eCAFE EC-1000W
User Manual – 1/46
CONTENTS
1. eCAFÉ™ – TAKE IT TO GO!™ ...................................................................................................................................2
1.1. Handling your Netbook ........................................................................................................................................2
1.2. A comprehensive package...................................................................................................................................3
1.3. A closer look at your eCAFÉ™ ............................................................................................................................3
2. THE eCAFÉ™, UNEQUALLED AND UNRIVALLED ...................................................................................................4
2.1. My eCAFÉ™........................................................................................................................................................4
2.2. Turning the eCAFÉ™ on......................................................................................................................................5
2.3. Technical specifications.......................................................................................................................................6
2.4. Multifunction keyboard.........................................................................................................................................9
2.5. An ultra-mobile computer suited to large files ....................................................................................................10
2.6. Extensive connectivity options for countless applications ..................................................................................11
2.7. A desktop device AND a mobile device .............................................................................................................13
2.7.1. Operating the eCAFÉ™ when connected to the mains ........................................................................13
2.7.2. Operating the eCAFÉ™ with the built-in battery...................................................................................13
2.7.3. Installing and removing the battery ......................................................................................................14
2.7.4. Optimising your use of the battery........................................................................................................17
2.8. Shutting your eCAFÉ™ down ............................................................................................................................17
2.9. Restoring your system .......................................................................................................................................19
3. FIRST STEPS WITH MY eCAFÉ™ ............................................................................................................................20
3.1. Accessing the applications.................................................................................................................................20
3.2. Connecting an external display..........................................................................................................................22
3.3. Mastering the touchpad .....................................................................................................................................22
3.4. Accessing the online help and tutorials..............................................................................................................23
3.5. Extensive contents to take you further ...............................................................................................................23
3.6. Connecting to the Internet..................................................................................................................................24
3.6.1. eCAFÉ™ Connect and the WiFi feature...............................................................................................24
3.6.2. Connecting to the Internet via an Ethernet cable..................................................................................27
3.6.3. Determining the connection status.......................................................................................................28
3.7. Sending and receiving emails............................................................................................................................29
3.8. Chatting with friends ..........................................................................................................................................29
3.9. Using the webcam .............................................................................................................................................30
3.10. Using the OpenOffice.org suite..........................................................................................................................30
3.10.1. Creating, editing and saving a document using OpenOffice.org Writer (Text Editor)............................32
3.10.2. Creating, editing and saving a spreadsheet using OpenOffice.org Calc (Spreadsheet) .......................34
3.10.3. Creating, editing and saving a slideshow using OpenOffice.org Impress (Presentations) ....................36
3.11. Saving data to a removable media (USB key, memory card).............................................................................41
3.12. Protection software for your eCAFÉ™ ...............................................................................................................42
INDEX ........................................................................................................................................................................43
TECHNICAL SUPPORT ........................................................................................................................................................44
WARRANTY INFORMATION ................................................................................................................................................45
eCAFE EC-1000W
2/46 – User Manual
1. eCAFÉ™ – TAKE IT TO GO!™
Thank you for trusting Hercules and choosing to purchase the eCAFÉ™ Netbook. The eCAFÉ™ has
been designed to allow you to communicate and create or edit documents such as text files, slideshows
or even images; it also includes advanced multimedia features designed to entertain you.
To make the most of your eCAFÉ™ Netbook, please follow the instructions provided in this manual.
1.1. Handling your Netbook
Please read this section with care before using the product.
Like any electronic device, the eCAFÉ™ requires you to observe a number of simple safety rules; these are listed
below. In addition, observing some simple precautions will enable you to extend your eCAFÉ™'s life.
- In no circumstance should you attempt to open the eCAFÉ™, its adaptor or its components; doing this
would expose the device's internal components to damage. Likewise, never attempt to open the
device's batteries.
- Use only the adaptor provided with the product.
- Always place your eCAFÉ™ on a horizontal, stable and flat surface.
- Never exert pressure on the display. Never touch the display with any objects that are liable to damage
it or scratch it.
- Always make sure that you have removed any objects placed on the device's keyboard (e.g. USB key, pen or
others) before closing your eCAFÉ™'s display.
- To avoid any risk of fire or electric shock, always keep your eCAFÉ™ away from:
- Rain or moisture, as well as all fluids (water, chemical products and any other liquids),
- Heat sources such as radiators, cookers or other heat-emitting devices (including
amplifiers),
- Direct sunlight.
- This product should be used only at temperatures ranging from 5 to 35°C.
- Never cover your eCAFÉ™ while the device is powered on.
- Always unplug your eCAFÉ™ before cleaning it. To clean it, use a soft cloth; avoid using chemical
sprays.
- The eCAFÉ™ provides a WiFi wireless connection feature. Use of this feature is liable to cause
interferences with the equipment located on planes or in hospitals. Always deactivate this feature before
entering these premises.
- Disconnect eCAFÉ™ from the mains if there is a storm.
- Never throw the device's battery into an open fire.
- When transporting the eCAFÉ™, always turn the device off if you are carrying it in a closed bag. As a general rule,
make sure that your eCAFÉ™ is placed in a well-vented environment when the device is powered on.
eCAFE EC-1000W
User Manual – 3/46
1.2. A comprehensive package
Compact design, an ultra-lightweight device, powerful connectivity, various accessories included.
