Helmer Scientific I.Series Manuel utilisateur

360414/A

Refrigerator Instructions for Use

and Operation Manual

i.Series®· Horizon Series™

Upright - Undercounter

Laboratory

i.Series

iLR105-GX, iLR113-GX, iLR120-GX,

iLR125-GX, iLR245-GX, iLR256-GX

Horizon Series

HLR105-GX, HLR113-GX, HLR120-GX,

HLR125-GX, HLR245-GX, HLR256-GX

Blood Bank

i.Series

iBR105-GX, iBR113-GX, iBR120-GX,

iBR125-GX, iBR245-GX, iBR256-GX

Horizon Series

HBR105-GX, HBR113-GX, HBR120-GX,

HBR125-GX, HBR245-GX, HBR256-GX

Pharmacy

i.Series

iPR105-GX, iPR113-GX, iPR120-GX,

iPR125-GX, iPR245-GX, iPR256-GX

Horizon Series

HPR105-GX, HPR113-GX, HPR120-GX,

HPR125-GX, HPR245-GX, HPR256-GX

Document History

Revision Date CO Supersession Revision Description

A 18 SEP 2019* 14979 n/a Initial release.

* Date submitted for Change Order review. Actual release date may vary.

Document Updates

The document is furnished for information use only, is subject to change without notice and should not be construed as a

commitment by Helmer Scientic. Helmer Scientic assumes no responsibility or liability for any errors or inaccuracies that may

appear in the informational content contained in this material. For the purpose of clarity, Helmer Scientic considers only the most

recent revision of this document to be valid.

Notices and Disclaimers

Condential / Proprietary Notices

Use of any portion(s) of this document to copy, translate, disassemble or decompile, or create or attempt to create by reverse

engineering or otherwise replicate the information from Helmer Scientic products is expressly prohibited.

Helmer, Inc. in the United States of America. All other trademarks and registered trademarks are the property of their respective

owners. Helmer, Inc., doing business as (DBA) Helmer Scientic and Helmer.

Disclaimer

This manual is intended as a guide to provide the operator with necessary instructions on the proper use and maintenance of

certain Helmer Scientic products.

Any failure to follow the instructions as described could result in impaired product function, injury to the operator or others, or void

applicable product warranties. Helmer Scientic accepts no responsibility or liability resulting from improper use or maintenance of

its products.

The screenshots and component images appearing in this guide are provided for illustrative purposes only, and may vary slightly

from the actual software screens and/or product components.

Helmer Scientic

14400 Bergen Boulevard

Noblesville, IN 46060 USA

www.helmerinc.com Part No. 360414/Rev A

Contents

1 About this Manual................................................................................................ 1

1.1 Intended Audience ..........................................................................................1

1.2 Model Reference............................................................................................1

1.3 Intended Use...............................................................................................1

1.4 Safety Precautions and Symbols ...............................................................................1

1.5 Avoiding Injury..............................................................................................3

1.6 General Recommendations ...................................................................................3

2. Installation ...................................................................................................... 4

2.1 Location...................................................................................................4

2.2 Placement and Leveling ......................................................................................4

2.3 Stacked Undercounter Units................................................................................... 4

2.4 AC Power Cord ............................................................................................5

2.5 Temperature Probes .........................................................................................5

2.6 Chart Recorder (if included) .................................................................................. 6

3 i.Series®Operation ............................................................................................... 8

3.1 Initial Power-Up.............................................................................................8

3.2 Operation .................................................................................................9

3.3 Change Temperature Setpoint ................................................................................. 9

3.4 Set Alarm Parameters.......................................................................................10

3.5 Active Alarms ..............................................................................................11

3.6 Mute Active Alarms ..........................................................................................11

3.7 Light Operation (if installed) ................................................................................. 12

4 Min/Max Temperature Monitoring .................................................................................. 13

5 i.Series®Access Control (Optional)................................................................................. 14

