Heat Controller VMH 09 Manuel

Heat Controller, Inc. • 1900 Wellworth Ave. • Jackson, MI 49203 • (517)787-2100 • www.heatcontroller.com

REPLACEMENT

PARTS MANUAL

VMH 09/12/18/27/36

Version C

InverterFlex

Ductless Mini-Split Heat Pump

VMH InverterFlex Mini-Split REPLACEMENT PARTS MANUAL Heat Controller, Inc.

B-VMH09FC-1 Indoor Unit Exploded View

Heat Controller, Inc. REPLACEMENT PARTS MANUAL VMH InverterFlex Mini-Split

B-VMH09FC-1 Indoor Unit Parts List

LOCATION PART DESCRIPTION QUANTITY PART NO.

1 Front panel assy 1 201132390011

2Air lter(left)(silver ion) 1 201132300002

3 Air cleaner 1 201130100212

4 Air cleaner holder 1 201130100217

5 Display box assy 1 203332590183

5.1 Display board assy 1 201332590136

6Window cover for repairing 1 201132500012

7 Screw cap 3 201132300037

8Panel frame assy 1 201132300026

8.1 Louver motor 1 202400200105

9Air out frame assy 1 201132390014

9.1 Vertical grille 10 201132590031

9.2 Louver holder 1 201132500032

9.2 Louver holder 1 201132500031

9.4 negative ion engender 1 202403000006

9.5 Louver motor 1 202400200017

11 Drain hose 1 201101020014

12 Bafe of temperature induction 1 201130490002

14 Breakwater 1 201132500002

15 Evaporator,assy 1 201532390005

16 Motor cover 1 201132500017

17 Motor 1 202400300137

18 Bearing holder 1 202730100201

19 Cross ow fan 1 201100200100

20 Chassis 1 201132300000

21 Connecting pipe clamp 1 201232500001

23 Installation plate 1 201232590025

24 Electronic control box,indoor unit 1 203352090128

24.1 E-Parts box's cover 1 201132500798

24.2 E-Parts box 1 201132500022

24.3 Main control board 1 201332390781

24.3.1 Wires capacitor 1 202401200001

24.4 Indoor temp sensor 1 202433190000

24.5 Evaporator temp sensor 1 202301300080

24.6 Wire join 1 202301400064

24.8 Transformer 1 202300900097

25 Remote Controller 1 203355091200

26 Holder,Remote Controller 1 201155000024

27 Seal 1 202720090001

29 Copper nut 1 201600320001

29 Copper nut 1 201600320000

30 Hinge Slide groove 2 201132300005

31 Airinlet grille Assebmly 1 201132300027

32 Horizontal louver 1 201132300033

34 Air lter(right)(silver ion) 1 201132300001

VMH InverterFlex Mini-Split REPLACEMENT PARTS MANUAL Heat Controller, Inc.

B-VMH12FC-1 Indoor Unit Exploded View

Heat Controller, Inc. REPLACEMENT PARTS MANUAL VMH InverterFlex Mini-Split

B-VMH12FC-1 Indoor Unit Parts List

LOCATION PART DESCRIPTION QUANTITY PART NO.

1 Front panel assy 1 201132590008

2Air lter(left)(silver ion) 1 201132500013

3 Air cleaner 1 201130100212

4 Air cleaner holder 1 201130100217

5 Display box assy 1 203332590183

5.1 Display board assy 1 201332590136

6Window cover for repairing 1 201132500012

7 Screw cap 3 201132500055

8Panel frame assy 1 201132500052

8.1 Louver motor 1 202400200105

9Air out frame assy 1 201132590023

9.1 Vertical grille 10 201132590031

9.2 Louver holder 1 201132500032

9.2 Louver holder 1 201132500031

9.3 Horizontal louver 1 201132500060

9.4 negative ion engender 1 202403000006

9.5 Louver motor 1 202400200017

11 Drain hose 1 201130000011

12 Bafe of temperature induction 1 201130490002

14 Breakwater 1 201132500002

15 Evaporator,assy 1 201532590004

16 Motor cover 1 201132500017

17 Motor 1 202400300137

18 Bearing holder 1 202730100201

19 Cross ow fan 1 201100200106

20 Chassis 1 201132500007

21 Connecting pipe clamp 1 201232500001

23 Installation plate 1 201232590025

24 Electronic control box,indoor unit 1 203352090129

24.1 E-Parts box's cover 1 201132500798

24.2 E-Parts box 1 201132500022

24.3 Main control board 1 201332590505

24.3.1 Wires capacitor 1 202401200001

24.4 Indoor temp sensor 1 202433190000

24.5 Evaporator temp sensor 1 202301300080

24.6 Wire join 1 202301400064

24.8 Transformer 1 202300900097

25 Remote Controller 1 203355091200

26 Holder,Remote Controller 1 201155000024

29 Copper nut 1 201600320002

29 Copper nut 1 201600320000

30 Hinge Slide groove 2 201132500010

31 Airinlet grille Assebmly 1 201132500054

34 Air lter(right)(silver ion) 1 201132500011

VMH InverterFlex Mini-Split REPLACEMENT PARTS MANUAL Heat Controller, Inc.

