HIK VISION DS-6101HLI Manuel utilisateur

Technical Manual

http://www.securityone.com.ar

http://www.hikvision.com/

DS-6101HLI Portable Video Recorder

Technical Manual

http://www.securityone.com.ar

http://www.hikvision.com/

Notices

The information in this documentation is subject to change without notice and does

not represent any commitment on behalf of HIKVISION. HIKVISION disclaims any

liability whatsoever for incorrect data that may appear in this documentation. The

product(s) described in this documentation are furnished subject to a license and

may only be used in accordance with the terms and conditions of such license.

This documentation is issued in strict confidence and is to be used only for

the purposes for which it is supplied. It may not be reproduced in whole or in

part, in any form, or by any means or be used for any other purpose without prior

written consent of HIKVISION and then only on the condition that this notice is

included in any such reproduction. No information as to the contents or subject

matter of this documentation, or any part thereof, or arising directly or indirectly

therefrom, shall be given orally or in writing or shall be communicated in any

manner whatsoever to any third party being an individual, firm, or company or any

employee thereof without the prior written consent of HIKVISION. Use of this

product is subject to acceptance of the HIKVISION agreement required to use this

product. HIKVISION reserves the right to make changes to its products as

circumstances may warrant, without notice.

This documentation is provided “as-is,” without warranty of any kind.

Please send any comments regarding the documentation to:

overseabusiness@hikvision.com

Find out more about HIKVISION at www.hikvision.com

Technical Manual

http://www.securityone.com.ar

http://www.hikvision.com/

Overview

The Portable Video Recorder is the professional surveillance product

designed for mobile handheld. It is integrated with the LCD monitor, 3G wireless

communication module, GPS module, battery power supply, line controller,

micro camera and headphone. The recorder uses the standard H.264 algorithm

and supports local menu settings, local Micro SD card recording, playback

functions, as well as access to the CMS platform.

DS-6101HLI Series Portable Video Recorder

Technical Manual

http://www.securityone.com.ar

http://www.hikvision.com/

Order Models

DS-6101HLI

Technical Manual

http://www.securityone.com.ar

http://www.hikvision.com/

Main Features

1-channel Video & Audio input;

Support up to 640×480 resolution;

LCD screen;

3G wireless transmission;

Micro SD storage.

Technical Manual

http://www.securityone.com.ar

http://www.hikvision.com/

Functions & Performance

Basic Functions

•Compression: H.264 video compression and OggVorbis audio compression.

•Network: support TCP/IP wireless transmission, including video, audio,

alarm, voice and serial device data.

•Embedded 3G module, access to CMS platform.

•Voice talk: two-way and duplex

•Portable shape: convenient operation and use.

•Friendly GUI and menu.

•Integrate GPS module, correctly to locate and upload to center.

•Support controller to alarm and capture picture.

•Built-in lithium battery, easy to replace.

•Auto switch of power saving mode, extending working time of battery.

•Mini USB port mode switchable, master mode for 3G module and other USB

devices to the recorder such like USB-disk, slave mode for PC access the

micro SD inside file.

Compression Functions

•1-channel video signal, 25 fps independent hardware compression, variable

and constant bitrate, user could set the video quality and limit the video

bitrate.

•VGA (640×480), QVGA(320×240)resolution supported.

•OSD, date and time settings.

•Text overlay.

Technical Manual

http://www.securityone.com.ar

http://www.hikvision.com/

Typical Applications

It is applicable to the surveillance requirements in various fields, such as:

•Traffic enforcement actions

•Urban enforcement actions

•Remote judgment for insurance

Technical Manual

http://www.securityone.com.ar

http://www.hikvision.com/

Panels & Interfaces

Front Panel Left Panel

1. Control line interface

2. Status indicator

3. Right-side button

4. 3G antenna interface

5. MICRO SD, mini USB and power interface

6. Front panel operation buttons

7. 12V power supply interface

8. mini USB interface

9. MICRO SD card slot

Technical Manual

http://www.securityone.com.ar

http://www.hikvision.com/

Specifications

Model

DS-6101HLI

Video/Audio

Input

Video

compression

H.264

Analog video

input

1-ch, PAL/NTSC self-adaptive, 420TVL

Audio

compression

OggVorbis

Audio input

1-ch, headphone

Video/Audio

Output

Resolution

Main stream: VGA, QVGA;

Sub stream: QVGA, VGA

Frame rate

PAL: 1—25fps, NTSC: 1—30fps

Video bitrate

Main stream: 32Kbps-2048Kbps;

Sub stream: 32Kbps-1024Kbps

LCD

QVGA resolution

Audio output

1-ch, connected to earphone

Audio bitrate

16kbps

Storage

Type

microSD(TF) Card

Max. capacity

Max. 32G

LCD

Size

2.8 inch

Type

TFT

Resolution

240×320

Network

Wireless

TD-SCDMA / EVDO/ WCDMA

Other

miniUSB

interface

1, USB2.0

Line control

Alarm, capture buttons, headphone, micro

camera

Battery

7.4V/2200mAh

Size(mm)

117mm(H)×65mm(W)×38mm(D)

Weight

360g(not include accessories)

Charge time

3-3.5h

Discharge time

>4h

Working

temperature

-10℃～+50℃

Working

humidity

10%～90%