5.1 Setup....................................................................................................14

5.2 Open Refrigerator with Access Control.......................................................................... 14

6 Horizon Series™Operation........................................................................................ 15

6.1 Initial Power-Up............................................................................................15

6.2 Display Minimum and Maximum Monitor Temperature Recordings .................................................... 15

6.3 Change Temperature Setpoint ................................................................................ 16

6.4 Set Parameter Values....................................................................................... 17

6.5 Set Temperature Units....................................................................................... 17

6.6 Set Alarm Setpoints (Parameters).............................................................................. 17

6.7 TemperatureCalibrationO󰀨sets ............................................................................... 18

6.8 Active Alarms .............................................................................................18

6.9 Mute and Disable Audible Alarms .............................................................................. 18

6.10 Light Operation ............................................................................................ 18

7 Horizon Series™Access Control (Optional) .......................................................................... 19

7.1 Setup....................................................................................................19

8 ProductSpecications ........................................................................................... 20

8.1 Operating Standards........................................................................................20

9 Compliance .................................................................................................... 23

9.1 Safety Compliance ......................................................................................... 23

9.2 Environmental Compliance................................................................................... 23

9.3 EMC Compliance ..........................................................................................23

Helmer Scientic i.Series®-Horizon Series™Refrigerator Instructions for Use

360414/A ii

1 About this Manual

1.1 Intended Audience

This manual provides information on how to use i.Series®and Horizon Series™ upright laboratory and undercounter, blood bank,

and pharmacy refrigerators. It is intended for use by end users of the refrigerator and authorized service technicians.

1.2 Model Reference

Models are indicated by a distinguishing model number that corresponds to the series, type, number of doors, and capacity of the

refrigerator. For example, “iLR113-GX” refers to an i.Series Laboratory Refrigerator with 1 door and a capacity of 13 cu ft.

1.3 Intended Use

Note

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment

is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required

to correct the interference at his own expense.

Helmerrefrigeratorsareintendedforthestorageofbloodproductsandothermedicalandscienticproducts.

1.4 Safety Precautions and Symbols

Symbols found in this document

The following symbols are used in this manual to emphasize certain details for the user:

Task Indicates procedures which need to be followed.

Note Provides useful information regarding a procedure or operating technique when using Helmer

Scienticproducts.

NOTICE Advises the user against initiating an action or creating a situation which could result in damage to

equipment; personal injury is unlikely.

Helmer Scientic i.Series®-Horizon Series™Refrigerator Instructions for Use

360414/A 1

Symbols found on the units

The following symbols may be found on the refrigerator or refrigerator packaging:

Caution: Risk of damage to equipment or

danger to operator Warning:Crushingofhands/ngers

Caution: Hot surface Danger: Risk of Fire or Explosion. Flammable

refrigerant used

Caution: Shock / electrical hazard Refer to documentation

These symbols also appear with appropriate information provided within this document.

Helmer Scientic i.Series®-Horizon Series™Refrigerator Instructions for Use

360414/A 2

1.5 Avoiding Injury

• Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by

the manufacturer.

• Do not damage the refrigerant circuit.

Review safety instructions before installing, using, or maintaining the equipment.

♦Before moving unit, ensure door is closed and casters are unlocked and free of debris.

♦Before moving unit, disconnect the AC power cord and secure the cord.

♦Never physically restrict any moving component.

♦Avoid removing electrical service panels and access panels unless so instructed.

♦Keep hands away from pinch points when closing the door.

♦Avoid sharp edges when working inside the electrical compartment and refrigeration compartment.

♦Ensure products are stored at recommended temperatures determined by standards, literature, or good

laboratory practices.

♦Proceed with caution when adding and removing product from the refrigerator.

♦Do not open multiple, loaded drawers at the same time.

♦Use manufacturer supplied power cord only.

♦Avoid risk of ignition by using only manufacturer supplied components and authorized personnel when servicing the unit.

♦ Usingtheequipmentinamannernotspeciedbythemanufacturermayimpairtheprotectionprovidedbytheequipment.

