HETCH BFS-1121-HC Manuel utilisateur
Body Fat/Hydration
Monitor Scale
Model No. : BFS-1121-HC
INTIMATE HEALTH ANALYZER
Size : 160 x 105mm
HETCH Body Fat/Hydration Monitor Scale (user manual)
Paper : 230gsm Art Card (cover matt laminate)
. User Friendly Tips
. Features/Specifications
. To Install or Replace Battery
. Performance Index
. Key Illustration
. LCD Display
. To Set Weight Unit
. Optional Normal Weighing Mode
. Warning Indications
. About Fat & Calorie
. Advise for Use & Care
. Warranty Card
A
B
C
D
E
F
G
H
I
J
K
L
Page : 2
A. USER FRIENDLY TIPS
The devise is designed to allow auto step on. Please always ignore the first reading and only start taking
effective record from the second time weighing.
Always remove your shoes and socks, wipe clean your feet before using.
Step on the weighing platform gently.
It is advisable to take measurement at the same time of the day.
Measured result could be misleading after intensive exercise, excessive dieting or under extreme dehydration
condition.
Always weigh/use the scale on a hard and flat surface.
The measured date of the following people may have deviation :
• Children under 10 or adult over 100 (can only use the devise under normal weighing mode)
• Adult over 70
• Body building athletes or other occupational athletes
People with the following conditions should not use the device :
• Pregnant women
• Those with symptom of edema
• Those on dialysis treatment
• Those who use heart pacemaker or with other implanted medical device
A.
B.
C.
D.
E.
F.
G.
H.
1. During measuring
Page : 3
A. USER FRIENDLY TIPS
B. FEATURES/SPECIFICATIONS
Using high precision strain gauge sensor.
Multifunction : test body fat%, body hydration%, body muscle%, body bone% and suggest calorie intake
requirement.
Built-in memory for 12 different users.
Optional normal weighing mode
(by passing parameter setting : Auto step on weighing and consecutive add on weighings.)
Low battery and overload indication.
1.
2.
3.
4.
5.
The Fat% Hydration% content evaluated by the Fat Monitor Scale is only for reference (not for medical purpose).
If your Fat% Hydration% content is over/below normal level, please consult your doctor for more advice.
Keep away from strong electro-magnetic field when using the scale.
It could be slippery if you weigh on a wet surface. Moreover, if the weighing platform surface is glazed, never step
on the edge of the scale and do keep balance during your weighing.
A.
B.
C.
2. Safety warning
Page : 4
C. TO INSTALL OR REPLACE BATTERY
Note : 1x3V CR2032 lithium batteries (included). Remove isolation sheet before use.
Open the battery case cover at the bottom of scale :
Take out the used battery with the aid of a sharp object, as shown in
picture.
Install new battery by putting one side of the battery beneath the battery
baffle and then pressing down the other side.
A.
B.
Open the battery case cover at the bottom of scale :
Press battery gently, the battery will pop up automatically.
Install new battery by connecting one side of battery to positive plate
first, and then pressing down the other side. Please observe the polarity.
A.
B.
The battery type of scale depends on the product structure. Find the battery type of your scale according to
the following pictures, then install and replace battery as described.
Page : 5
D. PERFORMANCE INDEX
E. KEY ILLUSTRATION
Turn on the scale and prompt to next parameter.
(Please refer to the Setting Personal Parameter overleaf)
Advance the value by one interval each press. Continuous pressing will speed up the
advance of value.
Decrease the value by one interval each press. Continuous pressing will speed up the
advance of value.
Set (ON/SET) :
▲ :
▼ :
Page : 6
F. LCD DISPLAY
Page : 7
Page : 8
G. TO SET WEIGHT UNIT
At the bottom of scale, you
can find a unit conversion
button as shown in picture.
If your scale is available (or applicable) in kg/lb/st, you can set to the one you
prefer by pressing the unit conversion button.
Press the unit conversion button when scale is power off, LCD shows current
weight unit. Press the button again to convert weight unit.
After selecting the prefered unit, the scale will be auto after 3 seconds. Selected weight unit will be activated
when the scale is turned on again.
• When setting lb/st as weight unit, the default height unit is feet/inch.
• When setting kg as weight unit, the default height unit is cm.
Remark : The unit system of scale depends on sales destination or the requirement of distributor.
H. OPTIONAL NORMAL WEIGHING MODE
1. Auto step on weighing
Page : 9
H. OPTIONAL NORMAL WEIGHING MODE
2. Consecutive add on weighing
After digits stabilize, more additional loadings can be conducted. Ensure each add on loading has to exceed 2kg
to get a new reading.
Example : If you want to get a weighing value of your baby, you can weigh yourself first, and then hold your baby
together, without stepping off the scale. Then you will get the total weight reading. Subtracting the
previous reading of yourself from the new reading, you will get the difference as your baby’s weighing
value.
Page : 10
