Heatzilla SY-CLP55 Manuel utilisateur
CERAMIC HEATER
SY·CLP55
USER
MANUAL
2
Welcome
Thank you for purchasing the new heater SY-CLP55. In order to fully benefit from
this product, please read these instructions carefully. Store the user manual in a
safe place for future reference.
Important Safeguards
Electric shock Not to be used by children Use dry hands
• When using electrical appliances, in order to reduce the risk of fire, electric shock,
and/or injury, these basic safety precautions should always be followed:
• Before inserting the mains plug into the socket, check that the mains supply
voltage and current rating correspond with the power supply details shown on the
model label of the appliance.
• Read all instructions carefully, even if you feel you are quite familiar with this type
of appliance.
• Unplug the outlet when not in use and before cleaning. Allow the device to cool
down before putting on or taking off parts.
• Do not use the heater near furniture, curtains, shelves, etc..
• Do not use the heater near close to any liquids or inflammable products.
• Do not place the heater below a socket outlet.
• Do not cover the heater while it is on to avoid overheating risks.
• Do not operate the appliance with a damaged cord or plug or after the appliance
malfunctions, or has been damaged in any manner.
• The use of accessories or any other attachments not recommended by the
appliance manufacturer may cause injuries and invalidate the running warranty.
• Do not use this appliance outdoor or near direct heat sources.
• Do not let the cord hang over the edge of the table or counter or be in contact with
hot surfaces or to be situated underneath or close to curtains, window coverings,
etc.
• This appliance should only be used for domestic purpose.
• This appliance should be placed on a flat and stable surface.
• Do not expose the appliance to water or moisture.
• To prevent damage to the power cord, always keep it away from sharp edges or
corners.
• Children of less than 3 years should be kept away unless continuously supervised.
Children aged from 3 years and less than 8 years shall only switch on/off the
3
appliance provided that it has been placed or installed in its intended normal
operating position and they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the hazards involved. Children
aged from 3 years and less than 8 years shall not plug in, regulate and clean the
appliance or perform user maintenance.
• This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children without supervision.
• Young children should be supervised to ensure that they do not play with the
appliance.
• Check the correct operation at all times. Do not leave the heater running alone in
a room with people with reduced mobility, mental disabilities, children or animals.
• Do not use the appliance with wet hand or connect the switch whilst your hands
are wet.
• Do not repair the appliance by yourself in case of any malfunction. Contact
Heatzilla technical service department for a proper repair.
• All electrical work must only be undertaken after disconnection of the power by
removing fuses or turning off the circuit breaker, to ensure all pole isolation of the
electrical supply.
• Wipe with a dry cloth moistened with soap and water. Dry thoroughly. Unplug the
power before cleaning. Do not allow water inside.
Important Warning:
• Do not carry the unit by holding the power cord.
• Do not insert objects through the protective grill.
• Do not use the device in a bathroom
• Always use the ceramic heater with the included foot and upright.
4
Parts of the SY-CLP55
1. Handle
2. Power and turbo knob
3. Rotating switch
4. Heat intensity knob
5. Back panel
6. Protection grill
7. Heating element
8. Tip over security switch
Using the SY-CLP55
Before first use:
• Take the appliance and accessories out of the box. Remove the stickers, protective foil or
plastic from the appliance.
• Connect the power cable to the socket. (Note: make sure the voltage which is indicated on
the appliance matches the local voltage before connecting the appliance. 220-
240V~50/60Hz
• Make sure to place the appliance on a flat, dry and stable surface. This appliance is only
suitable for indoor and for domestic use.
• Make sure to not place the appliance against curtains or furniture. Keep a minimum distance
of 50 cm. between the rear, front, sides and top part of the heater.
Using the ceramic heater:
• Power & turbo knob – functions
● : OFF
: Flow of cool air
I : Low Heating power (750W)
II : High Heating power (1500W)
5
• If you have selected minimum or maximum power, choose the desired temperature with
the thermostat. With the thermostat, the temperature can be regulated continuously.
When the desired temperature is reached, the unit will turn off
automatically. Once the temperature has dropped below the
programmed level, the heater will turn on again.
• When you stop using the heater, turn off all of the power switches, and then disconnect the
plug from the wall outlet.
• If you wish to move the heater, please turn off the switches, disconnect the plug, and carry
the unit using the handle on top of the unit.
• This unit has a rotation function feature. Press the button (3) down to begin rotating. Press it
again to stop rotating.
Safety control
To avoid damage and danger by overheating, the heater is fitted with an electric protector/tip
over switch function that switches off the heater in case the heater tilts or falls.
Cleaning and maintenance
• Make sure to switch off the appliance remove the switch from the outlet before cleaning.
• Allow the appliance to cool down completely before cleaning or touching it.
• Clean the outside cabinet with a soft damp cloth. Never immerse the unit in water or any
other liquid.
• Do not use solvents or any chemical substance during internal or external cleaning and
be careful not to allow the moisture to penetrate the electrical parts.
• Do not use waxes or polishing materials. These products may react with the heat
causing discoloration of the paint.
• Do not use sharp objects, hard brushes or industrial cleaners to clean the unit.
• Always wrap the plug cable before storing it, to prevent accidents, tripping and falls.
• Do NOT attempt to repair or adjust any electrical or mechanical functions on this unit.
Doing so will void the warranty
• Always store your appliance on a flat, firm, clean and dry surface, out of reach of
children and where there is no dust and moisture.
• If you have any questions regarding this unit’s operation or believe any repair is
necessary, please contact Heatzilla.
6
Guidelines for protection of the environment
Used electrical and electronic products must not be discarded with household
waste. The presence of this symbol on the product or its packaging serves as a
reminder of this. Some of the materials of which this product is comprised can be
recycled if they are taken to an appropriate recycling centre. By reusing the
components and raw materials of used products, you contribute significantly to
protecting the environment. For further information on collection sites for used
equipment, you can enquire at your town council, the waste treatment department,
or the shop where you have purchased the product.
Do not dispose of batteries with the household waste. Return used batteries to a
battery recycling centre.
Dispose of the packing materials in accordance with local regulations.
Packaging:
The packaging is 100% recyclable, return the packaging separated.
Specifications
Ceramic portable heater
Adjustable power (750 / 1500W)
Thermostat to adjust the temperature
Manual adjustment for: Fresh, moderate, hot air
Ceramic resistance
90º oscillation
Tip over protection switch
Overheating protection
Instant heat emission
Maximum heat and lower consumption.
Power: 220-240V ~ 50 / 60Hz.
This device complies with the EC directives. The product has been tested according to
all current European directives, applicable such as electromagnetic compatibility (EMC)
and low voltage (LVD).
This device has been designed and manufactured in compliance with the latest
regulations and technical requirements for safety.
7
Declaration of Conformity
Manufacturer Name: Satyatrade S. L.
Address: Pol. Ind. La Raya. C/ Guadalquivir, 2.
Camarma de Esteruelas, 28816 Madrid
Tel: 902 430 967
Fax: 91 8864285
NIF: B83254763
Manufacturing country: China
Description: Ceramic Portable Heater
Heatzilla® SY-CLP55 complies with the following directives:
EMC Standard: Directive 2014/30/EU
LVD Standard: Directive 2014/35/EU
ROHS Standard: Directive 2011/65/EU Restriction of Hazardous Substances
Signed: Ajeet Nebhwani Utamchandani
Sole Administrator
