2 Using the Mouse in Live View .......................................................................34

3.2.3 Using an Auxiliary Monitor............................................................................35

3.2.4 Main/Aux Output Switching...........................................................................36

3.2.5 Quick Setting Toolbar in Live View Mode.....................................................36

3.3 Configuring Live View Settings.................................................................................39

3.4 Channel-zero Encoding..............................................................................................41

3.5 User Logout................................................................................................................42

C H AP T E R 4......................................................................................................................43

PTZ Controls..........................................................................................................................43

4.1 Configuring PTZ Settings..........................................................................................44

4.2 Setting PTZ Presets, Patrols & Patterns.....................................................................44

4.2.1 Customizing Presets........................................................................................44

4.2.2 Calling Presets.................................................................................................45

4.2.3 Customizing Patrols........................................................................................46

4.2.4 Calling Patrols.................................................................................................48

4.2.5 Customizing Patterns ......................................................................................49

4.2.6 Calling Patterns...............................................................................................50

4.3 PTZ Control Toolbar..................................................................................................51

C H AP T E R 5......................................................................................................................52

Record Settings.......................................................................................................................52

5.1 Configuring Encoding Parameters.............................................................................53

5.2 Configuring Record Schedule....................................................................................56

5.3 Configuring Motion Detection Record ......................................................................59

5.4 Configuring Alarm Triggered Record........................................................................61

5.5 Configuring Manual Record ......................................................................................64

Autres manuels pour DS-7200-SH

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels HIK VISION DVR

HIK VISION

HIK VISION DS-9104HFI-ST series Guide de l'utilisateur

HIK VISION

HIK VISION DS-7300HI-S Series Manuel utilisateur

HIK VISION

HIK VISION DS-7200-ST Series Manuel utilisateur

HIK VISION

HIK VISION DS-7004HI Manuel utilisateur

HIK VISION

HIK VISION DS-7300 Series Manuel utilisateur

HIK VISION

HIK VISION DS-9000 Series Manuel utilisateur

HIK VISION

HIK VISION DS-7100HGHI-K1/R Series Manuel utilisateur

HIK VISION

HIK VISION DS-8004HSI-S Manuel utilisateur

HIK VISION

HIK VISION DS-6701HFI Guide de l'utilisateur

HIK VISION

HIK VISION DS-7300HFI-S Series Manuel utilisateur

HIK VISION

HIK VISION DS-MP3516-RS/GW Manuel utilisateur

HIK VISION

HIK VISION DS-8104AHGHLI-E4 Manuel utilisateur

HIK VISION

HIK VISION DS-9216HWI-ST Manuel utilisateur

HIK VISION

HIK VISION iDS-7200AHQHI-M Series Manuel utilisateur

HIK VISION

HIK VISION DS-7100HWI-SL Series Manuel utilisateur

HIK VISION

HIK VISION DS-7300HI-S Series Manuel utilisateur

HIK VISION

HIK VISION DS-MP5504 Series Manuel utilisateur

HIK VISION

HIK VISION HiLook Series Manuel utilisateur

HIK VISION

HIK VISION Ds-7604ni-e1, ds-7608ni-e1 Manuel utilisateur

HIK VISION

HIK VISION DS-90 HWI-ST Series Manuel utilisateur

HIK VISION

HIK VISION DS-8000 Series Manuel utilisateur

HIK VISION

HIK VISION DS-7208 Manuel utilisateur

HIK VISION

HIK VISION DS-7200HGHI-K1 Series Manuel utilisateur

HIK VISION

HIK VISION DS-7104NI-K1/W/M(C) Manuel utilisateur

Manuels DVR populaires d'autres marques

FLIR

FLIR M3100E Series Manuel utilisateur

VTRACKPRO

VTRACKPRO FPRO300 Manuel utilisateur

Swann

Swann NVR-7085 models Manuel utilisateur

XtendLan

XtendLan DVR-1670C Manuel utilisateur

urmet domus

urmet domus 1093/004AHD Manuel utilisateur

Holux

Holux M1 Manuel utilisateur

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manuel utilisateur

Whistler

Whistler D16VRS Manuel utilisateur

Defender Security

Defender Security 82-20235 Manuel utilisateur

MISUMI

MISUMI MP-WF100M Manuel utilisateur

Speco

Speco D8HU Manuel utilisateur

UST

UST DDR-E04AA Instructions d'utilisation

Consolidated

Consolidated Digital Video Recorder Manuel utilisateur

Mace

Mace DVR0404RW Guide de démarrage rapide

RCA

RCA RTD315W Manuel utilisateur

FSM

FSM Colibri Grande PRO Manuel utilisateur

Hauppauge

Hauppauge HD PVR 2 Manuel utilisateur

Identivision

Identivision ICR-PH161i PIONEER Manuel utilisateur
