HealTech Electronics ILE-1-KIT Manuel utilisateur

iLogger easy

Supplementary Manual

Yamaha MT-07 ABS 2014- (iLE-1-KIT)

www.healtech-electronics.com 1/4

Secure the bike on a stand.

Remove the seats.

Remove the plastic covers from the fuel

tank.

Remove the fuel tank.

If the iLE is used together with the iQSE

quickshifter, plug the iLE-H-iQSE

connectors in-line with the 4-pole iQSE

connectors, then connect the Red, Black

and White wires to the green terminal

block as show on the photo.

(Without the iQSE connect the iLE-H-PWR

Red and White wire to the ignition coil

connectors and the iLE Black wire terminal

to the battery negative terminal.)

iLogger easy

Supplementary Manual

Yamaha MT-07 ABS 2014- (iLE-1-KIT)

www.healtech-electronics.com 2/4

Connect the green terminal block to the

iLE modul.

Splice the iLE Blue VSS wire to the

White/Yellow wire of the ABS connector.

Optional:

Connect the iLE Black/Green wire to the

Black/Blue wire of the Front Brake

switch behind the headlight.

iLogger easy

Supplementary Manual

Yamaha MT-07 ABS 2014- (iLE-1-KIT)

www.healtech-electronics.com 3/4

Optional:

Connect the iLE Black/White wire to

White wire of the Throttle position

sensor at the ECU connector.

Optional:

Connect the iLE Pink wire to the

Green/White wire of the Engine coolant

temperature sensor at the ECU

connector.

Optional:

Connect the iLE White wire to the Sky

Blue wire of the Neutral indicator light.

(Black, 14-pole multi connector under the

fuel tank)

iLogger easy

Supplementary Manual

Yamaha MT-07 ABS 2014- (iLE-1-KIT)

www.healtech-electronics.com 4/4

Optional:

Connect the iLE Green wire to the

Green/Red wire of the Oil pressure

switch over the right footpeg.

Mount the GPS receiver on the tail

fairing.

Connect the GPS connector to the iLE

module.

Typical position for the iLE module.

Secure the unit properly.