A-VMH18DC-1 Outdoor Unit Exploded View

Heat Controller, Inc. REPLACEMENT PARTS MANUAL VMH InverterFlex Mini-Split

A-VMH18DC-1 Outdoor Unit Parts List

LOCATION PART DESCRIPTION QUANTITY PART NO.

1Rear grille 1 2011481G0001

2Indoor temp sensor 1 202301300196

3Condenser coil assembly 1 201557090037

4Pipe Temperature Sensor 1 202440500004

4Pipe Temperature Sensor 1 202301300423

5 Valve plate 1 201257190060

6Base pan assembly 1 201257090030

7Right clapboard 1 201257190056

8 Valve cover 1 201135600000

9Front right clapboard assembly 1 201245500804

10 Partition plate assembly 1 201257190026

11 Front panel 1 20124810G002

12 Front grille 1 201235390011

13 Motor mounting bracket assembly 1 2012481G0039

14 Axial ow fan blade assembly 1 201145500002

15 Left support 1 201248100070

16 Fan motor 1 202400400955

17 Supporter of back 1 201248100076

18 Handle (small) 1 201150290006

19 Top cover assembly 1 20125719G005

21 Reactor 1 202301000818

21 Reactor 1 202301000832

21 Reactor 1 202301040055

24 Cover for reactance lter 1 201237790013

25 Electrical box assembly 1 203357090028

25.1 E-Parts box 1 201257190050

25.2 Main control board holder 1 201157390005

25.3 Main control board 1 201357090035

25.4 Inverter control board subassembly 1 201357090032

25.5 Motor capacitor 1 202401100353

25.6 Terminal Block 2 202301450156

25.7 Wire Clip 1 201157390004

25.9 Radiator 1 202301990007

25.10 Capacitor,Compressor 1 202401000508

25.11 Clip, capacitor 1 201200100026

26 Liquid valve assembly 1 201657090307

26.1 Electronic expansion valve 2 201601300106

26.2 Liquid pipe valve 2 201600740100

27 Electronic expansion valve Solenoid 2 201601300107

28 4-way valve subassembly 1 201657090312

28.1 Gas valve 2 201600720091

28.2 4-way valve 1 201600690011

29 Discharge temp sensor Ass'y 1 202448200000

30 Compressor 1 201400600540

31 Crank case heater 1 202403100500

39 Clamp for front grille 8 201135110801

40 Handle (large) 1 201257190054

41 Electrical box cover 1 201257090037

VMH InverterFlex Mini-Split REPLACEMENT PARTS MANUAL Heat Controller, Inc.

A-VMH27TC-1 Outdoor Unit Exploded View

Heat Controller, Inc. REPLACEMENT PARTS MANUAL VMH InverterFlex Mini-Split

A-VMH27TC-1 Outdoor Unit Parts List

LOCATION PART DESCRIPTION QUANTITY PART NO.

1Rear grille 1 2011481G0001

2Indoor temp sensor 1 202301300196

3Condenser coil assembly 1 201557190030

4Pipe temperature sensor 1 202440500004

4Pipe temperature sensor 1 202301300422

5 Valve plate 1 201257190060

6Base pan assembly 1 201257090030

7Right clapboard 1 201257190056

8 Valve cover 1 201135600000

9Front right clapboard assembly 1 201245500804

10 Partition plate assembly 1 201257190026

11 Front panel 1 20124810G002

12 Front grille 1 201235390011

13 Motor mounting bracket assembly 1 2012481G0039

14 Axial ow fan blade assembly 1 201145500002

15 Left support 1 201248100070

16 Fan motor 1 202400400955

17 Supporter of back 1 201248100076

18 Handle (small) 1 201150290006

19 Top cover assembly 1 20125719G005

21 Reactor 1 202301000818

21 Reactor 1 202301000832

21 Reactor 1 202301000814

24 Cover for reactance lter 1 201237790013

25 Electrical box assembly 1 203357190029

25.1 E-Parts box 1 201257190050

25.2 Main control board holder 1 201157390005

25.3 Main control board 1 201357190030

25.4 Inverter control board subassembly 1 201357190027

25.5 Motor capacitor 1 202401100353

25.6 Terminal block 2 202301450156

25.7 Wire Clip 1 201157390004

25.9 Radiator 1 202301990006

25.10 Capacitor, compressor 1 202401000612

25.11 Clip, capacitor 1 201200100026

26 Liquid valve assembly 1 201657190227

26.1 Electronic expansion valve 3 201601300106

26.2 Liquid pipe valve 3 201600740100

27 Electronic expansion valve solenoid 3 201601300107

28 4-way valve subassembly 1 201657190224

28.1 Gas valve 3 201600720091

28.2 4-way valve 1 201600690011

29 Discharge temp sensor assembly 1 202448200000

30 Compressor 1 201400600530

31 Crank case heater 1 202403100500

39 Clamp for front grille 8 201135110801

40 Handle (large) 1 201257190054

41 Electrical box cover 1 201257090037

VMH InverterFlex Mini-Split REPLACEMENT PARTS MANUAL Heat Controller, Inc.

A-VMH36QC-1 Outdoor Unit Exploded View
