Advance / Advance Plus
Installer manual
Translation of the original document
Introduction
This manual is intended for use by the installer of the ventilation
system. It contains important information concerning installation,
use, maintenance and troubleshooting for the ventilation system.
The installer is responsible for installing and commissioning the
ventilation unit.
The following definitions are used in this manual to draw attention
to hazards, instructions or indications related to people, products,
installations and/or the surroundings.
ä Warning!
Indicates a hazard that can cause injury and/or severe damage
to the product, system or surrounding area.
ä Caution!
Instructions important for the installation, functioning, operation
or maintenance of the product. Failure to observe these
instructions can result in minor injury and/or severe damage to
the product, system or surrounding area.
Note
Instructions important for the installation, functioning, operation
or maintenance of the product. Failure to observe these
instructions can result in minor damage to the product, system
or surrounding area.
Tip
Instructions that may be important for the installation,
functioning, operation or maintenance of the product, but are
not related to injury or material damage.
Tip
Do not forget to register the product via the Heatrae Sadia
website. (www.heatraesadia.com/warranty_registration)
Although this manual has been drawn up with the utmost care, no
rights may be derived from this document.
Heatrae Sadia reserves the right to modify products and manuals
without prior notice.
Due to our continuous product improvement process, the
illustrations in this document may not match the delivered product.
The latest version (if available) can be downloaded from our
website via www.heatraesadia.com.
3
Contents
1. Safety and other regulations 5
2. Product information 7
2.1. Models 7
2.2. Accessories 7
2.3. Technical specifications 8
2.4. Capacity 8
2.5. Technical drawings 9
2.6. Parts 10
2.7. Controls 11
3. Installation 13
3.1. Installation requirements 13
3.2. Installing the ventilation unit 13
3.3. Connecting the condensate drain 21
3.4. Connecting the ducts 22
3.5. Electrical connection 23
4. Operation 24
4.1. Control options 24
4.2. RF-VI wireless remote control 24
4.3. Wireless control switch with timer 25
4.4. Wireless control switch with automatic control/
timer
26
4.5. Wired three-position switch 26
4.6. Pairing and unpairing RF remote controls 27
4.7. Pairing and unpairing RF sensors 27
5. Commissioning 28
5.1. Preparation 28
5.2. Putting into service 28
5.3. Adjusting the capacity 29
6. Inspection and maintenance 30
6.1. Inspection and maintenance schedule 30
6.2. Check for unusual noises 31
6.3. Inspecting and cleaning the fan 31
6.4. Inspecting and cleaning the bypass valve 32
6.5. Inspecting, cleaning and replacing filters 34
6.6. Maintenance 35
6.7. RF remote control maintenance 35
6.8. Inspection of additional RF sensors 35
6.9. Inspecting and cleaning air valves 35
6.10. Inspecting/cleaning ducts 35
7. Faults 36
8. Service parts 40
9. Warranty 42
10. Declarations 43
4
1. Safety and other regulations
äWarning!
●The specifications and settings of the
ventilation system comply exclusively with
the standards and statutes of the country
in which the ventilation system is sold.
Applications outside this country can lead
to very dangerous situations.
●The entire system must comply with the
current regulations as referred to in this
document and other applicable
documents provided by the manufacturer.
●All supplements, amendments and
regulations effective at the time of
installation are applicable for all
regulations.
●After installation, no health, safety or
environmental risks may be present in
accordance with the applicable CE
standards. This also applies to other
products included in the system.
●Do not use the product for purposes other
than those for which it is intended, as
described in this manual.
●Be careful when using electrical
appliances:
-Never touch the appliance with wet
hands.
-Never touch the appliance when
barefoot.
●This product and/or system may be
operated safely by children aged 12 years
and older and by people with physical,
sensory or mental disabilities or a lack of
experience/knowledge if under
supervision or after having received
instructions regarding safe use, and if they
are aware of the product and/or system
hazards.
●Cleaning and maintenance by the user
may not be done by children or people
with physical, sensory or mental
disabilities or a lack of experience/
knowledge without supervision.
●Do not allow children to play with the
product and/or system.
●Do not use the product in the vicinity of
flammable or volatile substances such as
alcohol, insecticides, petrol etc.
●Work may solely be performed on the
system by Heatrae Sadia or recognised
installers in accordance with the provisions
laid down in this manual. Only original
accessories and parts produced by the
manufacturer may be used for these
purposes.
●The system includes parts which may be
live. The installer should take the following
steps before carrying out work on an open
system:
-Disconnect power to the appliance or
system by unplugging the power cord
at the wall socket.
5
-Secure the appliance or system against
being switched on accidentally.
-The appliance includes moving parts.
When the plug is removed from the
wall socket, these parts will continue
moving for a few seconds. Therefore,
you should wait a minimum of 10
seconds before opening the appliance
after removing the plug.
äImportant!
●The safety instructions must be followed in
order to prevent physical injury and/or
damage to the product.
●Maintenance instructions must be
followed to prevent damage and
excessive wear and tear.
