Heat Controller VMH 09 Manuel

Heat Controller, Inc. • 1900 Wellworth Ave. • Jackson, MI 49203 • (517)787-2100 • www.heatcontroller.com

REPLACEMENT

PARTS MANUAL

VMH 09/12/18/24

Version C

Inverter Single Zone

Ductless Mini-Split Heat Pump

VMH Inverter Mini-Split REPLACEMENT PARTS MANUAL Heat Controller, Inc.

VMH09SC-1 Indoor Unit Exploded View

Heat Controller, Inc. REPLACEMENT PARTS MANUAL VMH Inverter Mini-Split

VMH09SC-1 Indoor Unit Parts List

LOCATION PART DESCRIPTION QUANTITY PART NO.

1 Front panel assy 1 201132590008

2Air lter(left)(silver ion) 1 201132500013

3 Air cleaner 1 201130100212

4 Air cleaner holder 1 201130100217

5 Display box assy 1 203332590183

5.1 Display board assy 1 201332590136

6Window cover for repairing 1 201132500012

7 Screw cap 3 201132500055

8Panel frame assy 1 201132500052

8.1 Louver motor 1 202400200105

9Air out frame assy 1 201132590041

9.1 Vertical grille 10 201132590031

9.2 Louver holder 1 201132500032

9.2 Louver holder 1 201132500031

9.3 Horizontal louver 1 201132500060

9.4 negative ion engender 1 202403000006

9.5 Louver motor 1 202400200017

11 Drain hose 1 201101020014

12 Bafe of temperature induction 1 201130490002

14 Breakwater 1 201132500002

15 Evaporator,assy 1 201532390036

16 Motor cover 1 201132500017

17 Motor 1 202400370022

18 Bearing holder 1 202730100201

19 Cross ow fan 1 201100200106

20 Chassis 1 201132500007

21 Connecting pipe clamp 1 201232500001

23 Installation plate 1 201232590025

24 Electronic control box,indoor unit 1 203332390677

24.1 E-Parts box's cover 1 201132500021

24.2 E-Parts box 1 201132500022

24.3 Main control board 1 201332390823

24.4 Indoor temp sensor 1 202433190000

24.5 Evaporator temp sensor 1 202301300080

24.6 Wire join 1 202301450119

25 Remote Controller 1 203355091200

26 Holder,Remote Controller 1 201155000024

27 Seal 1 202720090001

28 Connector for watering 1 201101020011

29 Copper nut 1 201600320001

29 Copper nut 1 201600320000

30 Hinge Slide groove 2 201132500010

31 Airinlet grille Assebmly 1 201132500054

34 Air lter(right)(silver ion) 1 201132500011

VMH Inverter Mini-Split REPLACEMENT PARTS MANUAL Heat Controller, Inc.

VMH09SC-1 Outdoor Unit Exploded View

Heat Controller, Inc. REPLACEMENT PARTS MANUAL VMH Inverter Mini-Split

VMH09SC-1 Outdoor Unit Parts List

LOCATION PART DESCRIPTION QUANTITY PART NO.

1Indoor temp sensor 1 202301310063

2Rear grille 1 2011374G0003

3Condenser coil assembly 1 201537390033

4Pipe Temperature Sensor 1 202440500004

5 Valve plate 1 201235120614

6Base pan assembly 1 201237590048

7 Clip, capacitor 1 201200100005

8Capacitor,Compressor 1 202401000612

9Handle (large) 1 201235290217

10 Valve cover 1 201135270201

11 Right clapboard 1 201237590003

16 Partition plate assembly 1 201237590008

17 Front panel 1 201237400029

18 Front grille 1 201235100023

19 Motor mounting bracket assembly 1 201237390026

20 Axial ow fan blade assembly 1 201100390002

21 Left support 1 201237400028

22 Fan motor 1 202400370023

24 Top cover assembly 1 201235270249

25 2-Cover for reactance lter 1 201235250802

26 Reactor 1 202301000820

26 Reactor 1 202301000819

27 Electrical box assembly 1 203337390159

27.1 E-Parts box 1 201237300033

27.2 Radiator 1 202301900068

27.3 E-Parts box’s cover 1 201237300162

27.4 Main control board 1 201337390096

27.5 Holder for E-parts 1 201137300162

28 Board of terminal,assy 1 203337590049

28.1 Wire joint 1 202301400223

28.2 Washer for wire joint 1 201135000004

28.3 Board of terminal 1 201237590046

29 Liquid valve assembly 1 201637390095

29.1 Liquid valve 1 201600740523

30 Gas valve assembly 1 201632390037

30.1 Gas pipe valve 1 201600720200

30.2 4-Ways valve 1 201600670003

31 Discharge temp sensor assembly 1 202301310068

32 Rotary compressor 1 201400620600

33 Crank case heater 1 202403100501

38 Handle (small) 1 201150290006

40 Electric pipe heater 1 202403100187

VMH Inverter Mini-Split REPLACEMENT PARTS MANUAL Heat Controller, Inc.

