Hi-view HP-9511DIR Manuel utilisateur

2 Mega Pixel

Water-Proof IR Network Camera

User Manual

Please read this instruction carefully for correct use of the product

Before use this product

Before operation, we strongly advise users to read this manual and keep it

properly for using later.

This is product instructions not quality warranty. We may reserve the rights of

amending the typographical errors, inconsistencies with the latest version,

software upgrades and product improvements, interpretation and modification.

These changes will be published in the latest version without special notification.

When this product is in use, the relevant contents of Microsoft, Apple and Google

will be involved in. The pictures and screenshots in this manual are only used to

explain the usage of our product. The ownerships of trademarks, logos and other

intellectual properties related to Microsoft, Apple and Google belong to the

above-mentioned companies.

IP CAMERA USER MUANUAL

Table of Contents

1Introduction.........................................................................................................1

1.1 Summarization.........................................................................................................................1

1.2 Check Package Content.............................................................................................................1

1.3 Connection ..............................................................................................................................1

2Installation ..........................................................................................................3

2.1 Install IP-CAM to Ethernet Network....................................................................................3

2.2 Install CMS......................................................................................................................3

3IE Remote Access.................................................................................................5

3.1 LAN................................................................................................................................5

3.1.1 Access through IP-Tool .......................................................................................5

3.1.2 Directly Access through IE...................................................................................7

3.2 WAN...............................................................................................................................8

4Remote Preview ...................................................................................................9

4.1 The Remote Preview Interface ............................................................................................9

4.2 Record Playback ...............................................................................................................9

4.3 Right-click Function ........................................................................................................10

4.4 Snap Pictures..................................................................................................................10

5Remote Live Surveillance...................................................................................12

5.1 System Configuration ......................................................................................................12

5.1.1 Basic Information .............................................................................................12

5.1.2 Date & Time Configuration................................................................................13

5.2 Video Configuration ........................................................................................................13

5.2.1 Camera Configuration .......................................................................................13

5.2.2 Video Stream...................................................................................................14

5.2.3 Time Stamp .....................................................................................................14

5.2.4 Video Mask .....................................................................................................15

5.3 Alarm Configuration........................................................................................................15

5.3.1 Motion Detection Area ......................................................................................15

5.3.2 Motion Detection Trigger...................................................................................16

5.3.3 Motion Detection Schedule ................................................................................17

5.4 Network Configuration ....................................................................................................17

5.4.1 Port.................................................................................................................17

5.4.2 Wired..............................................................................................................18

5.4.3 NET Traversal Configuration..............................................................................18

5.4.4 Server Configuration.........................................................................................19

5.4.5 IP Notify .........................................................................................................20

5.4.6 DDNS Configuration.........................................................................................20

5.4.7 RTSP ..............................................................................................................22

5.4.8 UPNP .............................................................................................................23

5.4.9 Mail Setting.....................................................................................................24

5.4.10 FTP ................................................................................................................24

5.5 Advanced Configuration...................................................................................................25

IP CAMERA USER MUANUAL

5.5.1 User Configuration ...........................................................................................25

5.5.2 Onvif Configuration..........................................................................................27

5.5.3 Security Configuration ......................................................................................27

5.5.4 Configure Backup & Restore..............................................................................28

5.5.5 Reboot Device..................................................................................................28

5.5.6 Upgrade ..........................................................................................................29

6Mobile Surveillance ...........................................................................................30

6.1 Network Configuration ....................................................................................................30

6.2 By Phones with iPhone OS...............................................................................................30

6.3 By Phones with Android OS .............................................................................................40

7Use method for IP-TOOL...................................................................................46

8Q & A................................................................................................................49

9Specification ......................................................................................................51

Page 1

IP CAMERA USER MUANUAL

1Introduction

1.1 Summarization

This IP-CAMERA (short for IP-CAM) is designed for high performance CCTV

solutions. It adopts state of the art video processing chips. It utilizes most advanced

technologies, such as video encoding and decoding technology, complies with the

TCP/IP protocol, SoC, etc to ensure this system more stable and reliable. This unit

consists of two parts: the IP-CAM device and central management software (short for

CMS). The CMS centralizes all devices together via internet or LAN and establishes a

sound surveillance system to realize unified management and remote operation to all

devices in one network.

This product is widely used in banks, telecommunication systems, electricity power

departments, law systems, factories, storehouses, uptowns, etc. In addition, it is also an

ideal choice for surveillance sites with middle or high risks.

1.2 Check Package Content

The pictures below are only for reference. Please make the object as the standard.

Accessories

Description

IP-CAMERA

The device without Lens

Quick Start Guide

The Brief instructions of the product

CD-ROM with software and manual

Screws and Screwdriver

For installation

1.3 Connection

MIC: connect to MIC

DC12V: connect to power supply

LAN: network port (some models support PoE power supply)

Some models of this series support internal focusing. The steps are as follows:

Page 2

IP CAMERA USER MUANUAL

Focus Zoom

Step 1: Remove the sun shade and lens case from the device as shown above.

Step 2: Loosen the screws of the lens for focusing. Then rotate the lens left or right to

adjust the focus.

Focus: Rotate left or right to adjust definition of the image.

Zoom: Rotate left or right to zoom in or out the image.

Page 3

IP CAMERA USER MUANUAL

2Installation

2.1 Install IP-CAM to Ethernet Network

The connection of digital video server is show below.

Figure 2-1 Connection

Please connect the PC and IP-CAMERAin accordance with the above picture.

The connection steps are shown as below:

Step 1: Connect the monitor, microphone and network to the device.

