Heinner HC-265M Manuel utilisateur

COMBI FRIDGE

Model: HC-265M

www.heinner.com

Combi fridge

Net capacity: 265L

Energy class: A+

www.heinner.com

Thank you for chosing this product!

Please read this instruction manual carefully before using it and kee it for later information

This manual is conceived for ofering you all of the necessary info regarding instalation, using

and maintenance of the machine. For a correctly and safely use of the machine, please, read

this manual before instalation and using.

I. INTRODUCTION

II. PACKAGE CONTENTS

Combi fridge

Instruction Manual

Warranty card

www.heinner.com

III. SAFETY WARNINGS

The appliance is not intended for use by young children or infirm persons without

supervision.

Young children should be supervised to ensure that they do not play with the appliance.

1) WARNING –Keep ventilation openings, in the appliance enclosure or in the built-in

structure, clear of obstruction.

2) WARNING –Do not damage the refrigerant circuit.

3) WARNING –Do not use electrical appliances inside the food storage compartments

of the appliance, unless they are of the type recommended by the manufacturer.

4) The appliance has to be unplugged after use and before carrying out user

maintenance on the appliance.

5) This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless they

have been given supervision or instruction concerning use of the appliance by a person

responsible for their safety.

6) Children should be supervised to ensure that they do not play with the appliance.

7) If the supply cord is damaged, it must be replaced by the manufacturer, its service

agent or similarly qualified persons in order to avoid a hazard.

8) Please abandon the refrigerator-freezer according to local regulators for it use

flammable blowing gas and refrigerant.

9）Please according to local regulations regarding disposal of the appliance for its

flammable refrigerant and blowing gas. Before you scrap the appliance, please take off

the doors to prevent children trapped.

www.heinner.com

IV. UNPACKING

WARNING: Use two or more people to move refrigerator-freezer.Failure to do so can result in

back or other injury.

Remove tape and any labels from your refrigerator-freezer before using(except the rating

label).

To remove any remaining tape or glue, rub the area briskly with your thumb.

Tape or glue residue can also be easily removed by rubbing a small amount of liquid dish soap

over the adhesive with your fingers. Wipe with warm water and dry.

Do not use sharp instruments, rubbing alcohol, flammable fluids, or abrasive cleaners to

remove tape or glue. These products can damage the surface of your refrigerator-freezer.

When moving the refrigerator-freezer, do not tilt the refrigerator-freezer beyond 45°from

upright position.

V. INSTALLING

1. Remove the hinge guard

2. Remove three screws with suitable tools

www.heinner.com

3. Remove middle hinge, screws, screw caps and plastic inserting nails. Install them on

the other side. Take off the lower door and put it away.

4. The disassembly and installation of bottom parts

A. Disassemble lower hinge and screws. Then install them on the other side and

consolidate the lower hinge.

Note：the refrigerator-freezer incline angle less 45°.

B、Swap over the position of the adjustable foot to the other side of the cabinet.

www.heinner.com

C. Swap over the position of the lower door block to the other side,

And install the screws and consolidate them.

5. Install the lower door.

6. Tighten the screws of the middle hinge on the reversible side.

7、Install the top door and remove the existing top door block. Install a new top door

block (not the same one) on the reversible side. Screw it down.

8. Move the hinge to another side of the box after removing the screws on the hinge;

Use screws to fasten.

9. Install the hinge cover after fastening the hinge.

www.heinner.com

CLEANING BEFORE USE：

After you remove all of the packaging materials, （especially the foam between outside

condenser and cabinet should be removed）clean the inside of your refrigerator-freezer

before using it.

SPACE REQUIREMENTS

WARNING: Keep flammable materials and vapors, such as gasoline, away form

refrigerator-freezer.Failure to do so can result in death, explosion, fine or burns.

To ensure proper ventilation for your refrigerator-freezer, allow for 200mm space on

each side between walls, 200mm space between back of your refrigerator-freezer and

the wall, and 300mm space between counter top and the roof or ceiling.

If you are installing your refrigerator-freezer next to a fixed wall, leave sufficient space

on the hinge side to allow for the door to swing open.

Never install your refrigerator-freezer near heat source and direct sun shins.

ELECTRICAL REQUIREMENT

WARNING: DO NOT REMOVE GROUND PRONG.

DO NOT USE AN ADAPTOR.

DO NOT USE EXTENSION CORD.

Failure to follow these instructions can result in death, fire or electrical shock.

Before you move your refrigerator-freezer into its final location, it is important to make

sure you have the proper electrical connection.

NOTE: Before performing any type of installation, disconnect the refrigerator-freezer

from the electrical source. When you are finished, connect the refrigerator-freezer to

the electrical source and reset the control to the desired setting.