●The product may not be modified.
●The product is only suitable for use with a
230 V, 50 Hz AC power supply system.
●Ensure that the electrical system to which
the product is connected meets the
necessary conditions.
●Do not expose the product to the
elements.
●Do not place any objects on top of the
device.
●Inspect the product regularly for faults. In
the event of faults, immediately contact
your installer or Heatrae Sadia.
●Switch the product off if:
-The product is not working properly.
-You want to clean the outside of the
product.
●Ensure that the electrical circuit does not
become damaged.
●Do not use the device to extract air from
boilers, heating systems etc.
●Ensure that the device drains into a sewer
system which leads outside, and is
suitable and installed for this purpose.
●Ensure that air valves and grilles are not
obstructed, and that they are clean.
●Watch out for sharp and protruding duct
sections during periodic cleaning of air
valves and grilles.
6
2. Product information
The Advance and Advance Plus consist of a central balanced
ventilation unit with a heat recovery system and a duct connection
set. The Advance Plus is also equipped with an automatic bypass
valve. The operation of the bypass valve is described under Bypass
control on page 12.
2.1. Models
Models
Item Type Description
95060001 Advance Balanced ventilation unit with heat
recovery
95060007 Advance Plus Balanced ventilation unit with heat
recovery and bypass valve
2.2. Accessories
Accessories
Item no. Type Description
95970200 RF-VI
TRANSMITTER
Wireless RF-VI remote with LED signals,
three modes and timer function
95970003 RFT-
TRANSMITTER
W
Wireless RF control switch with three
settings and a timer function (White)
95970204 RFT-AUTO CO2 RF control switch with two positions,
automatic and timer functions
95970002 HRS-3I C Conventional wired switch with three
settings
95970201 RF-CO2 230 V RF CO2-sensor
95970203 RF-RH [BAT] RF-RH battery-powered sensor
95970202 RF-PIR RF-PIR battery-powered presence sensor
7
2.3. Technical specifications
Advance/Advance Plus
Dimensions (H x W x D) 760 x 597 x 290 mm
Weight 12 kg (including duct connection set)
Installation 2x 6 mm screws (not provided); on wall/ceiling/floor with min. load-bearing
capacity 200 kg/m2
Housing IP 30, double-insulated
Housing and insulation EPP housing (grey), PP hollow-core panel (internal), foamed PVC faceplates
(white)
Duct connection parts /
condensate drain
PP (black)
Motor module HIPS (black)
Filter caps TPE (RAL 7040)
Mounting brackets Galvanised steel
Filter class Standard G3 (dust filter for the first three months), then replace with G4 or F7
Duct nozzles (4x) Ø 125 mm, top side, with leak-safe seals
Heat exchanger Plastic counterflow exchanger (PS), not removable
Thermal efficiency Up to 91%
Condensate drain (2x) Ø 14 mm OD, PVC condensate hose (1 m), included
Temperature sensors 1x outside air temperature sensor; 1x exhaust air temperature sensor
Bypass control*Automatic control with built-in bypass valve on extraction side, 100%
Frost control Automatic frost protection (reduce fan speed at temperatures below -1°C)
Motor (1x) DC (CE) 120 W
Impellers (2x) PA plastic (backward curved)
Maximum power consumption 90 W
Power supply 230 V, 50 Hz, 4-wire power cable
Cable length 1.5 m (RAL 7001)
RF (built in) 100 m in free space, 868 MHz
Manual The user manual can also be placed in the bottom corner of the unit
* Applies exclusively to Advance Plus
2.4. Capacity
Capacity [m3/h] Pressure [Pa] Power [W]
Mode 1 minimum 25 12 4
Mode 1 standard 50 17 6
Mode 1 maximum 75 38 13
Mode 2 *100 70 26.5
Mode 3 minimum 75 38 13
Mode 3 standard 125 104 44
Mode 3 maximum 150 150 72
Mode 3 maximum 175 100 78
* Mode 2 is a calculated value, depending on the set minimum and maximum capacity.
Mode 1 and 3 can be adjusted using the potentiometers on the
motor module.
(see Adjusting the capacity on page 29).
8
2.5. Technical drawings
>50 (1) >50 (1)
>150 (1)
> 150 (1)
290 >360 (1)
B
5
5
4
1
3230V
2
76 76
425
132
86 86
122
A
760
597
(1) Minimum clearance around the ventilation unit
Number Description
1Exhaust air to outside
2Exhaust air from dwelling
3Supply air from outside
4Supply air to dwelling
5Condensate drain (2x)
9
2.6. Parts
7
9
8
4
6
5
1
3
2
7
9
8
4
6
5
1
3
2
10
Main components of Advance and Advance Plus
Number Description
1Ventilation unit
2Motor module
3Duct adapter EPP side
4Mounting bracket
5Duct adapter duct side
6Wire bracket
7Filter
8Filter cap
9Ceiling mounting bracket
10 Bypass valve *
* Applies exclusively to Advance Plus
10