Step 2: Connect the power supply.

Step 3: Install the device.

2.2 Install CMS

After the CDD IP-CAM connected to the Ethernet, user can remote monitoring and

managing the device by using client software or IE browser. This chapter is the client

software, which is the quick install guide of the CMS, the operation and monitor setting

details please refers to CMS user manual in CD.

Note: Before to install control center software in user’s computer, please make sure

all anti-virus software in the computer closed so that CMS can install correctly.

System requirement

Supported Operating System:

Operating system

Comments

Windows XP

Windows XP SP2 or most updated patch; Direct 9.0c or above

Windows Vista

Windows Vista; Direct 10. c

Window 7

Window 7 Ultimate

Windows 2003

Windows 2003 serve or Directx 9.0c or above

Windows 2000

Windows 2000 SP4 or Directx 9.0c or above

Computer hardware requirement

Please make sure the software running well and the computer is compatible ：

Recommended PC Specification –4 channels

Page 4

IP CAMERA USER MUANUAL

Item

Specification

CPU

Intel Pentium 3.0 GHz orAMD 3000+

Memory

1GB

HDD

160GB

Recommended PC Specification -9 channels:

Item

Specification

CPU

Intel Core 2 Duo 1.8 GHz orAMD Dual core 3800+

Memory

1GB

HDD

250GB

Recommended PC Specification -16 channels:

Item

Specification

CPU

Intel Core 2 Duo 2.2 GHz orAMD Dual core 3800+

Memory

2GB

HDD

250GB

Notice:

The AMD chip hyper-3800+ and X64 series are not tested.

For real-time view at CIF, max 25 channels can be played concurrently.

For real-time view at D1, max 6 channels can be played concurrently.

Installation Process

It is recommended to disable the anti-virus software before the installation of CMS.

1. Run the „Setup.exe‟ from software CD. Then install CMS according to the prompts.

2. After you install this software, double click it to run if necessary.

3. Find the user manual of the control center system from programs. You can operate

this software according to the introduction of this user manual.

If you just want to user IP-tool, there is no necessary to install CMS software. You can

open the CD and find the IP-tool software and double click it to install.

Page 5

IP CAMERA USER MUANUAL

3IE Remote Access

IP-Cam can be connected through LAN or WAN. Here only take IE browser (6.0)

for example. The details are as follows:

3.1 LAN

In LAN, there are two ways to access IP-Cam: 1. Access through IP-Tool; 2. Directly

access through IE browser.

3.1.1 Access through IP-Tool

Step 1: Make sure the PC and IP-Cam are connected to the LAN and the IP-Tool is

installed in the PC from the CD.

Step 2: Use IP-Tool to modify the network of IP-Cam. Then, double click the icon

on the desktop to run this software as shown below:

After starting IP-Tool, clicking the IP-Cam name in the list can display the detail

information of IP-Cam. If you cannot confirm which one is yours, please shut off the

electricity of the IP-Cam and then power on it. When shutting off the power, the device

information will disappear. When powering on, the device information will emerge. Well,

this device is the used device. Right click the device information and select “network

setup”. Then the network setup window will pop up as shown below:

Page 6

IP CAMERA USER MUANUAL

For example, the network segment of this computer is 192.168.13.x under the local

config table. So, please modify the IP address, Gateway of IP-Cam which must be in the

same network segment with the computer. Modifying the network, you have to input the

password and click “OK” button to save the setting.

Note: The default user name is: admin. The default password is: 123456.

The new IP address of this device will display as follows after modification.

Step 3: Use the IP-Tool to login the IP-Cam.

Right-click the IP address and select “browse with IE” or double click the information

of this device. The IE browser will auto download the Active X control. If the IE

browser cannot download the Active X control, please refer to Q4 of Chapter 9. After

the completion of the installation of the Active X control, a login window will pop up.

Input User name and password and then click “OK” button to login.

Note: You can also use the modified IP address of the IP-Cam. Input the IP address in

the IE browser bar and then click “Enter” to access IP-Cam. The default user name is

admin. The default password is 123456.

Table des matières

Autres manuels Hi-view Caméra IP

Hi-view

Hi-view HLC-36BM Manuel utilisateur

Manuels Caméra IP populaires d'autres marques

FLIR

FLIR Exx series Manuel utilisateur

Avigilon

Avigilon H4A-BO1-IR Manuel utilisateur

Digital Watchdog

Digital Watchdog DWCA-C128-64 Manuel utilisateur

ShareTech

ShareTech AV1 Manuel utilisateur

Ezviz

Ezviz C6C Manuel utilisateur

Melchioni

Melchioni UCAM 2015 Manuel utilisateur

Geutebruck

Geutebruck G-Cam/ESD-4630 Manuel utilisateur

Arecont Vision

Arecont Vision MegaBall AV3146DN-3310-D-LG Manuel utilisateur

Mitel

Mitel 6800i Series Manuel de service

Vitek

Vitek VTC-IR403-212NP Manuel utilisateur

THOMSON

THOMSON DSC - 323W Manuel utilisateur

AVer

AVer FB2027 Manuel utilisateur

ENFORCER

ENFORCER EV-T5105-N2SQ Manuel utilisateur

Wansview

Wansview NC543 Manuel utilisateur

Eneo

Eneo MCB-64A0003M0A Manuel utilisateur

deView electronics

deView electronics CBDNI36F Manuel utilisateur

Swann

Swann SwannEye Manuel utilisateur

LevelOne

LevelOne IP CamSecure Manuel utilisateur