LEVELING

If the refrigerator-freezer is not leveled during installation. The doors may not close or

seal properly, causing cooling, frost, or moisture problems. It is very important of the

refrigerator-freezer to be level in order to function properly.

To level your refrigerator-freezer you may either turn the adjustable foot clockwise to

raise that side to the refrigerator-freezer or turn counter –clockwise to lower that side.

NOTE: Having someone push against the top of the refrigerator-freezer, take some

weight off. This makes it easier to adjust the adjustable foot.

V. BEFORE USING

www.heinner.com

To obtain the best possible results form your refrigerator-freezer, it is important that you

operate it properly.

TEMPERATURE CONTROL

The temperature selector knob is located on the right hand side wall of the refrigerator

interior.

Setting“Off”： UnitOff

Setting“Min”： Less Cool Temperature

Setting“Med”： Normal Operation (adequate for most situations)

Setting“Max”： Coolest Temperature

During high ambient temperatures e.g. on hot summer days. It may be necessary to set

the thermostat to the Coolest setting (position “Max”). This may cause the compressor

running continuously in order to maintain a low temperature in the cabinet.

For the first time you install your refrigerator, set the thermostat knob at “Med”.

Give your refrigerator time to cool down completely before adding food. It is the best to

wait 24 hours before adding food. The thermostat knob controls the temperature. When

the thermostat control knob is set to OFF, the refrigerator will not be running.

CHANGING THE BULBS

Unplug refrigerator-freezer or disconnect refrigerator-freezer from power supply before

you remove the bulb.

· Replace the bulb with 15-watt appliance bulb. Not all bulbs will fit your

refrigerator-freezer. Be sure to replace the bulb with one of the same size and shape.

·Plug in refrigerator-freezer or reconnect refrigerator-freezer to power supply.

POWER INTERRUPTIONS

If the electricity in your house goes off for a shorter period, keep both doors closed to

help foods stay cold and frozen.

If the power will be out for a longer period, remove foods from the freezer and stored it

in a frozen food locker.

FRESH FOOD STORAGE

Wrap or store food in the refrigerator in airtight and moisture –proof material.

This prevents food odor and taste transfer throughout refrigerator.

·Fruit –wash, let dry and store in refrigerator in plastic bags or crisper.

·Leafy vegetables- Remove wrapping and trim or tear off bruised and discolored areas,

wash in cold water and drain. Place in plastic bag or plastic container and store in crisper.

·Fish –Use fresh fish the same day as purchased.

VII. USING INSTRUCTION

www.heinner.com

·Meat –Store most meat in original wrapping as long as it is airtight and moisture –

proof.

Re –wrap if necessary.

·Leftovers –Cover leftovers with plastic wrap or aluminum foil.Plastic containers with

tight lied can also be used.

FROZEN FOOD STORAGE

When using the refrigerator-freezer for the first time, turn the temperature control to set

“ med” for at least two hours before introducing the food to be stored.

All frozen food products you purchase should be placed in the freezer compartment as

soon as possible to avoid the frozen food from defrosting.

Storage recommendation printed on the packaging of frozen food by the manufacturers

should be always be followed.

Be careful that the drawer mustn’t mangle the refrigeration pipeline.

FREEZING FRESH FOOD

Ensure that your freezing operations are carried out under the most hygienic conditions

as freezing alone does not sterilize the food. It is advisable to freeze the food by packing

it into separate meal portions and not in bulk form. Never put hot or even warm

foodstuffs into the freezer compartment. Prior to storing the frozen food, pack it in plastic

bags, aluminum sheets or freezing containers and place into the freezer compartment.

See the data plate on the back of the refrigerator-freezer for the maximum permissible

amount in kilograms of fresh food that can be frozen in any 24 hour period with a room

temperature of 25℃. Never freeze more than the maximum permissible.

Note: Never put bottled food or drinks in the freezer compartment.For best performance,

leave enough space in the Freezer compartment for air to circulate around the packages.

PROLONGED OFF PERIODS

If the refrigerator-freezer is not in use for a long period of time, proceed as follows:

Disconnect the refrigerator-freezer from the main supply by removing the plug from the

wall socket.

Clean and dry the inside as instructed under the heading of cleaning the

refrigerator-freezer.

Leave the door open to prevent any unpleasant smells from building up while the

refrigerator-freezer is not in use.

www.heinner.com

The refrigerator-freezer should be clean at least once a month to prevent odors form building

up. Wipe up spills immediately.

To clean your refrigerator-freezer:

·Unplug it.

·Remove all movable parts from inside, such as shelves and crisper. Etc.