♦Ensure product is stored safely, in accordance with all applicable organizational, regulatory and legal requirements.

♦ Therefrigeratorisnotconsideredtobeastoragecabinetforammableorhazardousmaterials.

♦ Usecautionwhenmovingundercounterunitsinastackedconguration.

♦REQUIRED: Decontaminate parts prior to sending for service or repair. Contact Helmer or your distributor for

decontamination instructions and a Return Authorization Number.

1.6 General Recommendations

General Use

Allow refrigerator to come to room temperature before switching power on.

During initial startup, high temperature alarm may sound while refrigerator reaches operating temperature.

Do not remove the cover from the condensate evaporator tray on upright units.

Initial Loading

Allow chamber temperature to stabilize at the setpoint before storing product.

Product Loading Guidelines

When loading your refrigerator, take care to observe the following guidelines:

♦Never load refrigerators beyond capacity.

♦Always store items within shelves, drawers or baskets.

♦ Temperatureuniformityismaintainedbyaircirculation,whichcouldbeimpededifunitisoverlled,particularlyatthetopor

against the doors or walls. Ensure a 2” (50 mm) clearance is provided below the fan.

Note

Productsstackedagainstwallsordoorsmayobstructairowanda󰀨ectperformanceofunit.

Helmer Scientic i.Series®-Horizon Series™Refrigerator Instructions for Use

360414/A 3

2. Installation

2.1 Location

Keep all ventilation openings in the enclosure or, in the structure of building-in, clear of obstruction.

♦ Hasagroundedoutletmeetingtheelectricalrequirementslistedontheproductspecicationlabel.

♦Is clear of direct sunlight, high temperature sources, and heating and air conditioning vents.

♦Upright units require minimum 8” (203 mm) above, and minimum 3” (76 mm) behind.

♦Undercounter units require minimum 3” behind the unit for clearance and feature access.

♦ Meetslimitsspeciedforambienttemperature(15˚Cto32˚C)andrelativehumidity.

2.2 Placement and Leveling

The evaporation tray located on the back of the upright refrigerator may be hot. Do not use the tray as a handle.

NOTICE

• To prevent tipping, ensure the casters (if installed) are unlocked and doors are closed before moving the unit.

• To avoid damaging refrigerant tubing or risking refrigerant leak, use caution when moving or operating the unit.

Undercounter units only

• Do not sit, lean, push or place heavy objects on top surface of undercounter units.

• Do not lean on or push down on an open door or extended drawers.

1. Ensure door is secured and casters (if installed) are unlocked.

2. Roll refrigerator into place and lock casters.

3. Ensure refrigerator is level.

Note

Helmerrecommendstheuseoflevelingfeetandwallandoorbrackets(PN400472-2)forstabilizationonundercounter

units. Contact Helmer Technical Service for parts and instruction.

2.3 Stacked Undercounter Units

NOTICE

• Forstackedconguration,bothunitsmusthavelevelingfeetinstalled.

• Back brace bars and front stabilizing brackets must be installed (Blue - PN 400821-1; Stainless Steel - PN 400821-2).

• When stacking units, place the heavier unit on the bottom.

• Do not open multiple loaded drawers at the same time.

• Do not lean on or push down on an open door or extended drawers.

Contact Helmer or your distributor for more information regarding the stacking kit and methods to secure both units to the wall

and/oroor.

Helmer Scientic i.Series®-Horizon Series™Refrigerator Instructions for Use

360414/A 4

2.4 AC Power Cord

Use manufacturer supplied power cord only.

Install power cord

If packaged with modular cord, insert plug securely into the refrigerator power receptacle prior to connecting to

grounded outlet.

2.5 Temperature Probes

A solid ballast or probe bottle and container of glycerin have been provided with this unit. The glycerin is used to create a solution

which, when placed in the probe bottle, simulates the product stored in the refrigerator. The product simulation solution temperature

reectstheproduct’stemperatureduringnormaloperation.

