HH PolarCool 18" Manuel utilisateur

4801-5035A 28 January 2021

Evaporative Cooling System User Manual

4801-5035A 28 January 2021

Evaporative Cooling System User Manual

Section 1: Introduction............................................................................................................................................

Section 1.1: Definitions of Informational Headings............................................................................................................................

Section 1.2: Scope of Manual...............................................................................................................................................................

Section 1.3: Limited Warranty..............................................................................................................................................................

Section 1.4: Overview...........................................................................................................................................................................

Section 1.4.1: Technical Specifications...................................................................................................................................................

Section 2: Setup......................................................................................................................................................

Section 2.1: Install Casters (18" Units Only)........................................................................................................................................

Section 2.2: Float Valve........................................................................................................................................................................

Section 3: Operation...............................................................................................................................................

Section 3.1: Components.....................................................................................................................................................................

Section 3.1.1: Fan Motor..........................................................................................................................................................................

Section 3.1.2: Water Pump......................................................................................................................................................................

Section 3.1.3: Control Panel (All Units) and Control Board (Not on 48" Units).....................................................................................

Section 3.1.4: Cooling Pads.....................................................................................................................................................................

Section 3.1.5: Float Valve........................................................................................................................................................................

Section 3.1.6: Liquid Level Switch (18", 24", and 36" Units)...................................................................................................................

Section 3.2: Controls............................................................................................................................................................................

Section 3.2.1: 18", 24", and 36" Variable-Speed Units............................................................................................................................

Section 3.2.2: 48" Single-Speed Units.....................................................................................................................................................

Section 3.3: Starting.............................................................................................................................................................................

Section 3.4: Shutting Down.................................................................................................................................................................

Section 4: Maintenance...........................................................................................................................................

Section 4.1: Regular Preventive Maintenance....................................................................................................................................

Section 4.2: Cooling Pads.....................................................................................................................................................................

Section 4.2.1: Cleaning and Replacement.............................................................................................................................................

Section 4.2.2: Breaking in New Cooling Pads.........................................................................................................................................

Section 4.3: Cleaning Spray Bar...........................................................................................................................................................

Section 4.4: Adjusting Water Pressure.................................................................................................................................................

Section 4.5: Changing Reservoir Water Level......................................................................................................................................

Section 4.6: Cleaning Reservoir...........................................................................................................................................................

Section 4.7: Cleaning Pump Filter........................................................................................................................................................

Section 4.8: Inspecting and Adjusting Fan Belt (48" Units Only).......................................................................................................

Section 4.9: Long-Term Storage...........................................................................................................................................................

Section 5: Troubleshooting......................................................................................................................................

Section 6: Replacement Parts..................................................................................................................................

Section 6.1: 18" Units...........................................................................................................................................................................

Section 6.2: 24" Units...........................................................................................................................................................................

Section 6.3: 36" Units...........................................................................................................................................................................

Section 6.4: 48" Units...........................................................................................................................................................................

Section 7: Wiring Diagrams......................................................................................................................................

Section 7.1: 18", 24", and 36" Units......................................................................................................................................................

Section 7.2: 48" Units...........................................................................................................................................................................

Section 8: Warnings/Avertissements.........................................................................................................................

Table of Contents

4801-5035A 28 January 2021

Evaporative Cooling System User Manual

Section 1.1: Definitions of Informational Headings

• DANGER: This heading indicates noncompliance with the stated information will lead to serious injury or death.

• WARNING: This heading indicates noncompliance with the stated information may lead to serious injury or death.

• CAUTION: This heading indicates noncompliance with the stated information may lead to minor or moderate injury.

• NOTICE: This heading draws attention to specific information.

Section 1.2: Scope of Manual

Section 1: Introduction

NOTICE: This document is subject to change without notice. The latest version is maintained at rollseal.net/rollseal-technicals/.

