Page 2
Do not use Fireye Programmer Module YP100
on a Heatec heater unless the module was
programmed at the Heatec factory. New modules
obtained directly from Fireye or other suppliers
may not be programmed to ensure safe operation
of Heatec heaters. Inappropriate programming
could result in an explosion with serious injuries or
death.
In order to comply with safety codes applicable to
our heaters we reset all new Fireye programmer
modules that we use on our heaters. We lock the
settings to ensure that they cannot be changed
accidentally.
If a heater is operated using a new module with
unlocked settings, those settings will be locked
automatically after eight hours of operation. And
once those settings are locked, they are permament
and cannot be changed.
To make sure that your programmer module has
the appropriate Heatec settings, check all of its
settings shown in the Heatec settings column of
Figure 3. Make this check immediately after
installing the new controller. Heatec settings that
differ from the Fireye factory default settings are
shown in red. Heatec settings that are the same as
Fireye factory default settings are marked same as
Fireye default.
Please refer to Fireye Publication BL-1001
for instructions on use of the keypad to check
factory default parameters. A printed copy of this
document is furnished with Fireye Burner Logix
controls. It is also available as a pdf document
from the Fireye website at: http://www.fireye.net/
pdf/BL-1001.pdf
Figure 3. Fireye factory settings vs Heatec factory settings.
Parameter Fireye Factory Default Heatec settings
Purge time 00:30s 00:60s
Count method DOWN Same as Fireye default
Prove 3-P open at start NO YES
PTFI*MTFI timing 10/10*10/15 Same as Fireye default
Terminal 6 interrupted or intermittent INTRP Same as Fireye default
Prove M-8 open NO YES
Prove M-D open NO YES
Post purge 0:15 Same as Fireye default
3-P Recycle YES Same as Fireye default
M-D WAIT 10m YES Same as Fireye default
PROVE M-D TFI NO YES
Baud rate 9600 Same as Fireye default
Unit address 00 Same as Fireye default
Lock Settings NO YES
DO IR LEARN NO Same as Fireye default