Notes

• Temperature probes are fragile; handle with care.

• Number and location of probes varies by model.

• Remote probes may also be introduced through the existing port on top or rear of the unit (if included).

• Solid ballast (if installed) should be placed in the bracket in a horizontal position.

•Failuretollprobebottlesorkeepprobebottles(ifinstalled)lledtotheappropriatelevelmaycausethechamber

temperature to display higher or lower than the actual temperature.

Primary Monitor Probe

The primary monitor probe is located at the top left side of the refrigerator.

Primary monitor probe

Secondary Monitor Probe (i.Series models 20 cu ft and larger only)

The secondary monitor probe is located in the lower left side of the refrigerator.

Secondary monitor probe

Helmer Scientic i.Series®-Horizon Series™Refrigerator Instructions for Use

360414/A 5

Fill Temperature Probe Bottle (if installed)

Note

Use approximately 4 oz. (120 mL) of product simulation solution (10:1 ratio of water to glycerin).

Glycerin packet included in refrigerator box.

1. Remove probe(s) from bottle and remove bottle from bracket.

2. Removecapandllwithapproximately4oz.(120mL)ofproductsimulationsolution.

3. Secure cap on bottle and place in bracket.

4. Replace probe(s), immersing at least 2” (50 mm) in solution.

Install Additional Probe Through Top or Rear Port

1. Peel back putty to expose port.

2. Insert probe through port into chamber.

3. Insert probe into bottle.

4. Replace putty, ensuring a tight seal.

2.6 Chart Recorder (if included)

The chart recorder has a back-up battery system enabling a period of continuous operation if power is lost. Battery life varies by

manufacturer as well as voltage level remaining. If full battery power is available, back-up power for the temperature chart recorder

is available for up to 14 hours.

Note

If chart recorder is operated on battery power, the battery should be replaced to ensure the back-up source has

proper charge.

Prior to use:

Place chart recorder probe in bottle or ballast with primary monitor probe.

Set up and Operation

Access the chart recorder by pressing and releasing the door (i.Series except 113 models) or pulling the door open (Horizon

Series, 113 models and undercounter models).

Install battery.

Connect the leads to the battery to provide back-up power to the chart recorder.

Helmer Scientic i.Series®-Horizon Series™Refrigerator Instructions for Use

360414/A 6

Install / Replace Chart Paper

Note

For accurate temperature reading, ensure the current time is aligned with the time line groove when the chart knob

is fully tightened.

Chart recorder stylus and time line groove

1. PressandholdCbutton.Whenstylusbeginstomoveleft,releasebutton.TheLEDashes.

2. When stylus stops moving, remove chart knob then move knob up and away.

3. Place chart paper on chart recorder.

4. Gently lift stylus and rotate paper so current time line corresponds to time line groove.

5. Hold chart paper in place while making sure the chart knob is fully tightened. (Failure to fully tighten the knob can result in paper

slipping and losing time.)

6. Press and hold C button. When stylus begins to move right, release button.

7. Conrmstylusismarkingonpaperandstopsatthecorrecttemperature.

8. Calibrate chart recorder to match primary temperature if needed and close recorder door.

Power Supply

The temperature chart recorder uses AC power when the system is operating. If AC power fails, the recorder continues to record

temperature with back-up power provided by the nine-volt battery.

♦The LED indicator glows green continually when main power is functioning and the battery is charged.

♦The LED indicator glows red continually when main power is functioning and the battery is either not installed or needs to

be changed.

♦ TheLEDindicatorashesredtoindicatethattherecorderisreceivingpoweronlyfromtheback-upbattery.

♦ TheLEDindicatorashesduringchartpaperchangemode.

Helmer Scientic i.Series®-Horizon Series™Refrigerator Instructions for Use

360414/A 7

Autres manuels pour i.Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Helmer Scientific Réfrigérateur

Helmer Scientific

Helmer Scientific i.Series Manuel utilisateur

Helmer Scientific

Helmer Scientific Horizon Series Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