VMH12SC-1 Indoor Unit Exploded View

Heat Controller, Inc. REPLACEMENT PARTS MANUAL VMH Inverter Mini-Split

VMH12SC-1 Indoor Unit Parts List

LOCATION PART DESCRIPTION QUANTITY PART NO.

1 Front panel assy 1 201132590008

2Air lter(left)(silver ion) 1 201132500013

3 Air cleaner 1 201130100212

4 Air cleaner holder 1 201130100217

5 Display box assy 1 203332590183

5.1 Display board assy 1 201332590136

6Window cover for repairing 1 201132500012

7 Screw cap 3 201132500055

8Panel frame assy 1 201132500052

8.1 Louver motor 1 202400200105

9Air out frame assy 1 201132590041

9.1 Vertical grille 10 201132590031

9.2 Louver holder 1 201132500032

9.2 Louver holder 1 201132500031

9.3 Horizontal louver 1 201132500060

9.4 negative ion engender 1 202403000006

9.5 Louver motor 1 202400200017

11 Drain hose 1 201101020014

12 Bafe of temperature induction 1 201130490002

14 Breakwater 1 201132500002

15 Evaporator,assy 1 201532590004

16 Motor cover 1 201132500017

17 Motor 1 202400370022

18 Bearing holder 1 202730100201

19 Cross ow fan 1 201100200106

20 Chassis 1 201132500007

21 Connecting pipe clamp 1 201232500001

23 Installation plate 1 201232590025

24 Electronic control box,indoor unit 1 203332590475

24.1 E-Parts box's cover 1 201132500021

24.2 E-Parts box 1 201132500022

24.3 Main control board 1 201332590549

24.4 Indoor temp sensor 1 202433190000

24.5 Evaporator temp sensor 1 202301300080

24.6 Wire join 1 202301450119

25 Remote Controller 1 203355091200

26 Holder,Remote Controller 1 201155000024

28 Connector for watering 1 201101020011

29 Copper nut 1 201600320002

29 Copper nut 1 201600320000

30 Hinge Slide groove 2 201132500010

31 Airinlet grille Assebmly 1 201132500054

34 Air lter(right)(silver ion) 1 201132500011

VMH Inverter Mini-Split REPLACEMENT PARTS MANUAL Heat Controller, Inc.

VMH12SC-1 Outdoor Unit Exploded View

Heat Controller, Inc. REPLACEMENT PARTS MANUAL VMH Inverter Mini-Split

VMH12SC-1 Outdoor Unit Parts List

LOCATION PART DESCRIPTION QUANTITY PART NO.

1Indoor temp sensor 1 202301310063

2Rear grille 1 2011374G0003

3Condenser coil assembly 1 201537490008

4Pipe Temperature Sensor 1 202440500004

5 Valve plate 1 201235120614

6Base pan assembly 1 201237590048

7 Clip, capacitor 1 201200100005

8Capacitor,Compressor 1 202401000612

9Handle (large) 1 201235290217

10 Valve cover 1 201135270201

11 Right clapboard 1 201237590003

16 Partition plate assembly 1 201237590008

17 Front panel 1 201237400029

18 Front grille 1 201235100023

19 Motor mounting bracket assembly 1 201237390026

20 Axial ow fan blade assembly 1 201100390002

21 Left support 1 201237400028

22 Fan moter 1 202400370023

24 Top cover assembly 1 201235270249

25 2-Cover for reactance lter 1 201235250802

26 Reactor 1 202301000820

26 Reactor 1 202301000819

27 Electrical box assembly 1 203337390159

27.1 E-Parts box 1 201237300033

27.2 Radiator 1 202301900068

27.3 E-Parts box's cover 1 201237300162

27.4 Main control board 1 201337390096

27.5 Holder for E-parts 1 201137300162

28 Board of terminal,assy 1 203337590049

28.1 Wire joint 1 202301400223

28.2 Washer for wire joint 1 201135000004

28.3 Board of terminal 1 201237590046

29 Liquid valve assembly 1 201637490232

29.1 Liquid valve 1 201600740523

30 Gas valve assembly 1 201637590195

30.1 Gas pipe valve 1 201600720201

30.2 4-Ways valve 1 201600670003

31 Discharge temp sensor Ass'y 1 202301310068

32 Rotary compressor 1 201400620600

33 Crank case heater 1 202403100501

38 Handle (small) 1 201150290006

40 Electric pipe heater 1 202403100187

VMH Inverter Mini-Split REPLACEMENT PARTS MANUAL Heat Controller, Inc.

VMH18SC-1 Indoor Unit Exploded View
