SC60

Woodburning Fireplace

2 in min. air

space clearance

from chimney

43-1/8 in

25 in

41-1/4 in

8 in

a brand of Hearth & Home Technologies Inc.

1915 West Saunders Street • Mt. Pleasant, Iowa 52641

800-927-6841 • heatilator.com

The information provided in this literature is for planning purposes only and subject to change.

Please consult the installation manual for actual installation. The ame and ember appearance

may vary based on the type of fuel burned and venting conguration used. For full warranty

details, go to heatilator.com.

*Please consult the MSRP book for a complete list of optional accessories.

Photo on cover shown with optional air gasketed door.

AVAILABLE FROM

HTL-1024U-1008

Options

DM Doors

Fireside Gas Logs

• Exceptional heating capacity of 70,000 Btu/hr.

• Large viewing area with 36" wide and 19-1/8" tall opening

• Firebox assembly is fully insulated and comes standard with rebrick lining and

outside air kit

• Standard 160 CFM fan with blower control connects directly to stainless steel

heat tubes for added heat output

• Ability to control combustion rate and heat output via the air kit and ue

damper assemblies

• A hearth extension is required

• SL300 Series venting

• Tested and listed to UL safety standards

• Heatilator Warranty

SC60

Incredible Heating Capacity

Options*

Product Dimensions

Framing

Dimensions

Gasketed Air Control Door

40-3/4 in.

19-1/8 in.

7-3/4 in.

35 in.

36 in.

42-1/8 in.

Damper

Handle

25 in.

10-1/4 in.

9 in.

Gas Knockout

10-1/2 in.

Dia.

10-1/2 in.

Dia.

25 in.

3-7/8 in.

9-7/8 in.

1-1/8 in.

18-3/4 in.

10-1/4 in.

9 in.

40 in.

(effective height)

3-1/2 in.

Gas Knockout

Outside

Air

21-1/8 in.

12-1/2 in.

25 in.

2 in min. air

space clearance

from chimney

43-1/8 in

25 in

41-1/4 in

8 in