Discover the packaging contents:
- eCAFÉ™ Netbook
- Battery
- Power adaptor
- User Manual
1.3. A closer look at your eCAFÉ™
- 1.6 GHz Intel® ATOM™ N270 processor
- 1 GB DDR2 RAM
- 10.1" backlit LCD display (max. native resolution 1024*600)
- 0.3 Megapixel built-in webcam, built-in microphone
- Built-in Intel® 945GSE graphics board, built-in sound board
- Built-in 802.11 b/g/n WiFi board
- 250 GB 2.5" SATA-II hard disk drive
- 4400 mAh / 48.8Wh rechargeable Lithium battery (6 cells)
- 100-240 VAC, 50/60 Hz, 20VDC/2.0 A (power adaptor
- 3 USB 2.0 ports (compatible with USB 1.1 devices)
- 10/100Mbps Ethernet port
- VGA output
- 1 headphones connector, 1 microphone connector
- 82-key keyboard
- Touchpad featuring 2 buttons
- Multiple-format memory card reader: SD (Secure Digital®), SD HC (Secure Digital®HC),
MMC (MultiMedia Card), ), MS (Memory Stick)
- Weight: less than 1.4 Kg (battery included)
- Dimensions: 274.8 x 195 x 30.8 mm
Your eCAFÉ™ EC-1000W features the Microsoft®Windows®7 Starter Edition operating system. It can
be enriched with the installation of applications compatible with this system. In no event shall Guillemot
Corporation S.A.'s liability be bound in the event of damages of any kind (including, but not limited to the
loss of data) resulting from the installation or use or incorrect use of these applications.
eCAFE EC-1000W
4/46 – User Manual
2. THE eCAFÉ™, UNEQUALLED AND UNRIVALLED
The eCAFÉ™ Netbook features a very wide range of applications and extensive connectivity interfaces,
which will enable you to instantly connect to the world that is best suited to your use: work,
communications, games or multimedia.
2.1. My eCAFÉ™
- Remove your eCAFÉ™ from the packaging, and ensure that all items mentioned in Section 1.2 of this
User's Manual are included.
- Remove the protection films from the display.
- Insert your battery (for more
information regarding battery installation
and removal, please refer to Section
2.7.3).
- Connect the power adaptor lead to
your eCAFÉ™, then connect the
adaptor to the mains.
eCAFE EC-1000W
User Manual – 5/46
2.2. Turning the eCAFÉ™ on
- Open the display (1) and press the
On/Off button located on the left-hand
side of the device (2).
Do not exert excessive strength on the hinges when opening the display. Do not hold your
eCAFÉ™ by the display when carrying the device.
When your computer starts up, the Windows Desktop is displayed.
If this is the first time you have used the eCAFÉ™ since purchasing it or since restoring the
system, Windows will ask you to answer a certain number of questions found in different screens
(choosing the computer’s name, accepting the license agreement, etc.). Simply follow the on-screen
instructions to do this.
eCAFE EC-1000W
6/46 – User Manual
2.3. Technical specifications
1. Webcam
2. 10.1" LCD display
3. Loudspeakers
4. UK or US keyboard
5. WiFi activation/deactivation
button
6. Left touchpad button
7. Touchpad
8. Right touchpad button
9. Numeric lock indicator
10. Capitals lock indicator
11. Hard disk drive activity
indicator
12. Battery operation
indicator
13. eCAFÉ™ on/off indicator
14. WiFi activity indicator
eCAFE EC-1000W
User Manual – 7/46
1. Removable battery 3. Air extraction grate
2. Battery locking tabs 4. Component access cover (memory, hard disk, etc.)
Any attempt to open the cover will cancel the warranty.
This part of your eCAFÉ™ is liable to heat during operation and charging. This is normal.
However, to improve thermal dissipation, we recommend you do not block the vents. Avoid
placing your eCAFÉ™ on a soft surface such as a sofa or a bed, for instance.
eCAFE EC-1000W
8/46 – User Manual
1. Not used 3. Microphone connector
2. USB ports 4. Headphones connector
1. Memory card reader 4. Ethernet port 7. Kensington®lock
2. USB port 5. VGA output connector
3. Not used 6. Power supply port
eCAFE EC-1000W
User Manual – 9/46
2.4. Multifunction keyboard
The eCAFÉ™ features an extended keyboard allowing you to control the display's settings.
UK keyboard:
US keyboard:
+
Put the eCAFÉ™ to
standby +
Deactivate/Reactivate
audio output
+
Switch from the LCD
display to an external
display + Lower the volume
+
Reduce display
brightness + Increase the volume
+
Increase display
brightness
eCAFE EC-1000W
10/46 – User Manual
2.5. An ultra-mobile computer suited to large files
Equipped with a hard disk drive and a multiple-format card reader, the eCAFÉ™ enables you to take
your most precious files with you, regardless of their size.
Hard disk drive
The eCAFÉ™ features a 250 GB (or more, according to versions) hard disk drive. This storage capacity
allows you to save movies, images and other large files to your device.
Memory card reader
The eCAFÉ™ is equipped with a multiple-format memory card reader supporting SD (Secure Digital®)
and SD HC (Secure Digital®HC), MMC (MultiMedia Card) MS (Memory Stick) formats; this device
enables you to view pictures taken with your digital camera or to extend your system's storage capacity,
for instance.
USB ports
The eCAFÉ™ is also equipped with three USB ports that enable you to connect a USB storage key or
other USB devices (for further information regarding USB ports, please refer to section 2.6, "Extensive
connectivity options for countless applications").