4801-5035A 28 January 2021

Evaporative Cooling System User Manual

Section 1.3: Limited Warranty

For three years from the date of invoice, PolarCool (a division of HH Technologies, Inc.) warrants the motor and any electrical

components of the PolarCool Evaporative Cooling System ("the Product") that are found, upon examination by factory-authorized

personnel, to be defective in material and/or workmanship.

PolarCool also warrants the metal housing of the Product for the full lifetime of the Product to the extent it is found, upon

examination by factory-authorized personnel, to be defective in material and/or workmanship. The Lifetime Warranty on the

Product housing does not cover ordinary wear and tear.

If any of the original component parts, including the Product housing, exhibit any defect(s) covered by this Limited Warranty

within the applicable time periods defined above, the same may be repaired or replaced at PolarCool's discretion.

This Limited Warranty excludes any labor, equipment, transportation, and/or service expenses that may be required to remedy the

warranted defect(s); all such charges must be funded by the purchaser. Neither the Product nor any of its component parts are to

be returned for repair or replacement until they have been inspected and/or a Return Goods Authorization (RGA) number has been

issued.

Complaints are to be directed first to the authorized distributor who sold the Product. If satisfaction is not obtained and/or the

distributor cannot be contacted, complete the warranty form at https://polarcool.net/polarcool-return-policy/.

This Limited Warranty is void if: a) the Product and/or any of its component parts are found to have been misused, abused, or

otherwise tampered with by unqualified personnel; b) any of the Product's component parts have been replaced by anything

other than authorized PolarCool replacement parts; c) the Product has been modified in any way other than oicially sanctioned

upgrades made by qualified personnel using authorized PolarCool accessories; d) the Product has not been appropriately

registered by its original purchaser; or e) the customer cannot provide proof of purchase indicating them to be the Product's

original owner.

This Limited Warranty is made solely to the original purchaser of the Product. It cannot be transferred.

This Limited Warranty is in lieu of any and all other representations and/or warranties, expressed or implied, including any implied

warranty of merchantability and/or fitness for a particular purpose. The remedy set forth by this Limited Warranty shall be the

exclusive remedy available to any entity. No entity has the authority to bind PolarCool to any representation or warranty other

than this Limited Warranty. PolarCool shall not be liable for any damages or losses resulting from any application of the Product or

caused by any defect, failure, or malfunction of the Product.

This Limited Warranty gives you specific legal rights. You may have additional rights, as some areas do not allow the exclusion or

limitation of incidental or consequential damages. The above limitation or exclusion may therefore not apply to you.

Warrantor: HH Technologies, Inc. (d.b.a. RollSeal)

Address: 1733 County Road 68; Bremen, AL 35033

Phone: 256-287-7000

Email: customerservic[email protected]

4801-5035A 28 January 2021

Evaporative Cooling System User Manual

Section 1.4: Overview

The PolarCool Evaporative Cooling System (henceforth referred to as "the unit") reduces air temperature by drawing warm

ambient air across a water-soaked surface (the cooling pads), evaporating the water and dissipating the heat it has absorbed.

Simple controls make the unit easy to operate, and the overall design permits straightforward cleaning and maintenance. Casters

allow the unit to be moved by hand and set up anywhere with proper water and power supplies.

Section 1.4.1: Technical Specifications

18"

Variable-Speed

24"

Variable-Speed

36"

Variable-Speed

48"

Single-Speed

Unit Dimensions

(H xW xD) 49-1/2" x 24" x 20" 37" x 48" x 35" 61" x 63" x 36" 73" x 74" x 35"

Shipping Dimensions

(H xW xD) 50" x 36" x 24" 47" x 56" x 40" 69" x 70" x 43" 80" x 84" x 44"

Empty Weight 134 lbs 310 lbs 481 lbs 625 lbs

Drive Direct Direct Direct Belt

Noise Level

(Low; Medium; High) 19.4 dB; 24.8 dB; 29.1 dB 18.5 db; N/A; 37 dB N/A; 22 db; 31 dB N/A; N/A; 35.2 dB

