How to use 1006KI control analog PTZ which is

directly connected

If you want to use the 1006KI to connect more than 1 PTZ directly by RS485 without

DVR, you need to make sure you use the parallel connection.

1. Open the device and choose SET button.

2. Choose the System

3. Go to the Serial Port and Choose ① RS-485

4. Then you can see this page. The Add. Bit0 is the Broadcast address which means if

you choose this channel, you can control all PTZ in the same time. But if you want

to control the different PTZ, you need to set different Add. Bit for all of them. (You

should notice that this Add need to match the address on the device.)

E.g. If the SW1 switch on the PTZ 1 is 1, we need to set our Add. Bit as 1 too. And

normally the default Baud Rate is 2400. For the Protocol, you can choose the

HIKVISION. Then press OK button to save the setting. Then we have finished 1

PTZ’s setting. You also need to configure another 4

Notice: I have confirm with R&D colleague that all kinds of analog speed dome

have the DIP Switch. So you just need to find it. And make sure PTZ have the

different address and do the setting as I mentioned above.

5. Then press the MODE button to pick the control mode : 6. To Analog Dev

6. If you want to control the PTZ which address is 1, you can press the button 1 and

CAM. Then you can use the joystick to control it. For another PTZ, you can also do

the operation as the same. Just remember they need to set the different address.

1

2

Thanks
