heimgard Indoor 360 Manuel utilisateur
Indoor 360°
camera 2
Quick start guide
version 1.0
Requires a
Heimgard
smart home
Hub
What is in the box
A. Camera
C. EU USB
power adapter
D. Screws &
wall anchors
B. Micro USB
power cable
E. Mounting bracket F. Positioning map
For wall mounting, you will also need electric drill, as well
as a twist drill bit when using wall anchors.
Device overview
To locate the reset button (I), gently slide the camera lens
(H) up to the top of the camera. The button is located at the
bottom left of the lens housing.
G.
H.
I.
J.
K.
LED-indicator
Camera lens
Join / reset button
Ethernet port
Power input
G.
H. I.
K.
J.
LED indicator status
OFF
Powered o.
Rebooting after reset.
RED LIGHT FLASHING
Network connection failed.
SOLID RED LIGHT
Booting.
Device malfunction.
RED AND GREEN LIGHT FLASHING
Firmware upgrading.
GREEN LIGHT FLASHING
Waiting for network.
SOLID GREEN LIGHT
Operating properly.
1.
3.
2.
Connect the power cable (B) to the power
input (K). Insert the power cable into the USB
power adapter (C). Connect the USB power
adapter to a wall socket.
Manage
Devices
Camera conguration
LED indicator status
Open the Heimgard app and follow these
steps to connect your camera.
Select Indoor 360° camera 2 from the list.
The camera is now
booting. Wait until the
LED-indicator (G) ashes
green before continuing.
4. From the drop-down menu, select the name of
your Wi-Fi network (SSID).
NOTE! Select 2.4 GHz (not 5 GHz) if you have
both options. You can also enter the network
name (SSID) manually.
Remember to distinguish between uppercase
and lowercase letters.
5. On the line below, enter your Wi-Fi password,
then tap Next.
6. Before pressing Next, make sure the LED (G)
on the camera is ashing green.
7. A QR code will now appear on the screen. Turn
the phone screen toward the camera lens (H)
to connect the camera to the Wi-Fi network.
Turn the brightness of the screen on your phone to
maximum for optimal readability of the QR code in front of
the camera.
Hold the phone in front of the
camera lens (H) and slowly move
it away until the QR code is
accepted (LED indicator (G) goes
from ashing calm green to fast
ashes indicating that the camera is
connecting to your Wi-Fi network).
8. When the camera is connected to the network,
the LED indicator (G) on the camera will light
solid green, and you will automatically be taken
to the Congure Devices screen. This might
take up to several minutes.
9. You can now give the camera a name, such
as “Camera hallway” and connect it to a room.
Create a new room if the desired room or area
does not already exist in the overview.
If you have multiple cameras to set up, repeat step 2, 3, and
6 to 9 to add them individually.
If you change the Wi-Fi network or the LED (G) indicates a
fault, reset the camera (see page 12).
The camera starts recording when it detects motion
(records up to ve minutes). If motion is still detected after
ve minutes, the recording continues in a new clip.
Conguration and use
Advanced settings:
The camera can be used for two purposes:
Recording and Generic.
Generic:
The camera does not record when it detects motion.
In the app you can stream and start recording manually.
Recording:
On motion: The camera will record when motion is detected.
On motion when away: The camera will record only when
“Away mode” for the alarm is activated and motion is
detected.
Where to place your camera
Place the camera as high as possible, in a place where it
has a good overview of the area it is to capture and near a
power outlet.
Floor
Wall
Freestanding on
a table / shelf
Wall mounting
Mounting examples