Water Consumption* 5 Gallons per Hour 7 Gallons per Hour 12 Gallons per Hour 17 Gallons per Hour

Reservoir Volume 10 Gallons 9 Gallons 12.5 Gallons 13.5 Gallons

Power Consumption 5A at 115V; 60 Hz 6A at 115V; 60 Hz 10A at 115V; 60 Hz 11A at 230V; 60 Hz

Cooling Area 800 21,200 23,000 24,000 2

Current 4.9A 6A 8.5A 9.5A

Typical Air Movement†3,000 CFM 4,400 CFM 10,000 CFM 17,500 CFM

*Assuming ≥ 90°F conditions. Cooler temperatures will result in less water usage.

†Depending on relative humidity, temperature, and area being cooled.

4801-5035A 28 January 2021

Evaporative Cooling System User Manual

Section 2: Setup

Section 2.1: Install Casters (18" Units Only)

NOTICE: 24", 36", and 48" units are shipped with their casters pre-installed. If you have such a unit, skip to Section 2.2.

CAUTION: The unit is very heavy. Ensure it is well supported while you install the casters.

1. Align one of the caster brackets with one of the caster support channels on the bottom of the assemby.

2. Run four 5/16"-18 x 3/4" carriage bolts through the bracket and the support channel.

3. Place a 5/16" washer and a 5/16"-18 nylon insert nut on each of the bolts, then tighten the nuts until they are fully seated.

4. Repeat Steps 1-3 on the remaining casters.

4801-5035A 28 January 2021

Evaporative Cooling System User Manual

Section 2.2: Float Valve

1. Li the cover at the top of the unit to access the cooling pads.

2. Remove the cooling pads, titling the spray bar if necessary.

3. Hold the float valve in place while peeling the tape from it. Be careful not to bend the float valve arm.

4. Reinstall the cooling pads, ensuring the "UP" and "Air Flow" arrows are oriented properly. Reorient the spray bar if necessary.

5. Close the cover.

4801-5035A 28 January 2021

Evaporative Cooling System User Manual

Section 3: Operation

The unit operates by pumping water from the reservoir through the spray bar to soak the cooling pads. Meanwhile, the propeller

draws warm air through the pads. The water evaporates as it pulled away from the pads; this evaporation dissipates the heat the

water has absorbed from the incoming air, thus cooling the outgoing air. Excess water returns to the reservoir to be recirculated.

Evaporative cooling reduces the dierence between the area's dry-bulb temperature (DBT; i.e. regular air temperature) and

wet-bulb temperature (WBT; i.e. temperature at 100% relative humidity) with approximately 75% eiciency. For example, at a DBT

of 85°F and a WBT of 65°F (a dierence of 20°F), the temperature on the outlet side of the unit would be reduced to approximately

70°F (a decrease of 15°F).

Section 3.1: Components

Section 3.1.1: Fan Motor

On 18", 24", and 36" units, the 115V fan motor can be operated at various speeds using the control panel. The propeller is mounted

directly to and driven directly by the motor sha.

On 48" units, the 240V fan motor can be operated at only one fixed speed. The motor is mounted to the side of the fan sha. It uses

a belt-and-pulley system to drive the propeller.

4801-5035A 28 January 2021

Evaporative Cooling System User Manual

Section 3.1.3: Control Panel (All Units) and Control Board (Not on 48" Units)

The control panel is located on the right side of the unit. It is the primary means of starting and stopping the fan and the pump.

On 18", 24", and 36" units, the control panel is connected to the control board (itself mounted inside the electronics enclosure),

which handles all operational logic. The board enables variable-speed operation and low-water-level pump shuto. The control

panel has multiple buttons that control fan power, fan speed, and pump power. It also has several LEDs that indicate the fan

status, fan speed, pump status, and water level status.

On 48" units, the control panel has a pair of toggle switches that turn the fan and pump on and o. There is no control board.