·Use a clean sponge or soft and a mild detergent in warm water. Do not use abrasive or harsh

cleaners.

·Hand wash, rinse and dry all surfaces thoroughly.

·Do not use cleaning waxes, concentrated detergents, bleaches or cleaners containing

petroleum on plastics and rubber parts.

·Never use paper towels, window sprays, scouring cleansers or flammable fluids on plastic

parts as these can scratch or damage material.

VIII. CLEANING AND MAINTENANCE

In case of malfunction, you can solve many common problems easily.

Your refrigerator will not operate…Check if:

-- The power supply cord is unplugged.

The doors will not close completely…Check if:

-- The drawers are out of position.

-- The gaskets are dirty.

-- The refrigerator-freezer is not level.

The refrigerator-freezer is noisy when running…Check if:

-- Check the refrigerator-freezer is level and it is not in contact with another appliance

or kitchen furniture.

The refrigerator-freezer does not cool sufficiently…Check if:

-- If the door has been opened too often, or it has been left open for a while it will

take time for the refrigerator-freezer to reach its set temperature.

-- Check the airflow the rear of the refrigerator-freezer has not been reduced due to

insufficient clearance.

The following characteristics should not be looked upon as a problem.

-- A gentle tricking sound caused by coolant flowing the pipe.

Compressor operating at high temperature.

REQUESTING ASSISTANCE OR SERVICE

If the problem is not due to one of the items listed in Troubleshooting, Contact the dealer

or authorized Service Company.

IX. TROUBLESHOOTING

Table des matières

Langues :

Autres manuels Heinner Congélateur

Heinner

Heinner HC-V268F+ Manuel utilisateur

Heinner

Heinner HCF-251NHA+ Manuel utilisateur

Heinner

Heinner HCF-316HA+ Manuel utilisateur

Heinner

Heinner HCF-251NHF+ Manuel utilisateur

Heinner

Heinner HFF-91HBKF+ Manuel utilisateur

Heinner

Heinner HFF-V102F+ Manuel utilisateur

Heinner

Heinner HFF-V102A+ Manuel utilisateur

Heinner

Heinner HCF-251HA+ Manuel utilisateur

Heinner

Heinner HFF-242NHF+ Manuel utilisateur

Heinner

Heinner HCF-205NHA+ Manuel utilisateur

Heinner

Heinner HFF-212EA+ Instructions d'installation

Heinner

Heinner HFF-N165SF+ Manuel utilisateur

Heinner

Heinner HFF-V182A+ Manuel utilisateur

Heinner

Heinner HFF-180NHF+ Manuel utilisateur

Heinner

Heinner HCF-H306F+ Manuel utilisateur

Heinner

Heinner HFF-91HF+ Manuel utilisateur

Heinner

Heinner HFF-V280NFXF+ Manuel utilisateur

Heinner

Heinner HFF-274NFF+ Manuel utilisateur

Heinner

Heinner HCF-M362CA+ Manuel utilisateur

Heinner

Heinner HFF-160NHA+ Manuel utilisateur

Heinner

Heinner HCF-205NHF+ Manuel utilisateur

Heinner

Heinner HFF-N240NFF+ Manuel utilisateur

Heinner

Heinner HFF-N85E++ Manuel utilisateur

Heinner

Heinner HFF-V280NFX+ Manuel utilisateur

Manuels Congélateur populaires d'autres marques

Siemens

Siemens GU..D SERIES Manuel utilisateur

Omcan

Omcan FR-CN-0155 Manuel utilisateur

Beko

Beko FNE290E24W Manuel utilisateur

Electrolux

Electrolux ARCTIS G 8 60 50-6I Manuel utilisateur

Electrolux

Electrolux EUF2042AOX Manuel utilisateur

Dometic

Dometic CoolFreeze CFX95DZ Manuel utilisateur

Electrolux

Electrolux EUF7000W1 Manuel utilisateur

Polar Electro

Polar Electro CT330 Manuel utilisateur

MPM

MPM MPM-145-SK Series Manuel utilisateur

SAF

SAF PRESTOTIG 200AC/DC Guide rapide

Zanussi

Zanussi ZFT11407WA Manuel utilisateur

AEG

AEG A63190GT Manuel utilisateur

AEG

AEG A81000TNW0 Manuel utilisateur

Matsui

Matsui MUC50S15E Manuel utilisateur

NEFF

NEFF G4344X8 Manuel utilisateur

Frigidaire

Frigidaire FV 1246 H Manuel utilisateur

Frigidaire

Frigidaire FFC13K1AW Manuel utilisateur

Electrolux

Electrolux EU 2400C Manuel utilisateur
