Parts Illustration
#Parts Description DX4800 DX6800
1 Pump 6060050 6091050
2 Motor B300-4V2 B550-4V2
3 Control Box 6001017 6001017
4 Media Pad Set (3 piece set) CP4800 CP6800
5 Float Valve 85023 85023
6 Overflow Tube 14216 14216
7 Prop (fan blade) 9001731 9001730
8 Water Distributor 6000707 6000710
9 Water Diverter 6000708 6000708
10 Silicone Drain Plug 6017081 6017081
11 Panel Cover DP4800 DP6800
12 Winterizing Cover (not shown) CVR4800 CVR6800
EN6
3
1
9
5
2
4
7
10
8
12 - Winterizing Cover
(not shown)
6
11
Side Venturi
Top Cap
Water Tank
Hessaire Warranty
EN7
(Hessaire.com / Warranty / Replacement Parts Request: fill in form, submit)
Lifetime warranty on evaporative cooler cabinet
Two year warranty on motor
One year warranty on pump
Warranty does not apply to media pads
All other components are covered for one year from date of purchase.
If a component is found to be defective within the periods described above, the
defective part will be provided free of charge. Replacement parts are available
through authorized dealers or online. Copy of proof of purchase and serial label
number will be needed for all warranty claims.
Items Not Covered / Conditions:
Hessaire will not be responsible or liable for damage to contents, flooring, car-
pet, walls, ceilings, structure/foundations or any other consequential loss or
damage—either direct or indirect resulting from installation, operation, neglect or
misuse of the evaporative cooler.
Not covered is damage due to outside elements/factors such as rain, wind, light-
ning, storms, floods, power surges, brownouts, etc—which are not considered to
be defects in materials or workmanship and in turn are not covered under the
Hessaire warranty.
Hessaire does not cover labor costs associated with troubleshooting or cooler
repairs—regardless if the product is under warranty or not.
Returns: Please Do Not return your cooler to Hessaire.
Return transportation costs are the responsibility of the purchaser.
Return authorization must be obtained from the seller/distributor where the unit
was purchased from.
All returns should be sent directly to the distributor/store where purchased.
Damaged Shipments:
Hessaire is not responsible for damaged shipments or shortages resulting from
carrier mishandling. Notify your carrier immediately to file a freight claim in the
event of damage. Keep damaged product for inspection until advised by the
carrier as to disposal.
Assistance:
Instructional videos and other helpful parts replacement information is available
on hessaire.com.
Visit hessaire.com for processing warranty claims:
