Hercules DJControlWave Manuel utilisateur

GettinG started with hercules dJcontrolwave and dJuced™ dJw

1/12

HERCULES DJCONTROLWAVE OVERVIEW

Hercules DJControlWave is a 2-deck DJ controller featuring Bluetooth®

wireless technology. It lets you mix incredibly easily with your iPad,

thanks to the dedicated DJUCED™ DJW app.

This controller is compatible with the following iPad models:

Be sure to completely charge the battery before using the

controller for the first time. For more information, please refer to

section 3. CHARGING THE HERCULES DJCONTROLWAVE.

2/12

SAFETY INSTRUCTIONS

- Place your device on a flat surface, to avoid the risk of the device falling.

- Never open up your device, as you risk damaging its internal components.

- This device is intended for use in a temperate environment.

- To prevent the risk of fire or electrical discharge, keep your device away

from:

- rain or humidity, as well as all fluids (water, chemical products or any

other liquids),

- sources of heat such as heaters, stoves or any other heat-producing

devices (including amplifiers),

- direct sunlight.

- Do not expose the device to drips or splashes of water.

- Never place any object filled with liquid (a glass, vase...) on your device.

- No naked flame sources, such as lighted candles, should be placed on the

device.

- Completely power off your device by setting the battery on/off switch

(located on the underside of the device) to the OFF position, if you will not

be using your device for an extended period of time.

- Power off the device before cleaning. Use a damp cloth and avoid using

aerosol cleaners.

- Markings are located on the underside of the device.

- Replace the device's power supply or accessories respecting the

specifications of the manufacturer or its authorized representative.

- This device contains no internal pieces which can be repaired by the user.

Maintenance must be carried out by the manufacturer or its authorized

representative.

- Only use a power adapter of the type stipulated in this manual, with the

following design features: Input: 100/240 VAC, 50/60 Hz; Output: 5 VDC, 1 A.

WARNING: RISK OF EXPLOSION IF THE BATTERY IS REPLACED BY A

BATTERY OF AN INCORRECT TYPE. FOLLOW THE INSTRUCTIONS

REGARDING THE DISPOSAL OF BATTERIES.

3/12

1. CONNECTING THE HERCULES DJCONTROLWAVE TO

YOUR IPAD

1.1. Enabling the Bluetooth®function on your iPad

On your iPad, open the Settings panel and make sure that the Bluetooth®

function is enabled.

1.2. Pairing the Hercules DJControlWave with your iPad

- Set the battery on/off switch

(located on the underside of the

Hercules DJControlWave) to the ON

position.

- Press the power button to

put the product in pairing mode.

The LED flashes in blue.

If the LED does not flash, press and hold the button for 3

seconds.

On the iPad, the Hercules DJControlWave appears in the list of available

Bluetooth® devices.

4/12

- Select the Hercules DJControlWave. The device’s status is then listed as

Connected and the Hercules DJControlWave’s LED stays lit up in blue.

The Hercules DJControlWave can only operate when connected to

the iPad via the Bluetooth® function.

Once the Hercules DJControlWave is connected, the DJUCED™ DJW app

notifies you that it wants to communicate with the controller.

- Select Allow to launch DJUCED™ DJW (if the app is already installed on

your iPad), or to be directed to the App Store in order to download the app

free of charge.

1.3. Downloading the app from the App Store

The DJUCED™ DJW app, specially developed for the Hercules

DJControlWave, is available on the App Store.

Once the app has been installed on your iPad, you will be able to enjoy all

of your Hercules DJControlWave’s different features.

Tips, hints and tutorials are available to help you get started mixing

step-by-step with Hercules DJControlWave and DJUCED™ DJW:

http://ts.hercules.com

5/12

2. POSITIONING THE IPAD ON THE HERCULES

DJCONTROLWAVE’S SUPPORT

The support features two different angles of inclination, making it easy

to view your iPad’s screen.

iPad support lowered iPad support raised

To ensure perfectly stable positioning, be sure to extend the feet

located on the underside of the Hercules DJControlWave.

2.1. Raising the support

- To raise the support, take hold of it with one finger from behind and your

thumb on the front, and tilt it forward: it should lock into the corresponding

notches.

6/12

2.2. Lowering the support

- To lower the support, press on the back of the support to disengage it

from the notches, and then tilt the support down.

Never force the support or apply too much pressure: by doing so,

you risk damaging the support.

- Position your iPad on the support.

7/12

3. CHARGING THE HERCULES DJCONTROLWAVE

The Hercules DJControlWave provides more than 8 hours of battery

life when fully charged, and can be charged using the included mini

USB/USB cable and power adapter.

3.1. Charging with the included cable and power adapter

It takes 4 hours to completely charge the battery if the device is not

used while it is charging.

3.2. Charging on PC/Mac

On some computers, completely charging the battery may take

longer than charging the battery with the included power adapter.

8/12

3.3. Battery charge level

The battery’s charge level is displayed in the DJUCED™ DJW app.

On the Hercules DJControlWave, a battery level indicator flashes in red

when the battery’s level is less than 10%.

The level indicator stays lit up in red while the battery is charging, and

goes off when the battery is fully charged.

9/12

4. CONNECTING SPEAKERS TO THE HERCULES

DJCONTROLWAVE

You can play the sound of your mix on speakers physically connected

to your iPad, or on wireless speakers connected via the Bluetooth®

function.

4.1. Playing the mix on speakers connected to your iPad (wired

connection)

Connect the speakers directly to your iPad’s headphone output (3.5 mm

mini-jack connector).

4.2. Playing the mix on a Bluetooth® wireless speaker (wireless

connection)

To play the mix on a Bluetooth® wireless speaker, the iPad must be

paired with both the Bluetooth® speaker and the Hercules

DJControlWave at the same time.

- After having connected the Hercules DJControlWave to your iPad (please

refer to section 1. CONNECTING THE HERCULES DJCONTROLWAVE TO YOUR

IPAD), pair the iPad with the Bluetooth® wireless speaker (for more

information, please refer to your wireless speaker’s user manual).

On the iPad, the wireless speaker appears in the list of available Bluetooth®

devices.
