INPUTS:
- LINE 1 – 5: Standard line inputs
OUTPUTS:
- PRE OUT: Volume controlled output
- TAPE OUT: Fixed line level output
REMOTE CONTROL:
Volume up (+) and down (-), input up ( ) and down ( ), and
mute functions are available. When muted, the
volume knob LED is blinking.
RCA OUTPUT ON
THESIS OUTPUTS:
There are two independent outputs that can be used to power two
devices at the same time.
THESIS PSU CONNECTOR:
To use the internal PSU of the , the supplied shorting plug must be
connected to the PSU IN connector. To use the Thesis ,
remove the shorting plug and connect the PSU cable
supplied with the .
:
The two RCA connectors on the are wired together. This makes bi-
amping or other forward connecting easier.
π
λ
λ
π
π
ω
ω
PLACEMENT:
Any rigid surface can be sufficient for placing your Thesis amplifiers.
Please consider the weight of the devices. It is best to
place them on a sturdy piece of furniture with stable
footing and the least possible movement.
VENTILATION:
Always allow adequate ventilation and airflow around the units. Do
not place it directly on carpet, soft fabric, etc. that can
block the ventilation holes.
HEAT DISSIPATION:
The power amplifiers have Class AB amplifier stages inside, which
generate some amount of heat at idle. This is normal.
CONNECTIONS:
It is best to do any cable connection when the amplifiers are
switched off. Take extra care when connecting
loudspeakers! Do not touch any of the poles to ground
or to each other!
Switch on order: preamplifier -> power amplifier
Switch off order: power amplifier -> preamplifier
L in
R in
Hand Made in the EU