Section 3.1.4: Cooling Pads

These 8"-thick paper-based blocks are a key part of the evaporative cooling process. As they are saturated with water, warm air is

drawn through them to dissipate the absorbed heat by evaporation. They are coated for protection against both impacts and algae

formation. They must be installed in the labeled orientation to allow proper airflow.

Section 3.1.6: Liquid Level Switch (18", 24", and 36" Units)

When this switch senses the water in the reservoir is too low, it signals the control board to stop the pump, preventing it from

running dry.

Section 3.1.5: Float Valve

This brass valve, connected to the water inlet inside the unit, shuts o the inlet when the water in the reservoir reaches the depth

to which the valve has been set. This prevents the reservoir from being overfilled.

Section 3.1.2: Water Pump

The pump moves water from the reservoir through the spray bar and onto the cooling pads.

On 18", 24", and 36" units, the 115V pump is turned on and o using a button on the control panel. The unit control board has

low-water-level protection logic that prevents the pump from running without adequate water in the reservoir.

On 48" units, the 240V pump is turned on and o using a switch on the control panel. The pump does not have low-water-level

protection since there is no control board.

4801-5035A 28 January 2021

Evaporative Cooling System User Manual

Section 3.2: Controls

Section 3.2.1: 18", 24", and 36" Variable-Speed Units

On a 18", 24", or 36" variable-speed unit, the control panel has the following inputs:

1. Fan Power - This button starts and stops the fan.

2. Fan Speed - These buttons adjust the speed of the fan between 10 presets. The "+" button increases the speed by one

increment, whereas the "-" button decreases the speed by one increment. The "-" button cannot be used to stop the fan.

The speed is indicated by the highest LED currently illuminated. Each LED corresponds to two speeds, with flashing

representing odd values (i.e. 1, 3, 5, 7, or 9) and solid green representing even values (i.e. 2, 4, 6, 8, or 10). For example, if the

bottom LED is flashing by itself, the speed is set to 1; if the first three LEDs are solid green, the speed is set to 6.

3. Pump Power - This button starts and stops the water pump.

The Pump section of the control panel also has the following indicator LEDs:

1. Unit Power - This LED (located behind the bottom logo) is solid red when the unit is powered on.

2. Pump ON - This LED is solid green while the pump is running.

3. Fill - This LED flashes green when the water level remains low for more than one minute. During this time, the pump will

automatically turn o, the Pump ON and Fill indicators will flash, and the Low Water indicator will turn solid red.

4. Low Water - This LED flashes red when the water remains low for less than one minute. Aer one minute, it turns solid red.

Ce manuel convient aux modèles suivants

Table des matières

Manuels Congélateur populaires d'autres marques

Siemens

Siemens GU..D SERIES Manuel utilisateur

Omcan

Omcan FR-CN-0155 Manuel utilisateur

Beko

Beko FNE290E24W Manuel utilisateur

Electrolux

Electrolux ARCTIS G 8 60 50-6I Manuel utilisateur

Electrolux

Electrolux EUF2042AOX Manuel utilisateur

Dometic

Dometic CoolFreeze CFX95DZ Manuel utilisateur

Electrolux

Electrolux EUF7000W1 Manuel utilisateur

Polar Electro

Polar Electro CT330 Manuel utilisateur

MPM

MPM MPM-145-SK Series Manuel utilisateur

SAF

SAF PRESTOTIG 200AC/DC Guide rapide

Zanussi

Zanussi ZFT11407WA Manuel utilisateur

AEG

AEG A63190GT Manuel utilisateur

AEG

AEG A81000TNW0 Manuel utilisateur

Matsui

Matsui MUC50S15E Manuel utilisateur

NEFF

NEFF G4344X8 Manuel utilisateur

Frigidaire

Frigidaire FV 1246 H Manuel utilisateur

Frigidaire

Frigidaire FFC13K1AW Manuel utilisateur

Electrolux

Electrolux EU 2400C Manuel utilisateur
